Product Type	Active Subwoofer
Brand	Sonus Faber
Model	Arena S15
Dimensions (H x W x D)	420 x 420 x 450 mm
Weight	18 kg
Frequency Response	30 Hz - 250 Hz
Amplifier Power	300 W RMS, 600 W Peak
Amplifier Type	Class D
Driver	15-inch paper cone
Connectivity	L/R line inputs, LFE input
Controls	Volume, crossover frequency, phase switch, auto standby
Power Consumption	Standby < 0.5 W, Operating up to 600 W
Cabinet Finish	Wood veneer or black lacquer
Safety Features	Overcurrent protection, thermal shutdown
Maintenance	Wipe with a soft dry cloth; avoid liquids
Placement	Floor, near front speakers for optimal integration
Spare Parts	Contact an authorized Sonus Faber dealer
Repairability	Serviceable by qualified technicians; no user-serviceable parts inside

Frequently Asked Questions - Arena S15 Sonus Faber

How do I connect the Arena S15 subwoofer to my system?

Use the LFE input if your receiver has a dedicated subwoofer output. Alternatively, use the L/R line inputs with a stereo RCA cable if connecting to a stereo preamp.

What is the best placement for the subwoofer?

Place the subwoofer on the floor near the front speakers, away from walls to reduce boominess. Experiment with corner placement for more bass but possibly less accuracy.

What crossover frequency should I set?

Set the crossover frequency knob to match your main speakers' low-frequency limit, typically 80 Hz for most systems. Adjust higher if your satellite speakers are small.

How do I clean the subwoofer cabinet?

Wipe the cabinet with a soft dry cloth. Do not use any liquids, solvents, or abrasive cleaners. For stubborn dirt, slightly dampen the cloth with water.

Does the subwoofer have auto standby?

Yes, the Arena S15 features auto standby that activates after a period of inactivity to save power. It automatically wakes up when a signal is detected.

What should I do if the subwoofer does not turn on?

Check the power cable and ensure the outlet is live. Verify that the power switch on the back is on. If it still doesn't power, try a different outlet or contact support.

Can I use this subwoofer with bookshelf speakers?

Absolutely. The Arena S15 pairs well with bookshelf speakers like the Sonus Faber Lumina or Sonetto series. Set the crossover appropriately for seamless integration.

What does the phase switch do?

The phase switch (0° or 180°) adjusts the timing of the subwoofer's output relative to the main speakers. Use the setting that produces more bass at your listening position, typically 0°.

What are the dimensions and weight of the Arena S15?

Dimensions: 420 x 420 x 450 mm (HxWxD). Weight: 18 kg. Ensure your shelf or floor can support this weight.

What is the warranty period?

The standard warranty for Sonus Faber products is 2 years from the date of purchase. It covers manufacturing defects. Register your product online for extended support.

USER MANUAL Arena S15 Sonus Faber

1. General information 15
   1.1 Information for the user 15
   1.2 Warranty and after sales support 15

2. Safety information 16

3. Installation 17

3.1 Packaging contents 17

3.2 Unpacking 17

3.3 Assembly 18

3.4 Remove the loudspeaker 22

1. Maintenance and cleaning 23

2. Technical specifications 24

ENGLISH

1. GENERAL INFORMATION

1.1 - INFORMATION FOR THE USER

Dear Customer,

We would like to thank and congratulate you on choosing Arena loudspeakers for your audio/audio video system.

Since we want you to obtain the best possible listening result in full safety, please read this instruction manual carefully before installation.

Should you have any doubts or enquiries, please contact your sales point's technical staff, the official Sonus faber distributor in your country, or Sonus faber directly by writing to

[e-mail].

Finally, we highly suggest registering on-line with the website www.sonusfaber.com in order to keep up to date on all the latest news, initiatives and promotions offered by Sonus faber.

Enjoy your music!

1.2 - WARRANTY AND AFTER SALES SUPPORT

The loudspeakers are designed and manufactured according to the highest quality standards. Should however a fault or a malfunction occur, all Sonus faber products are covered by a standard warranty that covers material, technical and manufacturing defects and/or inconsistencies for two (2) years from the date of purchase by the original owner.

Please be aware that you can extend the warranty period by registering your product on https://www.sonusfaber.com/en/register-product/.

