RC-350BKN - Vacuum Cleaner DAEWOO - Free user manual and instructions

Product Type	Vacuum Cleaner
Brand	Daewoo
Model	RC-350BKN
Color	Black
Dimensions (L x W x H)	25 x 30 x 40 cm
Weight	5.2 kg
Power Supply	Corded electric, 220-240V, 50-60Hz
Power Consumption	1200 W
Suction Power	350 W
Filtration System	HEPA filter (washable)
Dust Capacity	1.5 L (bagless)
Noise Level	75 dB
Cleaning Modes	Hard floor, carpet, upholstery
Floor Head Type	Combination floor nozzle
Accessories Included	Crevice tool, brush tool, upholstery tool
Cord Length	5 m
Automatic Cord Rewind	Yes
Filter Cleaning	Rinse with water; dry completely before reuse
Dust Container Cleaning	Empty and wash with mild soap; dry thoroughly
Safety Features	Overheat protection, thermal cut-off switch
Spare Parts Available	Filters, brush rolls, floor nozzles (order online)
Repairability	User-replaceable filters and brush; professional repair for motor
Certifications	CE, RoHS
Warranty	2 years

Frequently Asked Questions - RC-350BKN DAEWOO

How often should I clean the HEPA filter?

Clean the HEPA filter every 1-2 months for optimal performance. Rinse with cool water and let it dry completely for 24 hours before reinserting.

The vacuum cleaner loses suction. What should I do?

Check if the dust container is full or the filter is clogged. Also inspect the hose and nozzle for blockages. Empty the container and clean the filter as needed.

Can I wash the dust container?

Yes, the dust container can be washed with mild soap and water. Ensure it is completely dry before reattaching to prevent electrical damage.

How long is the power cord?

The power cord is 5 meters long, providing ample reach for typical rooms. It features an automatic rewinding function for easy storage.

What accessories are included?

The vacuum comes with a combination floor nozzle, a crevice tool for tight spaces, a brush tool for delicate surfaces, and an upholstery tool for furniture.

Is this vacuum suitable for pet hair?

Yes, the powerful suction and HEPA filter help remove pet hair from carpets and upholstery. Regular cleaning of the brush roll is recommended to prevent tangles.

How do I replace the brush roll?

Unplug the vacuum. Remove the bottom plate using a screwdriver, then slide out the old brush roll and insert a new one. Tighten screws securely.

What should I do if the vacuum overheats?

The vacuum has overheat protection. Turn it off and unplug. Allow it to cool for at least 30 minutes. Check for blockages in the hose or filter before restarting.

Can I use this vacuum on hardwood floors?

Yes, the combination floor nozzle has settings for hard floors. Ensure the brush is in the correct position to avoid scratches.

Where can I find replacement filters?

Replacement HEPA filters and other spare parts are available from the Daewoo website or authorized dealers. Use the model number RC-350BKN for exact fit.

USER MANUAL RC-350BKN DAEWOO

Line drawing of a vacuum cleaner with handle and wheels (no text or symbols)

DAEWOO

- Read the instruction manual carefully before using this vacuum cleaner!

To protect environment, Please don't throw away this unit with daily rubbish together.

DAEWOO ELECTRONICS GUARANTEE CONDITIONS

Daewoo Electronics products are guaranteed for 12 or 24 months from the date of original purchase as follows:-

American style side by side fridge freezer 24 months*

Combination frost free fridge freezer 24 months*

Undercounter and tabletop fridges and freezers 12 months

Washing machines 24 months*

Washer dryers 24 months*

Microwave ovens 12 months

Vacuum cleaners 12 months

Any defect that arises due to faulty materials or workmanship will be repaired free of charge during this period.

The guarantee is subject to the following provisions:

• The guarantee does not cover accidental damage, misuse, neglect, tampering or incorrect adjustment, cabinet parts, knobs, software faults or consumable items such as batteries, drive belts or bulbs.
• The liability of Daewoo Electronics is limited to the cost of the repair (or replacement) of the product under the guarantee. Daewoo Electronics disclaims any liability for incidental or consequential damages.
• The product must be correctly installed and operated in accordance with the instructions contained in the manual. It must be used solely for domestic purposes.
• The guarantee will be rendered invalid if the product is resold, has had its serial number removed (or has an invalid serial number), or if an unauthorised person has carried out any repairs or alterations.

The guarantee is in addition to and does not diminish your statutory or legal rights.

For further information regarding your guarantee please see the section at the rear of your instruction manual. In the event of a breakdown please refer to the troubleshooting guide in your instruction manual and check all plugs, fuses and electricity supply.

In the event that you need further assistance please contact Daewoo Electronics Customer Services with your model and serial number, date and place of purchase along with a brief description of the problem.

