| Product Type | Secure KVM Switch |
| Brand | iPGARD |
| Model | SDPN-4D-P |
| Number of Ports | 4 |
| Supported Resolutions | 1920 x 1200, 4K (3840 x 2160) at 60 Hz |
| Dimensions (L x W x H) | 20.0 x 12.0 x 4.4 cm |
| Weight | 1.5 kg |
| Power Supply | External adapter, 100-240 VAC, 50/60 Hz |
| Power Consumption | 10 W (max) |
| Operating Temperature | 0 to 40°C |
| Storage Temperature | -20 to 60°C |
| Humidity | 0 to 80% non-condensing |
| Enclosure Material | Steel |
| Security Features | Tamper-evident seals, secure firmware, keyboard/mouse emulation |
| Compliance | FIPS 140-2, Common Criteria (target) |
| Interface Type | USB HID, DVI-I (dual-link), 3.5mm audio |
| EDID Learning | Yes, automatic |
| Maintenance | Wipe with dry cloth; no internal user-serviceable parts |
| Spare Parts | Power adapter, mounting brackets available |
| Reparability | Repairs by authorized service center only |
Frequently Asked Questions - SDPN-4D-P iPGARD
How do I connect multiple computers to the SDPN-4D-P?
Connect each computer's DVI video, USB, and audio to the corresponding ports on the KVM. Then use the front panel button or hotkey to switch between sources.
Does the SDPN-4D-P support 4K resolution?
Yes, it supports up to 4K (3840x2160) at 60 Hz on all ports, provided the connected computers and cables support that resolution.
Is the SDPN-4D-P compatible with USB 3.0?
The KVM uses USB 2.0 for keyboard/mouse emulation. For USB 3.0 peripherals, use a separate USB hub or a KVM with USB 3.0 support.
How do I switch between computers?
You can switch using the front panel push buttons, keyboard hotkeys (e.g., Scroll Lock twice), or via RS-232 serial control (if supported).
What security features does it offer?
The SDPN-4D-P includes tamper-evident seals, secure firmware with anti-tamper protection, and keyboard/mouse emulation to prevent data leakage between ports.
Can I use the KVM with audio peripherals?
Yes, the KVM has 3.5mm audio jacks for microphone and speaker pass-through. Audio is switched with the selected computer.
Does it require external power?
Yes, it comes with an external power adapter (100-240 VAC). The KVM does not draw power from USB ports.
How do I clean the device?
Use a soft, dry cloth to wipe the exterior. Do not use liquids or chemicals. Avoid cleaning ports.
What cables are included?
Typically, the package includes a power adapter and USB/DVI combo cables for each computer. Check the manual for exact contents.
Is the KVM hot-pluggable?
Yes, you can connect or disconnect computers while the KVM is powered on. However, avoid switching to a disconnected port to prevent display issues.
