IM-9055 - Waffle Maker Imarflex - Free user manual and instructions

Product Type	Waffle Maker
Brand	Imarflex
Model	IM-9055
Rated Voltage	230V AC, 60Hz
Power Consumption	750 watts
Non-Stick Coating	Teflex™ Crystalline
Indicator Lights	Red (power on), Green (ready/cooking done)
Usage	Pour batter into upper hole, close lid, cook until green light turns on
Cleaning Method	Wipe non-stick plate with damp cloth or paper towel
Water Immersion	Do not immerse in water
Abrasive Materials	Do not use to avoid scratches
Maintenance	Only by qualified technician from Authorized Imarflex Service Center
Cord Safety	Do not allow cord to touch hot surface; loop loosely after use
Child Safety	Close supervision required when used by or near children
Plug Type	Standard convenience outlet (230V)
Initial Use	Wipe plate with damp cloth; apply oil for best results
Batter Capacity	Fill up to the hole edge
Filling Options	Add jelly, jam, or other fillings before closing lid

Frequently Asked Questions - IM-9055 Imarflex

How do I use the Imarflex IM-9055 Waffle Maker?

First, wipe the non-stick plate with a damp cloth. For best results, apply a little oil. Plug in the unit; the red light turns on. Wait until the green light turns off, indicating it's preheated. Fully open the lid, pour batter up to the hole edge, add fillings if desired (e.g., jelly, jam), then close the lid. The green light will turn on when cooking is complete. Unplug after use.

How do I clean the waffle maker?

Unplug the unit and allow it to cool completely. Wipe the non-stick plate with a paper towel or soft cloth. Clean the body with a damp cloth. Do not use abrasive materials or immerse in water.

Can I immerse the waffle maker in water?

No, never immerse the unit in water to protect against electric shock. Only wipe with a damp cloth.

What should I do if the cord is damaged?

Do not use the appliance. The cord must be replaced before use; contact an authorized Imarflex service center for repair.

What do the red and green lights indicate?

The red light turns on when the unit is plugged in and heating. The green light turns off when the unit is preheated and ready for batter. The green light turns on again when the cooking cycle is complete.

Can I use the waffle maker for other purposes?

No, this appliance is intended only for making waffles/pancakes. Do not use it for other purposes.

Can I add fillings like jam or jelly?

Yes, after pouring the batter, you can add fillings such as jelly, jam, or other spreads before closing the lid.

Is the non-stick coating durable?

Yes, the waffle maker features Teflex™ Crystalline non-stick coating, but avoid using abrasive materials to prevent scratches.

Who should perform repairs?

Any maintenance other than cleaning should be performed by a qualified technician from an Authorized Imarflex Service Center.

How should I store the waffle maker after use?

Unplug the unit, allow it to cool, clean as directed, and loop the cord loosely. Store in a dry place away from heat sources.

USER MANUAL IM-9055 Imarflex

IM-9055

Close-up of three round food items on a dark plate, garnished with cream and a cherry (no visible text or symbols)

SPECIFICATION

MODEL NO. : IM-9055

RATED VOLTAGE : 230 Va.C./60HZ

POWER CONSUMPTION : 750 watts

IMPORTANT SAFEGUARDS

1. Read all instructions carefully.
2. Before using the pancake maker check if the voltage indicated in this unit corresponds with the convenience outlet (230 Va.C.).
3. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should be replaced before using.
4. Do not allow cord to touch hot surface of the unit. Loop cord loosely after use.
5. Do not place on or near gas stove, electric burner or in a heated oven.
6. Avoid touching the none-stick plate while cooking is in progress.
7. To protect against electric shock, do not immerse the unit in water.
8. Close supervision is necessary when any appliance is used by or near children.
9. Do not use this pancake maker other than intended use.
10. Maintenance other than cleaning should be performed by a qualified technician from an Authorized Imarflex Service Center.

HOW TO USE

1. For initial use wipe the non-stick plate of the pancake maker with damp cloth. For best result, wipe the non-stick plates with oil it can add aroma to the pancake.
2. Plug into the convenience outlet. The red light will turn ON.
3. Close the pancake maker and prepare the pancake mixture while the unit is heating.
4. When the pancake maker is ready the green light will turn OFF.
5. Fully open the pancake maker, pour the mixture up to the hole edge. If desired put filling such as jelly, jam, etc and close the lid.
6. The green light will turn ON when cooking is done.
7. Unplug when finished.

CLEANING AND MAINTENANCE

1. Unplug and wait for the unit to cool off before cleaning.
2. Wipe the non-stick coated plate with paper towels or soft cloth.
3. Wipe the body of the unit with damp cloth,
4. Do not use abrasive materials to avoid scratches.