Check the complete Warranty Policy at www.sonusfaber.com/warranty-policy.

The following should also be kept in mind for your convenience:

- The warranty on the loudspeakers covers any manufacturing defects;

- Keep the receipt as proof of purchase to show to the retailer if necessary;

- Keep the loudspeakers' original packaging so that they can be transported without suffering damage if they need to be shipped to an authorized service center;

- The loudspeakers must be accompanied by a description of the malfunction or defect encountered.

The product warranty will be void under the following conditions:

- If the product has been disassembled or modified by persons other than a Sonus faber authorized service center;

- If the product has been used in a manner that is not consistent with the indications contained within this manual.

2. SAFETY INFORMATION

• This instruction manual must be read carefully and kept in an accessible location for any needs that may arise.
• Make sure that in-wall/in-ceiling fixing is suitably stable.
• Previously check that the capacity of the mounting surface is sufficient to support the weight of the loudspeaker/s.
• Avoid staying in close proximity to the loudspeakers while the audio system is operating at high volume. This can cause permanent damage to your hearing. Children must be kept at a safety distance of least 50 cm from the loudspeaker.
• The speakers generate an electromagnetic field that is harmless to humans and pets, but can compromise the proper functionality of electronic equipment, such as CRT monitors or TVs, when placed in close proximity. If this occurs, increase the equipment's distance from the loudspeakers.
• The technology underlying the speakers' functionality is based on the principles of electromagnetism, and the user should therefore avoid operating equipment that generates strong electromagnetic fields, as these could affect the loudspeaker's proper functionality.
• Do not connect the loudspeakers parallel to each other or directly to a constant voltage sound distribution system (100 V, 70.7 V or similar) without an adapter transformer. This could result in a serious system overload, with possible damage to the loudspeaker and/or the amplifier.
• Do not place audio cables and electrical power cables in close proximity to one another. An electromagnetic field is present in the vicinity of the power cables, which can cause an unpleasant humming noise. If this should occur, move the audio cables and electrical power cables away from each other.
• The connections must be made with the equipment turned off. Pay attention to the polarities of the terminals during connection.
• Connect the loudspeaker to a PS1 certified source pursuant to the IEC 62368-1 Standard.

3. INSTALLATION

3.1 - PACKAGING CONTENTS

• Speaker
• Frame
• Template for the hole
• Protective cover
  • Accessories box: fabric grids, screws, screw covers.

3.2 - UNPACKING

Respect the following general indications:

• It is advisable to open the packaging as close to the final location as possible.
• Use a proper tool to open the packaging. Do not insert the blade too deep to avoid damaging the contents.
• Keep all the packaging elements for any future transport operations.
• Do not wear any watches, bracelets, rings, etc., in order to avoid scratching the loudspeakers and their finishes. The same care must be taken in order to protect the loudspeakers from any metal elements present on the clothes you are wearing, such as zippers, buttons, belt clasps, rivets, etc.
• Check the content of the packaging. If one or more of the items is missing, notify the dealer where the product was purchased.
• Do not touch the drivers during the operation.

For the safe handling of the loudspeakers, it is strongly recommended to follow the instructions given in the table below:

Up to 44 lb A person
From 44 lb to 88 lb At least 2 people
From 88 lb to 132 lb At least 3 people
From 132 lb to 176 lb At least 4 people

Hold the loudspeaker securely with both hands in order to avoid dropping it.

The packaging materials can cause pollution. These materials must not be disposed of as domestic waste and must be brought to a waste collection and recycling center.

Do not leave the packaging materials within the reach of children! They could pose a risk of poisoning or suffocation if ingested.

If using a dedicated stand, do not use it with any speaker system other than the one for which it was designed. Improper use of the stand can result in damage or injury.

3.3 - ASSEMBLY
3.3.1 - MARK THE AREA TO BE CUT ON THE WALL USING THE TEMPLATE SUPPLIED

Two simple 3D rectangular panels with dashed outlines and internal lines, no text or symbols present.

18 19

Pay attention to the polarities of the terminals during connection. The connections must be made with the equipment turned off!

3.3.3 - INSERT THE FRAME IN THE DRILLED HOLE

Technical line drawing of a door frame with two views: one open and one closed, both without any text or symbols.

