Product Type	Portable Bluetooth Speaker
Brand	Squeak
Model	BeatBoxer SQ1000
Dimensions (W x H x D)	200 x 80 x 80 mm
Weight	0.8 kg
Power Source	Built-in rechargeable lithium-ion battery
Battery Life	Up to 10 hours (at 50% volume)
Charging Time	Approximately 4 hours
Bluetooth Version	5.0
Wireless Range	Up to 10 meters (33 feet)
Water Resistance	IPX5 (splash-proof)
Output Power	20W RMS
Frequency Range	80 Hz - 20 kHz
Connectivity	Bluetooth, 3.5mm AUX input, Micro USB charging
Controls	Power, Volume +/-, Play/Pause, Next/Previous, Hands-free call
Additional Features	TWS pairing, LED indicator, Built-in microphone
Cleaning and Maintenance	Wipe with a soft, dry cloth. Do not use liquids or abrasives.
Safety Precautions	Keep away from water, heat, and magnets. Do not disassemble. Use only included cable.
Spare Parts / Repairability	Battery is built-in and not user-replaceable. Contact Squeak support for service.

Frequently Asked Questions - BeatBoxer SQ1000 Squeak

How do I pair my BeatBoxer SQ1000 with a Bluetooth device?

Turn on the speaker by pressing the power button. The LED will flash blue indicating pairing mode. On your device, enable Bluetooth and select 'BeatBoxer SQ1000' from the list. If prompted, enter '0000' as the PIN. Once connected, the LED will turn solid blue.

How long does the battery last on a full charge?

The speaker provides up to 10 hours of playback time at 50% volume. Actual battery life may vary depending on volume level and audio content.

Is the BeatBoxer SQ1000 waterproof?

The speaker has an IPX5 rating, meaning it is splash-proof and can withstand light rain or splashes. However, it should not be submerged in water.

Can I use the speaker while it is charging?

Yes, you can use the speaker while it is plugged in and charging. However, frequent use during charging may affect the battery lifespan over time.

How do I reset the speaker to factory settings?

To reset, press and hold the Power and Volume Up buttons simultaneously for 5 seconds. The LED will flash red briefly, and the speaker will power off. It will then be reset.

Can I connect two BeatBoxer SQ1000 speakers together?

Yes, the speaker supports TWS (True Wireless Stereo) pairing. Pair your phone with one speaker, then press the TWS button (if available) or follow the manual to link a second speaker for stereo sound.

What does the LED indicator mean?

- Flashing blue: Pairing mode
- Solid blue: Connected via Bluetooth
- Flashing red: Low battery
- Solid red: Charging
- Off: Fully charged or power off

How do I clean the speaker?

Use a soft, dry cloth to wipe the exterior. Do not use any liquids, sprays, or abrasive cleaners. Keep the charging port and openings free of dust.

Can I use the speaker as a speakerphone for calls?

Yes, the speaker has a built-in microphone for hands-free calling. When a call comes in, press the Play/Pause button to answer and again to hang up.

What if the speaker won't turn on?

First, charge the speaker for at least 30 minutes using the included cable. If it still does not turn on, try a reset (see above). If the issue persists, contact Squeak customer support.

USER MANUAL BeatBoxer SQ1000 Squeak

We would like to thank you for purchasing a portable Bluetooth speaker with karaoke function. This is a device that is sure to make your time spent with family and friends more enjoyable, providing hours of great fun. Please read this manual before using the device.

FRONT PANEL

TOP PANEL

DESCRIPTION

1. Microphone input (MIC)
2. AUX-in input
3. USB port
4. MicroSD card slot
5. USB-C charger socket (DC 5V, 1A) and charging LED
6. Power switch (ON - lighting off, LIGHT - lighting on)
7. Volume control
8. ECHO (Karaoke) effect level.
9. Microphone input volume level

1. Equalizer effect selection*
2. REC button
3. MODE button
4. Next track
5. Pause/play
6. Previous song
7. Display/Status
8. Wireless remote control signal receiver wireless
9. Antenna
   *Only available in SD/USB mode.

WIRELESS REMOTE CONTROL

1. Standby mode on/off
   2 Repeat* mode.
2. Mode selection: Bluetooth/AUX-in/FM/USB/SD
   4 Previous song/radio station
3. Next song/radio station
4. Graphic equalizer*: normal/bass/pop/rock/jazz.
5. Play/Pause
6. Quieter
7. Louder
8. Mute
9. Numeric keypad
10. Stop

To charge the device, use the included USB->USB-C cable. If you wish to charge the device from the mains, we recommend using a DC 5V, 1A charger. It is forbidden to use chargers with a voltage higher than 5V. This will void the warranty and damage to the speaker.

