Product Type	Security Camera
Brand	Joblotron
Model	JK-16
Dimensions (W x H x D)	7.5 x 7.5 x 15 cm
Weight	0.35 kg
Power Supply	DC 12V / 1A
Power Consumption	Max 8W
Image Sensor	1/2.9" CMOS
Resolution	1920 x 1080 (Full HD)
Frame Rate	Up to 30 fps
Night Vision	IR LEDs, up to 20m range
Lens	3.6mm fixed
Field of View	80° diagonal
Weatherproof Rating	IP66
Operating Temperature	-20°C to 50°C
Video Output	CVBS (BNC) or AHD
Mount Type	Wall / Ceiling bracket included
Main Functions	Motion detection, day/night switching, privacy zone
Maintenance and Cleaning	Clean lens with microfiber cloth; avoid solvents
Safety Instructions	Install as per manual; use certified power adapter
Spare Parts and Repairability	Contact authorized service center for repairs
In the Box	Camera, mounting kit, power adapter, manual

Frequently Asked Questions - JK-16 Jablotron

How do I connect the JK-16 camera to my DVR?

Use a BNC cable to connect the camera's video output to the DVR's video input. Ensure the power adapter is connected. If using AHD, make sure the DVR supports AHD format.

Can I use this camera outdoors?

Yes, the JK-16 has an IP66 weatherproof rating, making it suitable for outdoor use in rain and dust.

How far can the night vision see?

The IR LEDs provide clear night vision up to 20 meters in complete darkness.

What power supply does the JK-16 require?

It requires a DC 12V 1A power adapter. Use the included adapter or a compatible one.

Does the camera support Wi-Fi?

No, the JK-16 is a wired camera. It uses a BNC or AHD connection, not Wi-Fi.

Can I adjust the camera angle after mounting?

Yes, the camera has a 3-axis adjustment mechanism for precise positioning.

How do I clean the camera lens?

Gently wipe the lens with a soft, dry microfiber cloth. Do not use alcohol or abrasive cleaners.

What is the warranty period for the JK-16?

Joblotron offers a 1-year limited warranty against manufacturing defects. Check your purchase for details.

Can I use a longer BNC cable?

Yes, but the maximum recommended length for reliable video signal is 300 meters (for RG59 cable). Use a signal booster if longer.

Is the camera compatible with my existing security system?

The JK-16 outputs analog video (CVBS or AHD). It should work with most DVRs that accept BNC inputs and support AHD or CVBS.

USER MANUAL JK-16 Jablotron

Installation instructions - only Jablotron distributor certified installers should install this kit. Detailed manuals for all included components can be found on the enclosed CD or on the Jablotron website www.jablotron.com

1. Kit contents

a) Install the control panel - see the drilling template on the last page of this manual.

Install and connect the backup battery to the control panel

Connect the AC power to the control panel

The Green LED should flash in the control panel

Connect the keypad's batteries (pull out the red tape to activate batteries). P will be indicated on the keypad

(programming mode). If E is indicated, there is no communication with the control

- If T is indicated, there is no communication with the control panel.

- Enter F0 6060 to re-enter P mode if you accidentally exit it

by pushing the N key

To save the keypad batteries, close its cover.

[Non-Text]

[Non-Text]

[Non-Text]

control panel.

2. Before installation

Decide upon suitable locations for all of the devices. The

wireless keypad should be within 20m of the control panel.

There should be power and a telephone line available for the

JK-16 PROFI 1/4 MGK24401

Control panel drilling template
JK-16 PROFI 4/4 MGK24401
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
[Non-Text]
1
40
K24
MGI
4 N
1/4
DFI
PRO
6 F
K-1

11. Specifications

Power	230 VAC, max 0.1 A, supervised, class II
Power supply	A type (EN 50131-6)
Backup battery	12 V, 2.26 Ah, normal life time 5 years
Backup power output	13VDC, the max. permanent current is 0.4 or 1A for max. 15 min (1 cycle per hour),
Consumption of the control panel is	30 mA; JA-60E 25 mA
Hard-wired inputs	4 input zones, selectable triggering:
Wireless zones	16 zones (2 detectors can be enrolled to each
Wireless controllers	max. 8 (JA-60F, RC-22, RC-44)
Access codes	master code and 14 user codes.
Wired outputs	Alarm relay dry contacts 1A/60V;
Programmable outputs	PgX , PgY connect to the GND max. 0,1 A
Siren output	12 V, 0.7 A
Working frequency*	433.92 MHz; digital hopping code; supervised communication
Comply with	EN 50131-1, EN 50131-6
Security grade	2 (low to medium risk)
Environmental class	II indoor – general (-10 to 40oC)
Safety	EN 60950-1
EMC	ETS 300683
Radio characteristics	ETSI EN 300220
Can be operated according to	ERC REC 70-03