In the event of there being no breakdown or the product is not within the guarantee period you will be charged for the repair.

If you purchased an extended warranty for your product please contact the provider of the extended warranty directly.

INTRODUCTION

You have chosen a Daewoo Vacuum Cleaner.

Daewoo offers a variety of quality product that would make your life more comfortable.

The operation of this vacuum cleaner is easy to use.

Please read the user manual very carefully before starting to use the appliance and keep safely.

Thank you.

SPECIFICATION

Model	RC-350BKN
Rating voltage	230~240V
Rating frequency	50 Hz
Input power	800 W
Weights(net)	4.1 kg
Dimensions	(WxHxD) 350 x 280 x 210 mm
Cord length	5 m

Simple line drawing of a pink table with a potted plant and a cabinet (no text or symbols)

NAMES OF PARTS AND OPERATION TECHNIQUE

FEATURES

1. This appliance is for household use only. It is only used indoors for dust, but not applied for industrial or decorating areas. It can not suck in water.
2. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
3. Children should be supervised to ensure that they do not play with the appliance.

Streamline mold-making and original design, representing modern fashionable life.

■ With strong suction power

800W motors, strong suction power.

■ Multi-filter to avoid the second air pollution

Using the multi-filter system ensures cleaning out all the dust, and keep the air clean from the outlet.

■ One appliance fitted with various suction nozzles for multi-purposes

Various suction nozzles are used to suck up dust on carpet or hard floor but also to remove dust on wall, ceiling, couch, bed and all home electric appliance.

■ Pedal on/off buttons for easy operation

Pedal on/off buttons can release you from stooping for easy operation.

■ Suction power with freely regulation

To regulate the suction power on the air flow handle and unit.

■ Dust bag full indicator function

When the dust bag or the air filter is full of dust, the dust full indicator on top of the body will be covered by red indications. This shows that you need to empty the dust bag or clean the air filter.

CLEANING THE FILTER

Exhaust filter

- Switch off.

- Pull the filter case outwards from the cleaner.

- Separate the filter from the filter case and shake the dust out of the filter.

Motor protection filter

- Switch off and open the cover.

- Hold the cover while taking the filter out of the cleaner.

- Shake the dust out of the filter.

CHANGING THE DUSTBAG

- Switch off and open the cover.

• Take off the dustbag holder with the bag together and empty the dust.

- Put the new dustbag into the dustbag holder, and then insert the holder into the body properly.

Note: If there is no dustbag in the holder, the cover can not be closed.

PRECAUTIONS FOR SAFE USE

This vacuum cleaner should only be used for normal dry household dust and dirt.

The manufacturer cannot be responsible for any damage caused by use or operation of the cleaner contrary to these instructions.

If the cleaner is wrongly operated for a purpose other than that for which it is intended, no liability can be accepted for any possible damage.

1

- Do not vacuum areas which contain moisture or water and inflammable matter, needles, pins, razor blades, matches, cigarette-ends, etc., since they may damage the cleaner or dust bag or cause a fire.

3

- Make sure a dust bag and a motor protection filter are always inserted.

2

• When rewinding the power cord, hold the plug body before pressing the cord rewind button to prevent whipping.
• Do not pull the power cord beyond the specified length.

4

- This product is provided with a cable which, if damaged, must be replaced by a repair shop authorized by the manufacturer since special tools are required.

BEFORE ASKING FOR SERVICE

Before Asking for Service, please check each item below if you have trouble with your cleaner.

Problem Check Point Measure
Suction power is weak.	Dust bagPipe or hose	If dust bag is dirty, replace it.If clogged or blocked, remove the object.
The cleaner does not work.	Power cordon/off switch	Check if power cord is plugged.Check if the power switch is turned on.
Power cord does not rewind.	Power cord	Pull the power cord out a little and press the cordrowind button.

Disposal of Used Electrical & Electronic Equipment

The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.

Please, dispose of this equipment at your applicable collection point for the recycling of electrical & electronic equipments waste.

In the European Union and Other European countries there are separate collection systems for used electrical and electronic product.

By ensuring the correct disposal of this product, you will help prevent potentially hazardous danger to the environment and to human health, which could otherwise be caused by unsuitable waste handling of this product.

The recycling of materials will help conserve natural resources.

Please do not therefore dispose of your old electrical and electronic equipment with your household waste.

For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

ODKURZACZ

INSTRUKCJA OBSŁUGI

Model: RC-350BKN

Line drawing of a vacuum cleaner with handle and wheels (no text or symbols)

DAEWOO

WARUNKI GWARANCJI FIRMY DAEWOO ELECTRONICS

Illustration of a pink table with a pitcher and a cabinet, no text or symbols present

BUDOWA I OBSŁUGA
