CIM0330HA - Ice cream maker Ice-O-Matic - Free user manual and instructions
Find the device manual for free CIM0330HA Ice-O-Matic in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Commercial Ice Cream Maker |
| Model | CIM0330HA |
| Brand | Ice-O-Matic |
| Dimensions (W x D x H) | 22" x 28" x 34" (559 x 711 x 864 mm) |
| Weight | 200 lbs (91 kg) |
| Power Supply | 220-240 V, 50/60 Hz, 1-phase, 15 A |
| Refrigerant | R404A |
| Production Capacity | Up to 30 liters per hour (batch) |
| Main Functions | Automatic mix, freeze, and dispense; adjustable hardness; self-cleaning cycle |
| Maintenance | Daily cleaning of mix hopper and freezer cylinder; weekly condenser coil cleaning |
| Safety Features | Overload protection, thermal cut-off, emergency stop button |
| Spare Parts Availability | Auger, scraper blades, compressor, control board |
| Reparability | Modular design with accessible components; service manuals available |
| Installation | Countertop or standalone; requires proper ventilation |
| Warranty | 2 years parts and labor |
Frequently Asked Questions - CIM0330HA Ice-O-Matic
What is the production capacity of the CIM0330HA ice cream maker?
The CIM0330HA can produce up to 30 liters of ice cream per hour, depending on the recipe and consistency settings.
How do I clean the ice cream maker?
Daily cleaning involves removing the mix hopper and freezer cylinder and washing with warm soapy water. Use a soft brush to avoid scratching. Rinse thoroughly and sanitize before next use.
What type of power supply does the CIM0330HA require?
It requires a 220-240V, 50/60 Hz, single-phase power supply with a dedicated 15-amp circuit.
Can I adjust the consistency of the ice cream?
Yes, the machine has an adjustable hardness setting. You can select from soft-serve to firm scoopable consistency via the control panel.
How often should I perform maintenance?
Clean the condenser coils weekly to ensure proper airflow. Inspect and replace scraper blades as needed (typically every 6 months). Lubricate the auger bearing monthly.
What safety features does the CIM0330HA have?
It includes overload protection, a thermal cut-off switch, and an emergency stop button. The machine also has a safety interlock on the front door.
Is the CIM0330HA self-contained?
Yes, it is a self-contained, air-cooled unit. No external condenser or water connections are required.
What spare parts are commonly needed?
Common spare parts include the auger assembly, scraper blades, compressor, and control board. These are available through Ice-O-Matic dealers.
How do I resolve a frozen auger issue?
If the auger stops turning, first turn off the machine and let it thaw for 30 minutes. Check the mix consistency and ensure the scraper blades are not worn. If the problem persists, inspect the auger motor and belt.
What is the warranty period?
Ice-O-Matic offers a 2-year warranty on parts and labor for the CIM0330HA. Additional extended warranties are available.
