E2TS1-100W - Toaster ELECTROLUX - Free user manual and instructions

Product Type	Toaster
Brand	Electrolux
Model	E2TS1-100W
Number of Slots	2
Functions	Defrost, Reheat, Cancel (Stop)
Color Control	7 positions (1 to 7)
Extra Features	Toasting rack for irregular bread, dust-proof cover, automatic pop-up, crumb tray
Cleaning	Removable crumb tray, wipe exterior with soft dry cloth
Safety	Grounded plug, automatic shut-off
Power Cord	Retractable under base storage

Frequently Asked Questions - E2TS1-100W ELECTROLUX

How do I clean the toaster?

Disconnect the power supply before cleaning. Wipe the outside with a soft dry cloth after the toaster cools down. Pull out the crumb tray from the bottom using the crumb tray handle and empty it. If used frequently, clean accumulated bread crumbs at least once a week. Make sure the crumb tray is completely closed before using again.

What should I do if bread gets stuck in the toaster?

First, unplug the toaster from the electrical outlet. Never attempt to remove bread jammed in the slots without unplugging first. Be careful not to damage the internal mechanism or heating elements when removing the bread.

Can I toast frozen bread?

Yes. Place the frozen bread in the slots, set the color control knob to your desired level, press the carriage handle down, then press the DEFROST button. The indicator will illuminate and the toaster will toast to your chosen color.

How do I use the reheat function?

To reheat cold toasted bread, press the carriage handle down, then press the REHEAT button. The indicator will illuminate. The toasting time is fixed; once the time is over, the carriage handle will automatically spring up.

What is the color control knob for?

The color control knob has 7 positions (1 to 7) to select the desired toasting level. Position 1 is the lightest (white) and position 7 is the darkest (puce). For a golden color, set it to position 4. Note that toasting one side may be darker than toasting double bread at the same level, and continuous toasting may darken subsequent slices.

Can I toast irregularly shaped bread or bagels?

Yes. The toaster has a toasting rack for irregular bread or round bread. Only one piece at a time. Press down the rack control handle to uplift the rack, then place the bread on the rack. When not in use, lift the rack control handle to reset the rack.

Why does the toaster emit an odor the first time I use it?

This is normal. Manufacturing residues or oil on the heating elements may cause an odor during first use. It will disappear after several uses. We recommend operating the toaster once without bread before first use.

Is the toaster safe to use near children?

The toaster can be used by children aged 8 years and above if supervised. Keep the appliance and its cord out of reach of children under 8. Children should not clean or maintain the toaster unless they are older than 8 and supervised.

What should I do if the toaster starts smoking?

Immediately press the STOP (Cancel) button to interrupt toasting. Unplug the toaster and allow it to cool down. Check for any food debris or excessive crumbs that may be burning. Clean the crumb tray.

How do I store the toaster when not in use?

Use the dust-proof cover to protect the top. The power cord can be wound under the bottom of the toaster for storage. Always unplug when not in use.

USER MANUAL E2TS1-100W ELECTROLUX

Exterior view of a modern electric toaster with two side grilles (no text or symbols visible)

EN INSTRUCTION BOOK

ID Buku Panduan

INSTRUCTION MANUAL

Read this booklet thoroughly before using and save it for future reference

COMPONENTS

A. Rack control handle
B. Crumb tray
C. Crumb tray handle
D. Dust-proof cover
E. Toasting rack

F. Carriage handle
G. Defrost
H. Reheat
I. Cancel (Stop)
J. Color control Knob

IMPORTANT SAFEGUARD

When using electrical appliance. Basic safety precautions should always be followed including the following:

1. Read all instruction.
2. Make sure that your outlet voltage corresponds to the voltage stated on the rating label of the toaster.
3. Do not touch hot surface. Use handles or knobs only.
4. To protect against electrical shock, do not immerse cord, plug, or any part of the toaster in water or other liquid.

5. Close supervision is necessary when it is used by or near children.

6. Unplug unit from outlet when not in use and before cleaning.

7. Do not operate any appliance with a damaged cord or plug, or in abnormal state. If its main cord is damaged, it must be replaced by the manufacturer's the nearest service agent or a qualified person.

8. Do not let the cord hang over edge of table or counter, or touch hot surface.

9. Do not place on or near a hot gas or electric burner, or in a heated oven.

10. Do not use the appliance for other than its intended use.

11. Oversize food, metal foil packages or utensils must not be inserted in the toaster as they may cause fire or electric shock.

