AR248 - Toaster Arzum - Free user manual and instructions

Product Type	Sandwich Maker and Grill
Model	AR248
Brand	Arzum
Power Supply	220-240 V ~ 50 Hz
Power Consumption	700 W
Non-stick Coating	Yes, on both upper and lower cooking plates
Indicator Lights	Red (power/heat) and green (temperature ready)
Cool-touch Handle	Yes, for safe opening
Security Latch	Yes, for locking plates together
Cord Storage	Yes, with heel rests for upright storage
Drip Tray	Yes, for collecting excess oil or crumbs
Cleaning Method	Wipe with damp cloth; do not immerse in water
Safety Features	Automatic temperature control; cool-touch handle; secure latch
Usage	Indoor household use only
Product Life	7 years
Dimensions (approx.)	Not specified; compact countertop size
Weight (approx.)	Not specified; lightweight design
Repairability	Contact Arzum Authorized Service for repairs; use original spare parts
Warranty	Covered by manufacturer guarantee (see manual for details)

Frequently Asked Questions - AR248 Arzum

Can I use this sandwich maker for toasting bread without fillings?

Yes, you can use the Arzum AR248 to toast bread. Simply place the bread slices between the plates and close the lid. Buttering the outside is optional due to the non-stick coating.

How do I know when the appliance is ready to use?

The red power indicator light turns on when plugged in. Once the green temperature light goes off, the appliance is preheated and ready for use.

Can I wash the cooking plates with water?

No, never immerse the appliance or its plates in water. Wipe the non-stick plates with a damp cloth after they have cooled down. Use mild detergent if needed.

What should I do if the cord is damaged?

Do not use the appliance. Contact an Arzum Authorized Service for repair. Do not attempt to replace the cord yourself.

Why does the green light turn on and off during cooking?

The green light is thermostatically controlled. It cycles on and off to maintain the correct cooking temperature.

Can I use metal utensils on the non-stick plates?

No, avoid metal utensils, steel wool, or abrasive cleaners as they can scratch the non-stick coating. Use wooden or silicone utensils.

How do I store the sandwich maker?

After cooling, close the lid and secure the latch. The appliance can be stored upright using the heel rests for cord storage.

Is it safe to leave the appliance unattended while cooking?

It is not recommended. Although the appliance has automatic temperature control, always supervise it during use for safety.

What types of bread can I use?

You can use any type of sliced bread. For best results, butter the outside if desired, but it is not necessary due to the non-stick plates.

Can I cook other foods besides sandwiches?

Yes, the AR248 can also grill items like vegetables or meat, provided they fit between the plates. Adjust cooking time according to personal preference.

USER MANUAL AR248 Arzum

I- Cool-touch handle
2-Temperature (ready) indicator light (green)
3-Energy (power/warm up) indicator light (red)
4- Upper and lower cooking plates
5- Security latch
6- Cord storage and heel rests

Thank you for purchasing Arzum brand Sandwich Maker. We wish this product to make life easier for you, as with other Arzum products offered to you.

In order to obtain utmost output from your appliance, please read carefully this user's manual and save it for further use.

IMPORTANT SAFEGUARDS

• Make sure that the voltage indicated on the Arzum Mintost Midi Sandwich Maker corresponds with the mains voltage in your home. Our company shall not be held liable for any failures owing to any discrepancy and such failures shall not be covered by the guarantee.
- Your appliance is for household use only. Do not use outdoors for commercial or industrial purposes. Otherwise, your appliance shall be treated out of the coverage of guarantee.
• To prevent harming your appliance do not use extension cords that supply insufficient current,
- Keep the appliance away from and out of the reach of children.
- When your appliance is used by the children, the persons with insufficient experiences and knowledge, physically (audio, visual) or mentally handicapped persons, they should be under the close supervision of the person that is responsible for their safety. It should be ensured that the appliance is not played as a toy by children.
- Do not place your appliance over or near direct heat sources such as a stove or heating oven.
- Do not let cord hang over edge of a table or counter, or touch any other appliances or hot surfaces.
- Place the unit on a flat and fixed surface, which would be resistant to heat.
• After having used, remove the mains plug from the wall socket and allow it to cool down; move only after it has completely cooled down.
- When not in use and before cleaning, disconnect the mains plug from power outlet.
- NEVER immerse the appliance into water for cleaning or any other purposes; do not let any water / water steam leak into the unit.
- Do not touch metal parts when in use.
- Avoid actions that may harm or damage the cord or plug of your device. To unplug the appliance, first hold the plug and NEVER pull by the cord.
- Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions or has been damaged in any manner, such as by dropping down, etc. Do not attempt to repair it by yourself. Immediately contact an Arzum Authorized Service. Be careful in using only the original spare parts in your appliance.
- When cleaning, do not use harmful chemicals, or abrasive cleansers such as metal scourers, or steel wool.
• Use your appliance for its intended purposes as recommended.

USING YOUR APPLIANCE

- You can use your Arzum Mintost Midi Sandwich Maker for various purposes such as making sandwiches, and toasting.

• Connect the mains plug to the power outlet. Energy (heating) light will be on and will indicate that the appliance is switched on and started heating.
• Preheat the appliance until the pilot light (temperature light / green light) goes off.

• When using bread; always butter the outside of the slice, and gently close the lid until you are able to close the security latch. Do not force the lid to close.

• The length of cooking time depends on the case, filling and personal taste. Your sandwich maker cooks on both sides at a time.

• It is not necessary to butter the outsides of all breads as the sandwich maker/grill has non-stick cooking plates.

NOTE:

The light is thermostatically controlled and will cycle during cooking to ensure that the correct temperature is maintained.

WARNING:

NEVER touch the outer surfaces of the unit as they heat up during operation. Use

the handle to open the upper cover. Vapor may come out from between the cooking plates of your appliance when the upper body is opened or during the cooking. Pay attention when taking out the foods.

Close-up of a white toilet seat with a curved handle and attached strap (no text or symbols visible)

CLEANING & CARE

• Before cleaning and care, unplug the appliance from the wall socket and allow it to cool down.
  • After each use, wipe cooking plates and drip tray to protect the cooking surfaces coated with the non-stick material.
• You can wipe the cooking plates with a damp cloth after they cool down.
• Do not use abrasive materials such as metal brush or steel wool as this will scratch the non-stick coating.
• Wipe the outer surface of the unit with a soft cloth and wipe dry it. NEVER immerse the appliance into water or other liquids.
• You can store your appliance in the upright position, as the upper and bottom sides will be locked when you close the security latch located on the right side of the metal handle.

Product life 7 years

TECHNICAL SPECIFICATIONS

220-240 V \~ 50 Hz

700 W
