KM36E - Microwave KELVINATOR - Free user manual and instructions

Product Type	Microwave Oven
Brand	Kelvinator
Model	KM36E
Capacity	0.9 cu ft (approx.)
Microwave Power	900 W
Power Consumption	1200 W (approx.)
Voltage	120 V / 60 Hz
Dimensions (W x D x H)	20.3 x 15.8 x 12.2 in (approx.)
Weight	30 lb (approx.)
Control Type	Digital Touch
Turntable	Yes, removable
Door Type	Drop down
Child Lock	Yes
Timer	Up to 99 minutes
Defrost Function	Yes, weight-based
Interior Light	Yes
Cleaning	Wipe with damp cloth; avoid abrasive cleaners
Safety Features	Child lock, auto shut-off, door interlock
Warranty	1 year limited (parts and labor)

Frequently Asked Questions - KM36E KELVINATOR

How do I set the clock on Kelvinator KM36E?

Press the Clock button, then use the number pads to enter the current time. Press Clock again to confirm.

Can I use metal utensils in the microwave?

No, metal can cause sparks and damage the oven. Use only microwave-safe containers.

How do I clean the interior?

Wipe with a damp cloth and mild detergent. Avoid abrasive cleaners. For odors, place a bowl of water with lemon slices and heat for a few minutes.

What is the child lock feature and how to activate it?

The child lock prevents accidental operation. Press and hold the Stop/Clear button for 3 seconds to lock/unlock.

Why does the microwave sometimes make a humming noise?

Humming is normal due to the magnetron and fan. If loud or unusual, check for loose items or contact service.

How do I defrost food using the KM36E?

Press the Defrost button, enter the weight in pounds, and press Start. The microwave will set time automatically.

Can I use the microwave for baking?

This model is a solo microwave, not suitable for baking. For baking, consider a convection microwave.

Why does the turntable not rotate?

Check if the turntable glass and roller ring are properly aligned. If still not rotating, the motor may need replacement.

What is the maximum cooking time?

The timer can be set up to 99 minutes and 99 seconds.

How do I reset the microwave after a power outage?

Simply press the Stop/Clear button to reset. The clock may need to be set again.

USER MANUAL KM36E KELVINATOR

Read these instructions carefully before using your microwave oven, and keep it carefully.

If you follow the instructions, your oven will provide you with many years of good service.

SAVE THESE INSTRUCTIONS CAREFULLY

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since this can

result in harmful exposure to microwave energy. It is important not to

break or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or allow

soil or cleaner residue to accumulate on sealing surfaces.

(c) WARNING: If the door or door seals are damaged, the oven must not

be operated until it has been repaired by a competent person.

ADDENDUM

If the apparatus is not maintained in a good state of cleanliness, its surface could

be degraded and affect the lifespan of the apparatus and lead to a dangerous

situation.

IMPORTANT SAFETY INSTRUCTIONS

To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following:

1. Use this appliance only for its intended uses as described in manual. Do not

they are liable to explode.

Warning. It is hazardous for anyone other than a competent eye is

cover which gives protection against

exposure to microwave energy.

Warning: Only allow children to use the

oven without supervision when adequate

instructions have been given so that the child is able to use the oven in a safe way.

and understand the hazards of improper

Use. Warning: When the application is not used

in the combination mode, children should

only use the oven under adult supervision

due to the temperatures generated.

(Only for grill series) Only use utensils suitable for use in

microwave ovens.

The oven should be cleaned regularly and

any food deposits should be removed.

Read and follow the specific:"PRECAU- IONS TO AVOID POSSIBLE EXPOSURE

TO EXCESSIVE MICROWAVE ENERGY"

When heating food in plastic or paper

containers, keep an eye on the oven due

to the possibility of ignition.

smoke is observed, switch off or unplug the appliance and keep the door closed.

n order to stifle any flames.

Do not overcook food.

Do not use the oven cavity for storage

purposes. Do not store items, such as bread, cooking, and other

such as bread, cookies, etc. inside the oven.