Be sure to charge the speaker to full before using it for the first time. Important!

You can use the device normally while it is charging, but we recommend that you run 3 full charging cycles at the beginning of use to form the built-in battery.

To start the device, slide the POWER button to the "ON" position. To turn on and activate the set's lighting, slide it to the "LIGHT" position. You can use the remote control to put the set into standby mode (standby).

CHANGING THE OPERATING MODE OF THE DEVICE

To switch modes, use the MODE button and select from the options: Bluetooth/SD/USB/FM radio/AUX-in. The current mode is displayed on the control panel.

MUSIC VOLUME CONTROL

To adjust the overall volume, use the main knob. To add an echo effect to the microphone signal, use the echo knob. On the other hand, the microphone input level can be adjusted using the mic/vol knob.

KARAOKE

To get started, plug the microphone into the microphone jack, then adjust the volume levels according to your preference. For a better sound effect, you can increase the microphone level via the mic/vol knob and the echo level via the echo knob.

BLUETOOTH MODE

Make sure the device is in Bluetooth mode, then use your smartphone to search for available Bluetooth devices. When the name „SQ1000“ appears in the list, click that item to pair the device (the pairing process does not require a password). Once the pairing process is successful, you can start the music player on your smartphone and control the volume with the VOL-/VOL+ buttons, use the PLAY/PAUSE button to play or pause play-back, and the PREVIOUS/NEXT TRACK buttons to change the current track.

MICROSD/USB CARD MODE

In this mode, in addition to the standard playback control using the PLAY/PAUSE, VOL-/VOL+ and PREVIOUS/NEXT TRACK buttons, you can use the repeat mode. To change the repeat mode, press the REPEAT button (repeat once ONE and repeat all ALL options are available). Also, using the EQ button, you can select one of the available graphic equalizer settings. In this mode, it is also possible to use the numeric keypad buttons to manually enter the song number.

Note: The device automatically remembers the last track played and resumes playback at the same point. To start playback from the beginning, manually enter the number of the first track, i.e. "0001", and wait a moment, or press the STOP button and then PLAY.

FM RADIO MODE

Unfold antenna buttons, then press and hold the PLAY button of the unit for 2 sec to start the automatic FM station tuning function. When the process is complete, the first station in the list will be played. Use the PEVIOUS/NEXT TRACK buttons on the unit or remote control to change the radio station. Press PLAY button once to mute/cancel mute.

AUX-IN MODE

AUX-in mode only allows you to use the volume control.

RECORDING MODE

In recording mode, while the device is in SD/USB mode, press the press the REC button to pause music playback and start recording the sound from the microphone. To stop recording, press the REC button again. The device will automatically play the recorded sequence. The recording function requires a microSD card or USB flash drive to be installed in advance.

It is worth remembering that the device has an active microphone input, which can lead to a slight hum even at the minimum volume setting.

In addition, the device has a built-in rechargeable battery, so be sure to charge it regularly at least once a week.

SMARTPHONE HOLDER

Top-mounted smartphone holder/stand addition to the speaker is a practical solution that allows you to seamlessly play music from your phone without having to hold it in your hand.

EN - Environmental guidance

The device is marked with the symbol of a crossed-out waste container, in accordance with the European Directive 2012/19/EC on waste electronic and electrical equipment. Products marked with this symbol should not be discarded with other household waste after use. The user is obliged to dispose of used electrical and electronic equipment by delivering it to a designated point where it will be recycled.

The collection of such waste at designated locations and its proper processing contribute to the conservation of natural resources. Proper recycling of waste electrical and electronic equipment has beneficial effects on human health and the environment. To find out where and how to safely dispose of waste electrical and electronic equipment, the user should contact the relevant local government authority, waste collection point or the point of sale where the equipment was purchased.

*The battery-powered speaker work duration test was conducted under home conditions. The speaker was connected to a Xiaomi phone with Android system via Bluetooth. The distance between the phone and the speaker was 5 meters. The volume was set halfway through the range.

MBM Group s.c. declares that this device complies with the essential requirements and relevant provisions of Directive RED 2014/53/EU of the European Parliament and of the Council of 16 April 2014 on the harmonization of the laws of the Member States relating to the making available on the market of radio equipment and repealing Directive 1999/5/EC. The full text of the Declaration of Conformity is available at www.squeak.pl

Thank you for purchasing our device! We would like to inform you that we are constantly developing our products - both their specifications and design. For this reason, there may be slight changes in subsequent versions of the product.

If you need technical support or want more information about our products, please visit our website www.squeak.pl, where you will find answers to many of your questions.