3.3.4 - PUSH THE METALLIC FINS INTO CONTACT WITH THE INTERNAL WALL

Pure architectural floor plan lines without any text, numbers, or symbols

Pure mechanical diagram showing a lever mechanism with no text or symbols

Remove the rubber bands
20 21

3.3.5 - SCREW THE FRAME

Pure architectural floor plan lines without any text, numbers, or symbols

Tighten the locking screws fully home without force, to prevent damage to the locking system!

Technical line drawing of a mechanical assembly with no visible text or symbols

3.3.6 - INSERT THE LOUDSPEAKER IN THE FRAME

Technical line drawing of a wall-mounted device with three circular components, shown from two different angles (no text or symbols)

21

3.3.7 - SCREW THE LOUDSPEAKER TO THE FRAME CLOSE WITH THE SCREW COVERS

Two simple line drawings of a cabinet with circular elements, no text or symbols present

3.4 - REMOVE THE LOUDSPEAKER
3.4.1 - UNSCREW THE LOUDSPEAKER FROM THE FRAME

Simple line drawing of a cabinet with two circular fixtures and a central knob (no text or symbols)

Technical line drawings of a mechanical component with internal circular features and two separate views showing positive charges (no text or symbols)

3.4.3 - UNSCREW THE FRAME AND ALIGN THE METAL FINS REMOVE THE FRAME FROM THE WALL

Technical line drawings of a double door frame with internal components and exterior panels (no text or symbols)

Perform the operation with the appliances off!

4. MAINTENANCE AND CLEANING

The loudspeakers do not require any particular maintenance operations, just general periodic cleaning.

It is recommended to use a soft brush to eliminate any dust that may have accumulated on the cabinet, the front panels, and the loudspeakers themselves, taking care not to damage the loudspeakers' delicate membranes.

It is recommended to use the supplied cloth and liquid to clean the metal and glass surfaces (where present). Do not use aggressive strong chemical products such as acetone, trichloroethylene, acids, abrasive agents, strong de-greasers, alcohol, lemon or wine. These measures will help you to keep your loudspeakers' working perfectly for years to come. Time will help improve the sound by breaking in the speakers' moving parts (membranes and suspensions), and the acoustic chamber will become accustomed to music being played the more it is used - much like what happens with acoustic string instruments!

1. TECHNICAL SPECIFICATIONS

	ARENA 30 ARENA 20 A	ARENA S15
Speaker type 4 way 3.5 way			Array Balanced Sub-Woofer
Low frequency transducer 2 x 8 in 2 x 8 in 2 x 8 in
Mid/High frequency transducer	2 x 6,25 in - 38 mm Dome Tw + 19 mm Super Tw	6,25 in - 25 mm Dome Tw -
Maximum recommended power	600 watts (Printing) 400 watts	(Printing) 400 watts (Printing)
Low-frequency cut-off (-6dB)	44.30 Hz 55 Hz 29 Hz
Low-frequency cut-off (-3dB)	-- 31,50 Hz
Frequency response (-6dB on-axis)	-- 29 Hz 180 Hz
Frequency Response (-3dB on-axis)	55.50 Hz 60 Hz 31.50 Hz	180 Hz
Max SPL 1 Meter	115 dB 112 dB -
Sensitivity 2.83 Vrms@1m	94.00 dB	92.00 dB	90.00 dB
Nominal Impedance	4 Ω	4 Ω	4 Ω
Minimal impedance 2.8 Ω	2.8 Ω	3.5 Ω
Crossover frequencies	200 Hz / 2k Hz / 10k Hz	160 Hz / 220 Hz / 3100 Hz	-
Enclosure type	Closed Box	Closed Box	Potentable Acoustical Load
Mounting Depth	162 mm - 6,3 in	144 mm - 5,6 in	202 mm - 7,9 in
Weight	58,7 kg - 129,4 lb	47,2 kg - 104 lb	38,7 kg - 95,3 lb
Depth	167 mm - 6,5 in	150 mm - 5,9 in	208 mm - 8,3 in
Width	321 mm - 12,6 in	321 mm - 12,6 in	432 mm - 17 in
Height	1.774 mm - 69,8 in	1.577 mm - 62 in	947 mm - 37,2 in

* see instruction's manual for more information.