10. Keypad operation

Entry	Function
User code	Arming / Disarming (Setting\Unsetting)
F1 / [IMAGE]	Arming without a code
F2 / [IMAGE]	Partial arming
F3 / [IMAGE]	Door lock opening
F4	Memory reading
F5	New master code (example: F5 1234 2789 2789)
F6	User codes setting (example: F6 1234 03 3344)
F7 / [IMAGE]	Disarming under duress
F8	Appliance control (F81 = ON, F80 = OFF)
F0 M.code	User test mode (example F0 1234)
N	Escape & fault detail reading

JK-16 PROFI 3/4 MGK24401

The wireless outdoor siren (JA-63A) enrolls after it is covered up while in enrollment mode.

To enroll the control panel to UC receivers enter 299 on the keypad while in P mode

Check individual device manuals for more details

*Enrollment mode will also start after shorting the reset pins in the control panel while it is in P mode.

6. Detector and controller testing

a) The system should be in P mode (if not enter F0 6060) b) Trigger detectors – their addresses (1=door and 2=PIR) should

be indicated (if the PIR detector does not react, re-enter test mode by opening and closing its cover)

c) Press button 🔒 on the RC-4x remote control – c2 will be indicated

7. To measure the strength of the radio signal

a) While in P mode, press 1 and then using 7 scroll to position 1 b) Press 8 to start measuring

c) Activate the door detector to view its signal strength d) Using the 1 key scroll to the next position (2 PIR) and

check its signal strength (if the PIR detector does not react, reenter its test mode by opening and closing its cover).

e) Repeat step d) to check all enrolled items. The wireless keypad

(c1) signal is indicated after you trigger its tamper. The remote control (c2) is indicated after you press it's 📄 button.

f) Change the location of an item if its signal is lower than 2 g) Return to P mode by pressing the N key

8. Programming the system

a) The system should be in P mode (if not enter F0 6060) b) Using the following sequences you can program:

Function	Sequence	Comments
Your installer code*	5 xxxx xxxx	6060 factory default xxxx new code
Exit delay	20x	3=30sec factory def.
Entrance delay	21x	3=30 sec factory def.
Alarm duration	22x	4=4min factory def.
Time & date	4 hh mm DD MM YY

- Must be changed

9. Finishing the installation

a) Fill in the information on the sticker label and attach it inside the keypad cover.

b) Switch the system to standby (by pressing the N key)

c) Instruct the user on how to operate the system

RC-44

Source or mode

Source of mode

If you install additional detectors (max. 32), you have to enroll them. The system should be in P mode (if not enter F0 6060): a) Press 1 to enter enrollment mode* b) The next free detector position will be displayed on the keypad. c) Install batteries into all new detectors step by step to enroll them (system will automatically offer the next free position) d) To scroll through sensor positions, press 1 (up) or 7 (down) e) To enroll a second detector to an occupied position press 5 before you install the detector's batteries f) To exit enrollment mode press the N key The wireless keypad (JA-63F) enrolls after you install its battery while in enrollment mode. The remote control (RC-4x) enrolls after you press and hold both 🔒 and 🔺 buttons while in enrollment mode.

4. Detector and accessory installation

a) Install the JA-60N magnetic detector onto the door (antenna pointing up or down)

b) Install the JA-60P PIR motion detector

c) Select Instant or Delay reactions via the DIP switches inside the detectors.

d) Connect the detector's batteries (pull out the red tape to activate the batteries).

e) Attach the keypad to the desired location

f) Plug the UC-260 wireless siren into a power socket

g) Test the wireless doorbell button and install it.

1. Enrollment of additional accessories

If you install additional detectors (max. 32), you have to enroll

In your install additional detectors (Main 62), you have to them. The system should be in P mode (if not enter F0 6060):

a) Press 1 to enter enrollment mode*

b) The next free detector position will be displayed on the keypad.

c) Install batteries into all new detectors step by step to enroll

them (system will automatically offer the next free position)

d) To scroll through sensor positions, press 1 (up) or 7 (down)

e) To enroll a second detector to an occupied position press 5 before you install the detector's batteries

f) To exit enrollment mode press the N key

The wireless keypad (JA-63F) enrolls after you install its

battery while in enrollment mode.

The remote control (RC-4x) enrolls after you press and hold both and buttons while in enrollment mode.

JK-16 PROFI 2/4 MGK24401
