| Product Type | 8x8 HDMI Matrix Switcher |
| Brand | VIZIO |
| Model | SV200M-0808 |
| Dimensions (W x D x H) | 430 x 200 x 44 mm (1U rackmount) |
| Weight | 2.7 kg |
| Power Input | AC 100-240V, 50/60Hz |
| Power Consumption | 30W (max) |
| Video Inputs | 8x HDMI Type A |
| Video Outputs | 8x HDMI Type A |
| Maximum Resolution | 4K@60Hz (4:4:4) |
| HDCP Support | HDCP 2.2 |
| Control Methods | Front panel buttons, IR remote, RS-232, TCP/IP |
| LED Indicators | Power, input selection per output |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 20% to 90% (non-condensing) |
| Maintenance | Clean with a soft, dry cloth. Do not use liquid cleaners. |
| Safety | Ensure proper ventilation. Do not block vents. Avoid exposure to moisture. |
| Spare Parts & Repairability | Contact VIZIO customer service for authorized repair. |
Frequently Asked Questions - SV200M-0808 VIZIO
How do I connect input sources to the SV200M-0808?
Connect your HDMI sources (e.g., Blu-ray players, game consoles) to the 8 HDMI input ports on the rear panel. Use high-speed HDMI cables for best performance.
How do I switch which input is displayed on a specific output?
Press the input selection button on the front panel corresponding to the desired output port, then use the arrow keys to select the input source. Alternatively, use the IR remote or web interface.
What maximum resolution does the matrix support?
The SV200M-0808 supports 4K@60Hz (4:4:4) resolution, as well as lower resolutions like 1080p and 720p.
Does it support HDCP?
Yes, it supports HDCP 2.2 for protected content such as Blu-ray discs and streaming services.
How can I control the matrix remotely?
You can control it via RS-232, TCP/IP, or IR remote. For IP control, connect to your network and use the provided web interface or telnet commands.
The LED indicators are not lit. What should I do?
Check that the power cable is securely connected and the power outlet is working. If the problem persists, the device may need service. Contact VIZIO customer support.
Can I cascade multiple units for more inputs/outputs?
Yes, you can cascade units by connecting an output of one matrix to an input of another. However, this may introduce slight delay. For larger systems, consider a dedicated matrix expansion solution.
How do I update the firmware?
Visit the VIZIO support website and download the latest firmware for the SV200M-0808. Use the USB port (if available) or the IP interface to perform the update. Follow the included instructions.
What is the warranty period for this product?
The VIZIO SV200M-0808 comes with a 1-year limited warranty. Register your product on the VIZIO website to activate warranty coverage.
How do I clean and maintain the device?
Use a soft, dry cloth to clean the exterior. Avoid using any liquid cleaners or sprays. Ensure proper ventilation by keeping vents clear of dust.