12. Bread may burn, therefore toasters must not be used near or below curtains and other combustible materials, they must be watched.

13. The use of accessory attachments not recommended by the appliance manufacturer may cause injuries.

14. Don't attempt to dislodge food when toaster is in operation.

15. Be sure to take the bread out carefully after toasting after toasting to avoid injuries.

16. This appliance has been incorporated with a grounded plug. Please ensure the wall outlet in your house is well earthed.

17. The appliance is not intended to be operated by means of an external timer or separate remote-control system.

18. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.

19. Keep the appliance and its cord out of reach of children less than 8 years.

20. Warning: if toast of small bread slices less than 85mm length, you must pay attention to the potential risk of burning when taking out the slices.

21. Don't use the appliance outdoors.

22. This appliance is intended to be used in household and similar applications such as:

23. staff kitchen areas in shops, offices and other working environments;

24. farm houses;
25. by clients in hotels, motels and other residential type environments;

26. bed and breakfast type environments.

27. Save these instructions.

FOR THE FIRST USE

As there is manufacturing residue or oil remained in the toaster or heat element, it usually emits the odor for the first use. It is normal and will not occur after several times use. Before toasting the first slice of bread it is strongly suggested to operate the appliance following below instructions, except without bread.

OPERATION:

1. Put bread slice into the bread slot, it can be inserted two slices at most every time. Only the regular slice can be placed into the bread slot. The irregular bread can only be toasted on the toasting rack and only one piece every time. When toasting on the toasting rack, press down the rack control handle to make the toasting rack uplift, then put the bread on the toasting rack. Lift the rack control handle to reset the rack when do not use.

Note: Make sure the crumb tray is completely positioned in place before using.

1. Plug the power cord into the outlet.
2. Set color control knob to your desired color. There is 7-position level, the lowest is white and the highest is puce. The bread slice can be toasted to golden color at the position of "4".

Note: 1) Toasting color for one side is darker than that for double bread at the same level.

2) If toasted continuously, toasting color for the latter bread is darker than the color of previous cycle at the same level.

1. Press carriage handle down vertically until it is positioned in place, the indicator of STOP will be illuminated, and toasting begins. Once the bread has been toasted to the preset color, the carriage handle will be automatically sprung up, and you can remove the bread readily.

Note: The carriage handle can only be latched when the appliance connects to the power supply.

1. During the toasted process, you may observe the toasting color. If it is satisfactory, you may interrupt the toasting process by pressing the STOP button at any time.
2. If the bread has been taken out from refrigerator. Set color control knob to your desired color. Press carriage handle down vertically until it is positioned in place, then press DEFROST button and the indicator of DEFROST will be illuminated. In this mode it will be toasted to your desired color.
3. If you want to reheat the cold toasted bread. Press carriage handle down vertically until it is positioned in place, then press REHEAT button and the indicator of REHEAT will be illuminated. In this mode, toasting time is fixed, so long as time is running over, the carriage handle will automatically spring up and end up the reheating process.

CAUTION:

1. Remove all protective wrapping prior to toasting.
2. If toaster starts to smoke, press STOP button to stop toasting immediately.
3. Avoid toasting the food with extremely runny ingredients such as butter.
4. Never attempt to remove bread jammed in the slots without unplugging the toaster from the electrical outlet first. Be sure not to damage the internal mechanism or heating elements when removing bread.
5. The bread slot is only applicable for toasting regular bread slice. Like the irregular bread or round bread, you can toast it on the toasting rack.
6. There is a dust-proof cover, when not use, you can put it on the top of the toaster to prevent dust.

CLEANING AND MAINTENANCE:

1. Disconnect the power supply before cleaning.
2. Wipe the outside with soft dry cloth after toaster cools down, never use metal polish.
3. Pull out the crumb tray on the bottom of toaster by crumb tray handle and empty it. If toaster is used frequently, accumulated bread crumbs should remove at least once a week. Make sure the crumb tray is completely closed before using the toaster again.
4. When not use or storage, the power cord may be wound under the bottom of toaster.

ENVIRONMENT FRIENDLY DISPOSAL

You can help protect the environment!

Please remember to respect the local regulations: hand in the non-working electrical equipments to an appropriate waste disposal center.