Remove wire twist-ties and metal handles

from paper or plastic containers/bags

before placing them in the oven.

install of locate this oven only in accordance with the installation

structions provided

eggs in the shell and whole hard-boiled

ggs should not be heated in microwave

evens since they may explode, even after microwaves heating has caused

- Microwave heating has ended.

Specifications

Model:	KM36E
Rated Voltage:	230V~50Hz
Rated Input Power(Microwave):	1500W
Rated Output Power(Microwave):	1000W
Oven Capacity:	36L
Turntable Diameter:	∅315mm
External Dimensions:	519x420x315mm
Net Weight:	Approx. 15.5 kg

To Reduce the Risk of Injury to Persons Grounding Installation

DANGER

Electric Shock Hazard

Touching some of the internal

components can cause serious

personal injury or death. Do not

disassemble this appliance.

WARNING

Electric Shock Hazard

Improper use of the grounding

grounding instructions are not completely

understood or if doubt exists as to whether the

appliance is properly installed

and grounded.

CLEANING

Be sure to disconnect the

oven from the power supply.

1. Clean the inside of the oven after using

with a slightly damp cloth.

1. Clean the accessories in the usual way

in soapy water.

1. The door frame and seal and

neighbouring parts must be cleaned

carefully with a damp cloth when they

are dirty.

UTENSILS

CAUTION

Personal Injury Hazard

It is hazardous for anyone

Utensil Test:

1. Fill a microwave-safe container with 1 cup of cold

water (250ml) along with the utensil in question.

1. Cook on maximum power for 1 minute.

against exposure to microwave

energy.

(1)

Materials you can use in microwave oven

Utensils Remarks

Shielding only. Small smooth pieces can be used to cover thin parts of

meat or poultry to prevent overcooking. Arcing can occur if foil is too

close to oven walls. The foil should be at least 1 inch (2.5cm) away from

oven walls.

Browning dish Follow manufacturer's instructions. The bottom of browning dish must be

at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause

the turntable to break.

Dinnerware Microwave-safe only. Follow manufacturer's instructions. Do not use cracked or chipped dishes.

Glass jars Always remove lid. Use only to boat food until just warm. Most glass jars

Glass jars. Always remove lid, too only to heat food until just warm. Most glass jars are not heat resistant and may break.

Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim

Do not use cracked or chipped dishes.

Oven cooking Follow manufacturer's instructions. Do not close with metal tie. Make

bags slits to allow steam to escape.

Paper plates Use for short-term cooking/warming only. Do not leave oven unattended

and cups while cooking.

Paper towels Use to cover food for reheating and absorbing fat Use with supervision

Paper towels Use to cover food for cooking and adding fat use with supervision for a short-term cooking only

Parchment Use as a cover to prevent splattering or a wrap for steaming

paper

Plastic Microwave safe only Follow the manufacturer's instructions. Should be

labeled "Microwave Safe". Some plastic containers soften, as the food

inside gets hot. "Boiling bags" and tightly closed plastic bags should be

slit, pierced or vented as directed by package.

Plastic wrap Microwave-safe only. Use to cover food during cooking to retain

moisture. Do not allow plastic wrap to touch food.

Thermometers Microwave-safe only (meat and candy thermometers).

Wax paper Use as a cover to prevent splattering and retain moisture.

Materials to be avoided in microwave oven Utensils Remarks

Aluminum tray	May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle	May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils	Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties	May cause arcing and could cause a fire in the oven.
Paper bags	May cause a fire in the oven.
Plastic foam	Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.
Wood	Wood will dry out when used in the microwave oven and may split or crack.

SETTING UP YOUR OVEN

Names of Oven Parts and Accessories

Remove the oven and all materials from the carton and oven cavity. Your oven comes with the following accessories: Glass tray 1

Turntable ring assembly Instruction Manual

Installation

1. Select a level surface that provide enough open space for the intake and/or outlet vents.

A) Control panel

B) Turntable shaft

C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system

Shut off oven power if the door is opened during operation.

Turntable Installation

Countertop Installation

Remove all packing material and accessories. Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.

Glass tray

(3) Blocking the intake and/or outlet openings can damage the oven. (4) Place the oven as far away from

A minimum clearance of 3.0 inches (7.5cm) is required between the oven at any adjacent walls. One side must be open (1) Leave a minimum clearance of 12 inches (30cm) above the oven.

