IAHN40 - Headphones iLive - Free user manual and instructions

Product Type	Over-ear headphones
Brand	iLive
Model	IAHN40
Driver Size	40 mm
Frequency Response	20 Hz – 20 kHz
Impedance	32 ohms
Design	Adjustable headband, padded ear cups
Weight	Approximately 200 g
Dimensions (folded)	160 x 180 x 70 mm
Power Source	Rechargeable lithium-ion battery
Battery Life	Up to 12 hours playtime
Charging	Micro-USB cable (included)
Connectivity	Bluetooth 5.0, 3.5 mm aux input
Controls	Volume, track skip, play/pause, power on/off
Microphone	Built-in microphone for hands-free calls
Noise Cancellation	Passive noise isolation
Care and Cleaning	Wipe with a soft, dry cloth; avoid moisture
Safety	Do not use at high volume for extended periods
Spare Parts and Repairability	Contact iLive support for spare ear pads and cables
General Information	Includes headphones, charging cable, audio cable, manual

Frequently Asked Questions - IAHN40 iLive

How do I pair the iLive IAHN40 headphones via Bluetooth?

Turn on the headphones and activate Bluetooth on your device. The headphones will enter pairing mode automatically. Select "iLive IAHN40" from the list of available devices. If prompted, enter 0000 as the PIN.

What is the battery life of the iLive IAHN40?

The battery lasts up to 12 hours on a full charge, depending on volume level and usage.

Can I use the headphones while charging?

Yes, you can use the headphones in wired mode (via the included 3.5 mm audio cable) while charging. Bluetooth usage during charging may be limited.

How do I clean the iLive IAHN40 headphones?

Use a soft, dry cloth to wipe the ear cups and headband. Do not use liquids or abrasive cleaners. Remove ear pads gently if deep cleaning is needed.

Do the headphones have noise cancellation?

The iLive IAHN40 offers passive noise isolation from the over-ear design, but does not feature active noise cancellation (ANC).

What cables are included in the box?

The package includes a Micro-USB charging cable and a 3.5 mm audio cable for wired connections.

How do I reset the iLive IAHN40 headphones?

To reset, hold the power button for 10 seconds until the LED flashes rapidly, then release. The headphones will restart and enter pairing mode.

Are the ear pads replaceable?

Yes, the ear pads can be replaced. Contact iLive customer support to order spare parts.

Why is the audio cutting out or distorted?

Ensure the headphones are within range (10 meters for Bluetooth). Low battery can cause distortion. Reset the headphones if the issue persists.

Can I use the headphones with my TV?

Yes, if your TV has Bluetooth or a 3.5 mm audio output. For Bluetooth, pair as you would with any other device. For wired, connect the audio cable to the TV’s headphone jack.

USER MANUAL IAHN40 iLive

• Bluetooth 5.0
• Bluetooth Wireless: range - 33 ft.
  • Built-in microphone
  • Aux in (3.5mm audio input)
• Folding adjustable headband
• On-ear controls
  • Voice prompts announce headphone operations

• Built-in rechargeable lithium ion battery: life

- approx. 8 hrs at 50% volume + ANC on

- Micro-USB port for battery recharge

Includes

• 3.5mm audio cable
• Micro-USB to USB charging cable

Power/Play / Pause / Speakerphone

Press and hold to power ON or OFF Press to play or pause audio. Press to answer incoming phone call.

Volume/Skip

Press to adjust volume.

Press and hold to skip tracks.

Active Noise Canceling

Press and hold to turn active noise canceling ON/OFF

Aux In

Battery Charging

Initial charge time is approximately 3 hours. Charge fully before use. The low battery indicator will flash, a voice prompt will announce "low battery," then the unit will automatically power OFF.

1. Using a Micro-USB to USB cable (included), connect to the USB port of a powered on computer or USB power adaptor (not included) to charge the unit.

Diagram showing a laptop connected to an ear with a USB cable, no text or symbols present

STATUS	INDICATOR
Power On	Flashing blue light
Charging	Solid red light
Charging Complete	Light OFF
Pairing	Flashing red / blue light
Pairing Complete	Flashing blue light

Pairing Bluetooth & Playing Audio

After initial pairing to a Bluetooth device, the headphones will stay paired unless unpaired manually by the user, or erased due to a reset of the device. If your device should become unpaired or you find it is unable to connect, repeat these steps.

1. Power ON the headphones.. The headphones defaults to Bluetooth Mode and is ready to pair automatically. When pairing, remain within 3 feet of the Bluetooth device.
2. Using the controls on your Bluetooth device, select IAHN40 in the Bluetooth Settings to pair. If need be, refer to the user's manual for your specific device for more information.
3. When successfully paired, a voice will announce, "Bluetooth is connected." Your Bluetooth device will now be heard through the headphones.
4. Use the controls on the connected Bluetooth device to select and play audio. Use the headphone controls or the connected Bluetooth device to play, pause, skip and adjust the volume level. Note: To pair to a different Bluetooth device, turn off Bluetooth on the currently connected device first.

Aux In

Aux In mode will function even if the headphones are not powered on. To conserve battery power, keep them powered off when using Aux In.

Requires a 3.5mm audio cable (included).

1. Connect a 3.5mm audio cable to the Aux In on the headphones and the audio output on an audio device.
2. Use the controls on the connected device to select and play audio.

Line drawing of a smartphone connected to a pair of headphones (no text or symbols)

Active Noise Canceling

The Active Noise Canceling feature will electronically mute background noise. It can be used with the Bluetooth or Aux In modes to enhance the quality of any music or audio that is playing through the headphones.

Active Noise Canceling mode will function even if the headphones are not powered ON.

1. To activate noise cancelling, press and hold the M button. The Indicator LED will turn green.
2. To deactivate noise cancelling, press and hold the M button again. The green LED will turn off.

Previously Connected Devices

• The headphones can remember multiple Bluetooth devices and will always try to re-connect to the last device used.
• To re-connect to a different device, turn off Bluetooth on unwanted devices, then access the Bluetooth settings menu on the device you wish to use and select IAHN40.

Customer Support

Customer Service: 1-888-999-4215 | Email Support: [e-mail] | Email Parts: [e-mail]

For Warranty Information and the most up-to-date version of this User's Guide, go to www.iLiveElectronics.com

To download this User's Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit the support section at: www.iLiveElectronics.com

Copyright © 2020 Digital Products International (DPI, Inc.).

All other trademarks appearing herein are the property of their respective owners.

Specifications are subject to change without notice.

FCC Warnings

WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Additional Warnings

• WARNING: To prevent fire or shock hazards, do not expose this unit to rain or moisture.
• WARNING : Where the mains plug or appliance coupler is used as the disconnect device, such disconnect device shall remain readily operable.
• Lithium batteries, like all rechargeable batteries, are recyclable and should be recycled or disposed of according to state and local guidelines. They should never be disposed of in normal household waste, and they should never be incinerated, as they might explode. Contact your local government for disposal or recycling practices in your area.
• This product meets and complies with all Federal regulations.
• To avoid hearing damage, make sure that the volume on your music player is turned down before connecting your headphones. After placing headphones in/on your ears, gradually turn up the volume until you reach a comfortable listening level.

WARNING : This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. This product meets and complies with required Federal product guidelines.
