BHCP65422BCH - Autres appareils de cuisine BEKO - Free user manual and instructions

Product Type	Built-in Gas Hob
Brand	Beko
Model	BHCP65422BCH
Number of Burners	4
Burner Types	Standard, Rapid, Triple Ring (Wok)
Width	65 cm
Depth	51 cm
Height	4.5 cm
Weight	Approx. 8 kg
Power Supply	220-240 V ~ 50 Hz (ignition)
Gas Type	Natural Gas (G20) / LPG (G30/G31) convertible
Total Gas Consumption	Up to 10.5 kW
Ignition	Automatic electronic ignition
Safety Features	Flame failure safety device (thermocouple)
Control Type	Front-mounted knobs
Material	Stainless steel / Tempered glass
Cleaning	Removable pan supports and burner caps; wipe with damp cloth
Installation	Built-in; cut-out dimensions: 560 x 480 mm
Repairability Index	7.5 / 10 (estimated)
Warranty	2 years (standard)

Frequently Asked Questions - BHCP65422BCH BEKO

How do I ignite the burners?

Press and turn the corresponding knob to the maximum position (high flame symbol) while holding it down. The electronic ignition will spark automatically. Once the flame is lit, keep the knob pressed for a few seconds to activate the safety thermocouple, then release.

Can I use LPG (bottled gas) with this hob?

Yes, the hob is supplied with injectors for natural gas and LPG. You need to change the injectors according to the gas type. Refer to the installation manual for the correct procedure or contact a qualified technician.

How do I clean the hob?

First, ensure the hob is cool and all knobs are off. Remove pan supports and burner caps. Wash them with warm soapy water and dry thoroughly. Wipe the hob surface with a damp cloth and mild detergent. Do not use abrasive cleaners or scouring pads.

What should I do if a burner does not ignite?

Check if the gas supply is on. Ensure the burner cap and crown are correctly positioned. Clean the ignition electrode and burner holes with a soft brush. If problem persists, contact service.

The flame is uneven or yellow – what can I do?

Uneven or yellow flame indicates incomplete combustion. Clean the burner cap and slots thoroughly. Ensure the burner is properly seated. If using LPG, check that the correct injectors are installed. If issue continues, call a professional.

What are the recommended cut-out dimensions for installation?

For this 65 cm hob, the recommended cut-out size is 560 mm width x 480 mm depth. Ensure a minimum distance of 50 mm from the rear wall and 60 mm from side walls. Ventilation openings must be present.

Does the hob have a safety device?

Yes, each burner is equipped with a flame failure safety device (thermocouple). If the flame goes out, the gas supply is automatically cut off within seconds to prevent gas leakage.

Can the gas supply be converted from natural gas to LPG?

Yes, the hob can be converted by replacing the injectors. A conversion kit is usually included. Adjust the minimum gas flow setting according to the instructions. It is recommended to have this done by a qualified technician.

What should I do if the knob is stuck or hard to turn?

Do not force the knob. Check for any debris or grease under the knob. Remove the knob (pull it off) and clean the stem. If it still sticks, contact service for replacement.

Where can I find spare parts for this model?

Spare parts such as burner caps, injectors, and knobs can be ordered from Beko official service centers or authorized dealers. Use the model number BHCP65422BCH to ensure compatibility.
