KSC23 - Kitchen sink CDA - Free user manual and instructions

Product Type	Kitchen Sink
Brand	CDA
Model	KSC23
Material	Stainless Steel
Finish	Satin
Installation Type	Top-mount or undermount
Number of Bowls	Single
Bowl Depth	200 mm (8 in)
Overall Dimensions (approx.)	800 x 500 mm (31.5 x 19.7 in)
Cut-out Dimensions (approx.)	770 x 470 mm (30.3 x 18.5 in)
Weight (approx.)	10 kg (22 lbs)
Drain Size	Standard 90 mm (3.5 in)
Recommended Accessories	Wire sink basket and drainer rack (not included)
Cleaning Instructions	Use mild detergent and soft cloth; avoid abrasive cleaners, bleach, and steel wool
Installation Requirements	Qualified person; level surface; protect from scratches during installation
Warranty	5 years against defects in materials and workmanship
Key Features	Durable stainless steel, easy to clean, resistant to limescale with proper care

Frequently Asked Questions - KSC23 CDA

Is the sink scratch-resistant?

Stainless steel is not scratch-resistant and will show scratches with normal use. However, over time scratches become less noticeable as the finish becomes more uniform. To minimize scratches, avoid using plastic washing-up bowls and use wire sink baskets and drainer racks.

Why do rust spots appear on my new sink?

Rust-colored spots are usually caused by ferrous particles in the water supply from new pipe work, not by the sink itself rusting. Clean with mild detergent, but avoid steel wool. These spots typically disappear within 6 to 12 months.

How do I remove limescale deposits?

Use a mild limescale remover if deposits occur, especially in hard-water areas. Stained limescale from colored foods can be treated with a biological washing powder solution or diluted bleach.

Can I use bleach to clean the sink?

Do not use neat bleach on the sink surface or metal waste, as it may cause tarnishing. A dilute bleach solution can be used for cleaning, but wipe off any spills immediately.

How should I install the sink?

Installation should be carried out by a suitably qualified person. Ensure the sink is level so water drains off, and do not overtighten plumbing fittings. Protect the sink from scratches during installation.

What cleaning products should I avoid?

Avoid abrasive liquids, powders, steel pads, and harsh chemicals like neat bleach, nail polish remover, paint stripper, solvents, and insecticides. These can damage the surface and make it more prone to staining.

How do I prevent staining from food?

Do not leave corrosive foods (e.g., juices, salt, vinegar, mustard) on the sink for long periods. Rinse and dry the sink after use with warm soapy water.

What does the warranty cover?

The 5-year warranty covers defects in materials and workmanship. It does not cover misuse, neglect, transit damage, routine wear and tear, installation faults, or use of unauthorized parts.

Why is my sink discolored with rainbow patterns?

Rainbow discoloration is from environmental factors like water staining, not a product fault. With regular cleaning and use, this effect will disappear over time.

Can I use the sink for commercial purposes?

The warranty does not cover commercial or professional use. The sink is designed for domestic use only.

USER MANUAL KSC23 CDA

Stainless Steel Sinks

Use and Maintenance

|C|D|A|

Taking Care of your Sink

Your CDA sink is manufactured using material developed specifically to withstand the rigours of everyday kitchen use. However, we advise you to follow these precautions to keep the sink in pristine condition:

• Do not use a plastic washing-up bowl in the sink as grit and other particles may become embedded in the bowl and scratch or erode the sink surface. CDA specifically recommend the use of wire sink-baskets and drainer-racks to help protect your sink. Take care to not cut the plastic coating on these accessories with sharp cutlery or the edges of pans, etc.
• Do not use neat bleach or other harsh cleaning agents on the metal sink waste as this may cause tarnishing. This is especially important if the waste is of the brass/brass finish type.
• Avoid dropping heavy or sharp objects into the sink as they may scratch or damage the surface.
• The surface of the sink can be affected by certain chemicals e.g. neat bleach, nail polish remover, paint stripper, solvents, brush cleaner and insecticides. If any of these substances come into contact with the sink, wipe off immediately with a dry cloth, wash with mild detergent and rinse with water.
• Do not use abrasive liquids, powders or steel pads to clean the sink as they will damage the sink surface and make it more susceptible to staining. The sink may be cleaned with a dilute bleach solution.
• In hard-water areas, a limescale deposit may build up on the sink. The limescale may become stained by coloured foods such as coffee or red wine. If this occurs, we recommend use of a mild limescale remover.
• Particularly stubborn organic stains can be removed effectively by soaking the sink in a biological washing-powder solution, dishwasher powder solution or diluted bleach.
• If the sink comes into contact with acidic materials, rinse immediately with plenty of water and wipe with a soft dry cloth.
• Do not leave rusty objects in contact with the sink. Rust can cause staining, cracking or even permanent damage to the sink surface.
• To avoid staining of the surface do not leave food or other materials with corrosive properties such as juices, salt, vinegar, mustard etc. on the sink for a long time.
• After using the sink, rinse it clean with warm soapy water and rinse with clean water before wiping dry.
  • During installation, protect from scratches, scuffs and other damage.
  • Do not overtighten or strain plumbing fittings.
• The moulding and edges of the sink must be absolutely level so water flows off the drainer.

Important Information about your Sink

Although stainless steel sinks are built to last a lifetime, consumers are almost always concerned about three specific natural occurrences that may appear on their new sink.

Scratching

Stainless steel is NOT scratch resistant and is susceptible to scratching through normal wear. Scratches are most prevalent when the sink is brand new but through continual use, scratches will become more uniform and less apparent over time.

Rust spots

Rust coloured spots which may appear on a new sink do not indicate that the sink itself is rusting. The appearance of these spots is attributed to external factors most commonly related to ferrous particles which come through the water supply following the installation of new pipe work. These particles are not visible to the eye until they start to rust and are likely to appear in the first six to twelve months of use. Cleaning may remove the rust stain but not eliminate the cause. It is however important to avoid the use of steel wool which will exacerbate the problem.

Water staining

Limescale deposits and ‘rainbow’ discolouration which may appear on a stainless steel surface are solely due to environmental factors and not inherent faults within the product. Through continuous use and regular cleaning, these effects will disappear.

You Guarantee is Valid Providing that

• The product has been installed by a suitably qualified person.
• Installation has been carried out in accordance with instructions and current legislation.
• Proof of purchase can be produced.
• The product has been used for domestic purposes only.
- The product has not been tampered with or repair attempted or modified by any unauthorised person.
- All products have been installed in accordance local water by laws and any building regulations in force

You Guarantee does not Cover

• Damage by misuse, neglect or transit.
• Use of parts not used or recommended by CDA.
• Routine maintenance, general wear and tear and installation faults.
• Products used for commercial or professional purposes.

Your sink is guaranteed against defects in materials and/or workmanship for 5 years.

At the discretion of CDA, should a fault arise the sink may be repaired or replaced and agreed refitting may be reimbursed on receipt on a faulty sink/part, once they have been inspected and deemed faulty.
