USER MANUAL IFC-812SL Imarflex

White electric fan with a clear blue cover and 'imcorflex' logo, mounted on a stand (no text or symbols on the fan itself)

IFC-812SL

1. Read all instructions carefully.

2. Before using the unit, check if the voltage indicated corresponds with the convenience outlet (230Va.c.).

3. Do not use a two-way socket with another appliance.

4. Do not use any appliance with a damaged cord or plug. If the cord is damaged it should be replaced with the same type and size or bring the unit to the nearest authorized service center.

5. Do not place the unit near gas stove, electric stove or in a heated oven.

6. Put the unit on flat stable surface; keep it away from the edge of counter to avoid accident.

7. Children should be supervised to ensure that they do not play with the appliance.

8. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliances by a person responsible for their safety.

9. To protect against electric shock, do not immerse the unit in water or any other liquid.

10. Do not use the unit for outdoor use.

11. This unit must only be used for room ventilation. Do not use in bathrooms.

12. Do not insert your hands or any object into the Fan Guard.

13. Never touch the unit with wet hands.

14. Do not use the plug to stop or start the operation of the unit, use the switch button.

15. Be sure that the fan is switched off from the convenient outlet before removing the guard or before cleaning.

16. Avoid water spillage into the socket, connector, cord and alike.

17. Do not use this unit other than its intended use.

18. For household use only; not intended for any business purposes.

19. Save this instruction for future reference.

FEATURES AND FUNCTIONS

Air circulator acts as a flow-straightener and further assists in focusing the outward stream of air into tight cyclone airflow.

- Summer: The cyclone air hits a wall across the room roughly halfway to decrease the room temperature.

- Rainy: This forces the hot air of the ceiling and mixes it with the cooler air resulting in an even room temperature.

SPEED CONTROL:

SYMBOL FUNCTION

OFF Power OFF

1 Low Speed
2 Medium Speed

3 High Speed

1 Low Speed and Automatic Oscillating
2 Medium Speed and Automatic Oscillating
3 High Speed and Automatic Oscillating

HOW TO USE:

1. Please make sure the Speed Control Knob is in "OFF" position.
2. Plug the unit into the convenience outlet (230Va.c.).
3. SPEED ADJUSTMENT – the speed can be adjusted by turning the control knob to the desired setting:

OFF	Fan is switched off
1	Low range speed of the fan (weak air flow)
2	Medium range speed of the fan (medium air flow)
3	High range speed of the fan (strong air flow)
1	Low Speed and Automatic Oscillating
2	Medium Speed and Automatic Oscillating
3	High Speed and Automatic Oscillating

1. OSCILLATION - 60° Oscillating Function
2. Turn off the unit every after use.

CLEANING AND MAINTENANCE:

1. Always unplug the unit from the convenience outlet before disassembling the unit.
2. Unscrew and remove the Front Fan Guard.
3. Clean the Rear Fan Guard with damp cloth. Wash the Front Fan Guard and Fan Blade with soap and water then rinse thoroughly.
4. Use vacuum or soft brush to clean the dust on the motor.
5. After cleaning return the Front Fan Guard and tighten the screws.
6. Wipe the Base with damp cloth.
7. Do not immerse the unit in water or other liquids.

REMINDER: Please do not forget to fill up and send the warranty card with a copy of the receipt to our email address [e-mail]

Distributed By: Sabretech Technology Inc.

103-113 Sen Gil Puyat Ave. Pasay

Made in China
