Product Type	Digital Audio Player (MP3 Player)
Brand	GPX
Model	MW151P
Power Source	1 x AAA battery (not included)
Audio Formats Supported	MP3, WMA (non-DRM), WAV
Playback Modes	Normal, Intro, Repeat One, Repeat All, Shuffle, Shuffle All
Equalizer Presets	Normal, Pop, Rock, Classic, Jazz, Bass
Connectivity	Mini-USB 2.0 High Speed
Headphone Output	Stereo headphone jack (3.5mm)
Included Accessories	Stereo earbuds, USB cable
System Requirements	Windows XP/Vista/7, Mac OS 10.4/10.5/10.6
File Transfer Method	Drag and drop (USB mass storage)
Controls	Play/Pause, Volume, Skip/Search, Mode
Lanyard Connection	Built-in loop
FCC Compliance	Class B digital device (Part 15)

Frequently Asked Questions - MW151P GPX

How do I power on the GPX MW151P?

Press and hold the Play/Pause button until the player turns on.

What battery does the MW151P use?

The MW151P requires one AAA battery (not included). Do not use rechargeable batteries unless specified.

How do I transfer music to the MW151P?

Connect the player to a computer using the included USB cable. It will appear as a removable drive. Drag and drop audio files into the drive. Remember to eject the drive before disconnecting.

What audio formats are supported?

The MW151P supports MP3, WMA (non-DRM), and WAV files.

How do I change the equalizer?

Press the Mode button to cycle through equalizer presets: Normal, Pop, Rock, Classic, Jazz, and Bass.

How do I change the play mode (repeat, shuffle)?

Press and hold the Mode button to switch between play modes: Normal, Intro, Repeat One, Repeat All, Shuffle, and Shuffle All.

Why is my computer not recognizing the MW151P?

Ensure the player is powered on (battery installed) and connected via the USB cable. Try a different USB port or cable. The player should appear as a removable disk.

How do I skip to the next or previous track?

Press the Skip/Search button to skip to the next track. Press it twice or press and hold to search within a track.

Can I use rechargeable batteries?

The manual specifies only standard 1.5V AAA batteries. Rechargeable batteries (1.2V) may not provide adequate power and could cause issues.

What should I do if the player freezes or stops responding?

Remove the battery and reinsert it after a few seconds. This will reset the player. If the problem persists, try a fresh battery.

USER MANUAL MW151P GPX

WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Digital Audio Player

Features

• Digital audio: MP3, WMA (non-DRM), WAV
- Mini-USB port, 2.0 high speed
- Stereo headphone jack
• DC battery power: requires 1 AAA battery (not included)

Included

• One set of stereo earbuds
- USB cable

System Requirements

Loading music onto the digital audio player requires a computer with a USB port and one of the following operating systems.

Windows XP, Windows Vista, Windows 7 Mac OS 10.4, 10.5, or 10.6

Power

• DC battery power: requires 1 AAA battery (not included)

Introduction

Skip/Search

Press or press and hold to skip or search through tracks.

Pure technical diagram of a mechanical component with no text, numbers, or symbols

Play/Pause

Press and hold to power the player off or on. Press to play or pause the audio player.

Mode

Press to switch between Normal, Pop, Rock, Classic, Jazz, and Bass. Press and hold to switch between Normal, Intro, Repeat One, Repeat All, Shuffle, and Shuffle All.

Volume

Press to adjust the volume.

Lanyard Connection

Battery Compartment

DC battery power: requires 1

AAA battery (not included)

Company Information

International Support

To download this User's Guide in English, Spanish, or French, visit the support section at www.gpx.com.

1. Connect the digital audio player to a computer using the MINI-USB connection and a USB cable (included).

2. Once connected, the unit will show up on the connected computer as if it were a connected USB thumb drive, external hard drive, or memory card.

3. Drag and drop the desired audio files into the unit's drive location on the connected computer.

4. After the files are loaded onto the unit, right-click on the drive and eject it from the computer, then disconnect the USB cable.

Playing Music

1. Press and hold the Play/Pause button to power on the digital audio player
2. Press the PLAY/PAUSE button to begin playing music from your digital audio player.

Press the Mode button to switch between Normal, Pop, Rock, Classic, Jazz, and Bass. Press and hold to switch between Normal, Intro, Repeat One, Repeat All, Shuffle, and Suf All.

MW151

Digital Audio Player

For the most up-to-date version of this

User's Guide, go to www.gpx.com