(2) Do not remove the legs from the bottom of the oven.

WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed near or over a he source, the oven could be damaged at the warranty would be void.

Operation Instructions

Order	Display	Microwave Power
1	P100	100%
2	P80	80%
3	P50	50%
4	P30	30%
5	P10	10%

3) Press " START " to start defrosting.

2) Turn " 🔍" to select the weight of food from 100 to 2000 g.

1) Press "WEIGHT DEFROST" once, and the oven will display "dEF1".

1. Defrost By Weight

3) Under the state of auto menu and weight defrost, cooking time cannot be increased

can increase 30 seconds cooking time.

2) In microwave cooking or time defrost state, each press of "QUICK START"

30 seconds, each added press will increase 30 seconds cooking time up to 95 minutes.

1) In waiting state, Press " QUICK START " to start cooking with 100% power for

1. Speedy Cooking

If the clock be set(12-hour system), LED will display the current time.

(4) When the kitchen time is reached, clock indicator will go out. The buzzer will ring 5 times.

(3) Press " START " to confirm setting.

(2) Turn " " to enter the timer time.(the maximum cooking time is 95 minutes).

(1) Press " KITCHEN TIMER ", LED will display 0:00, clock indicator will be lighted.

1. Kitchen Timer

4) Turn " " to adjust the minute figures, the input time should be within 0–59.

2) Turn " " to adjust the hour figures, the input time should be within 0--23.

When the microwave oven is electrified, the LED will display "0:00", buzzer will ring once. 1) Press "CLOCK", the hour figures will flash.

1. Clock Setting

"Microwave" Pad instructions

1. Defrost By Time
   1) Press "TIME DEFROST" once, and the oven will display "dEF2".

2) Turn " [IMAGE] to select the defrost time.

3) Press " START " to start defrosting.The defrost power is P30. It cannot change.

7. Auto Reheat1) Press " AUTO REHEAT " once, and the LED will display "200".

2) Press " AUTO REHEAT " more times or turn " [IMAGE] " to choose the weight of food,and "400" or "600" g will be selected.

3) Press " START " to start cooking.

8. Auto Menu1) Press "AUTO MENU" once,then press "AUTO MENU"several times or turn " [IMAGE] "to choose the menu, and "A-1" to "A-8" will display, which means pizza, chickenpieces,meat, vegetable, fish, pasta, soup and potato.

2) Press " START " to confirm.

3) Turn " [IMAGE] " to choose the default weight as the menu chart.

4) Press " START " to start cooking.

Example: If you want to use "Auto Menu" to cook fish for 350g.1) Press "AUTO MENU" once,then turn " [IMAGE] " till "A-5" display.

2) Press " START " to confirm.

3) Turn " [IMAGE] " to select the weight of fish till "350" display.

4) Press " START " to start cooking.

c. Turn " " to adjust the cooking time till the oven displays "10:00". d. Please do not press " START " to start cooking.Do as following.

11. MEMORY FUNCTION

(1) Press "MEMORY" to choose memory 1-3 procedure. The LED will display 1,2,3. (2) If the procedure has been set, press "START" to use it. If not, continue to set

the procedure. Only one or two stages can be set.

(3) After finishing the setting, press "MEMORY" to save the procedure and turn back to the

waiting states.If press " START",it can save and operate the setting.

Example: to set the following procedure as the second memory, that is memory 2.

to cook the food with 80% microwave power for 15 minutes.

The steps are as follow:

a. In waiting states, press "MEMORY" twice, stop pressing until the screen displays "2".

b. Press "MICROWAVE" twice until "P80" displays.

c. Press "START" to confirm the power.

d. Turn " " to input the cooking time of 15 minutes.

e. Press "MEMORY" to save the setting. Buzzer sounds once then turn back to waiting

states. If you press "START" after the above step, the procedure will be

saved as the memory 2 and operated.

f. If the electricity is not cut off, the procedure will be saved all the time. If it is, the procedure

need to reset.

g. If you want to run the saved procedure, in waiting states, press "MEMORY" twice, screen

displays "2", then press "START" to run.

1. Inquiring Function

(1) In states of microwave, grill and combination cooking, press "MICROWAVE", the

current power will be displayed for 3 seconds. After 3 seconds, the oven will turn back

to the former state;

(2) In cooking state, press "CLOCK" to inquire the time and the time will display

for 3 seconds.

(3) In preset state, press "PRE-SET" to inquire the preset time, and the preset time

will display for 3 seconds.

1. Lock-out Function for Children

Lock: In waiting state, press " STOP/CLEAR " for 3 seconds, there will be a long beep

denoting entering the children-lock state and the locked indicator will display if the

time has been set, otherwise, the LED will display " [::]".

Lock quitting: In locked state, press " STOP/CLEAR " for 3 seconds, there will be a long

"beep" denoting that the lock is released.

3) Press "PRE-SET", the hour figures will flash.

4) Turn " 🔥 " to adjust the hour figures, the input time should be within 0–23.

5) Press "PRE-SET", the minute figures will flash.

6) Turn " " to adjust the minute figures, the input time should be within 0--59.

7) Press " START " to finish setting. If the door is closed, buzzer will ring

twice when the time arrives, then cooking will start automatically.

1. Multi-section cooking

At most 2 sections can be set for cooking. In multi-section cooking, if one section is

defrosting, then defrosting shall be placed in the first section.

Example: If you want to defrost food for 5 minutes and then cook with 80% microwave

power for 7 minutes, operate it as the following:

1) Press "TIME DEFROST" once, and the oven will display "dEF2".

2) Turn " 🔍" to select the defrost time till "5:00" display.

D/2 = 1/2

3) Press " MICROWAVE " once, the screen display "P100".

4) Press " MICROWAVE " once again or turn " " to choose 80% microwave power.

5) Press " START " to confirm, and the screen displays "P 80".

6) Turn " 🔍 " to adjust the cooking time till the oven displays "7:00".

7) Press " START " to start cooking, and buzzer will sound once for the

first section, defrosting time counts down; buzzer will sound once again entering

the second cooking. when cooking finish, buzzer sounds five times.

Service and Spares

In the event of your appliance requiring service, or if you wish to purchase spare parts, contact your local Kelvinator Service Centre by telephoning:

0860 234 481/2/3 (South African Customers) [phone] (International Customers)

Help us to help you

Please determine your type of enquiry before writing or telephoning. When you contact us we need to know: - Your name - Telephone Number

- Physical Address where appliance is located

- Model and Serial Number of the appliance - Clear and concise details of the fault

Customer Care

For general enquiries or information regarding Kelvinator appliances contact:

Customer Care Department

Kelvinator

P.O. Box 3657

2000

South African Customers: 0860 234 481

[phone]

E-mail:

[e-mail]

Trouble shooting

Normal
Microwave oven interfering TV reception	Radio and TV reception may be interfered when microwave oven operating. It is similar to the interference of small electrical appliances, like mixer, vacuum cleaner, and.electric fan.It is normal.
Dim oven light	In low power microwave cooking, oven light may become dim. It is normal.
Steam accumulating on door, hot air out of vents	In cooking, steam may come out of food. Most will get out from vents. But some may accumulate on cool place like oven door. It is normal.
Oven started accidentally with no food in.	It is forbidden to run the unit without any food inside.It is very dangerous.

Trouble	Possible Cause	Remedy
Oven can not be started.	(1) Power cord not plugged in tightly.	Unplug. Then plug again after 10 seconds.
	(2) Fuse blowing or circuit breaker works.	Replace fuse or reset circuit breaker (repaired by professional personnel of our company)
	(3) Trouble with outlet.	Test outlet with other electrical appliances.
Oven does not heat.	(4) Door not closed well.	Close door well.
Glass turntable makes noise when microwave oven operates	(5) Dirty roller rest and oven bottom.	Refer to "Maintenance of Microwave" to clean dirty parts.

According to Waste of Electrical and Electronic Equipment

(WEEE) directive, WEEE should be separately collected and

treated. If at any time in future you need to dispose of this

product please do NOT dispose of this product with household waste. Please send this product to WEEE collecting points

where available.
