Product Type	4K HDBaseT Scaling Receiver
Brand	Black Box
Model	VX-1003-RX
Video Input	1x RJ-45 HDBaseT
Video Output	1x HDMI
Max Input Resolution	3840x2160 @ 30 Hz (UHD)
Max Output Resolution	3840x2160 @ 30 Hz; also supports 1080p, 720p, WUXGA, WXGA
Max Transmission Distance	Up to 328 ft (100 m) via CAT6 at 4K @ 30 Hz
HDCP Compliance	HDCP 2.2
Power Supply	Input: 100-240 VAC, 50/60 Hz, 1.5A; Output: 12 VDC, 3.0 A
Power over HDBaseT	Yes (PoH), receiver can power transmitter via 48 VDC
Operating Temperature	32 to 118°F (0 to 65°C)
Storage Temperature	-4 to 140°F (-20 to +70°C)
Humidity	10 to 90% non-condensing
Dimensions (H x W x D)	0.98 x 9.21 x 5.67 in (2.5 x 23.4 x 14.4 cm)
Weight	Approx. 1.5 lb (0.68 kg)
Included Accessories	12 VDC power supply with US/EU/UK/AU plugs, 2x IR sensors, 2x mounting brackets
Control Interfaces	RS-232 (3-pin Phoenix), Ethernet (2x RJ-45), IR (3.5 mm), USB for firmware
Audio Output	1x RCA S/PDIF, 1x 3-pin Phoenix (balanced analog audio)
Scaling Support	4K to 1080p downscaling and aspect ratio conversion
Mounting	Surface mount with included brackets
Regulatory Compliance	FCC Part 15 Class A, IC
Cable Requirements	CAT5e or higher, IEEE-568B termination

Frequently Asked Questions - VX-1003-RX Black Box

What is the maximum distance for 4K video transmission with the VX-1003-RX?

The maximum distance is 328 feet (100 meters) using a CAT6 cable at 4K @ 30 Hz. For 1080p @ 60 Hz, it can reach the same distance.

Does the VX-1003-RX support power over HDBaseT?

Yes, it supports Power over HDBaseT (PoH). The receiver can send 48 VDC power to the connected HDBaseT transmitter, eliminating the need for a separate power supply at the transmitter end.

What video resolutions can the scaling receiver output?

The receiver scales incoming video to 4K @ 30 Hz (3840x2160), 1080p @ 60 Hz, 720p @ 60 Hz, WUXGA (1920x1200), and WXGA (1280x800).

What control interfaces are available?

The unit supports RS-232 via a 3-pin Phoenix connector, Ethernet (2x RJ-45 for pass-through or control), IR input and output (3.5 mm), and USB for firmware updates.

Can I use the VX-1003-RX with a presentation switcher?

Yes, it is designed to work with Black Box presentation switchers like the AVSC-0401H. This combination allows multi-room AV switching with scaling for mixed display types.

What is included in the package?

The package includes the VX-1003-RX receiver, a 12 VDC power supply with interchangeable plugs (US, EU, UK, AU), two IR sensors, and two mounting brackets.

How do I clean and maintain the device?

Clean the enclosure with a dry cloth. Do not use liquids or aerosol cleaners. Ensure the unit is unplugged during cleaning and during lightning storms.

Is the VX-1003-RX HDCP compliant?

Yes, it is compliant with HDCP 2.2, allowing protected content from Blu-ray players, streaming devices, and other sources to be displayed.

What type of cable is recommended for HDBaseT connection?

Use a CAT5e or higher cable terminated according to IEEE-568B standards. For best performance, use solid-core, shielded CAT6 or CAT7 cables.

Why are the LEDs not lighting up after installation?

Check the power supply connection to the transmitter or switcher (if using PoH). Ensure the HDBaseT cable is properly terminated and not longer than the specified distance. Verify that the source and display are powered on and compatible with HDBaseT.

USER MANUAL VX-1003-RX Black Box

FCC and IC RFI Statements/NOM Statement

FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS

This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subject 3 of Part 15 of PCC rules, which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial environment. Operation of this equipment in a residential area is likely to cause interference, in which case the user at his own expense will be required to take whatever measures may be necessary to correct the interference.

Trademarks Used in this Manual

TRADEMARKS USED IN THIS MANUAL

Black Box and the Double Diamond logo are registered trademarks of

BB Technologies, Inc.

Blu-ray" is a trademark of Blu-ray Disc Association.

Any other trademarks mentioned in this manual are acknowledged to be

the property of the trademark owners.

Important Safety Instructions

1. Do not expose this apparatus to rain, moisture, dripping or splashing water

and do not place objects filled with liquids, such as vases, on the apparatus.

1. Do not install or place this unit in a bookcase, built-in

confined space. Make sure the unit is well ventilated.

1. To prevent risk of electric shock or fire hazard caused by overheating, do not

abstract the unit's ventilation openings with newspapers, tablecloths,

curtains, and similar items.

1. Do not install near any host sources such as radiators, heat registers, stoves,

or other apparatus (including amplifiers) that produce heat

1. Do no place sources of flames, such as lighted candles, on the unit.

2. Clean this apparatus only with a dry cloth.

3. Unbelug this apparatus during lightning storms or when unused for jnoa

periods of time.

1. Protect the power card from being walked on or climbed particularly at

(1) Targeted list: (Subs. 2003; 2004; 2005; 2006; 2007; 2008; 2009; 2010; 2011; 2012; 2013; 2014; 2015; 2016; 2017; 2018; 2019; 2020).

1. Oakure vitrheinertivierungskreis specified by the manufacture

2. Only the all-invested reserves specified by the funds and li

3. Refer all servicing to qualified service personnel.

Disclaimer

Black Box Network Services shall not be liable for damages of any kind,

including, but not limited to, punitive, consequential or cost of cover damages.

resulting from any errors in the product information or specifications set forth

in this document and Black Box Network Services may revise this document at

Table of Contents

Table of Contents

1. Specifications 7
2. Overview 9
   2.1 Introduction....9
   2.2 Features....9
   2.3 What's Incused 10
   2.4 Hardware Description 10
3. India installation 12

Chapter 1: Specifications
1. Specifications
Scaling Receiver (VX-1003-RX) Specifications

Video
Connectors Input	(1) BI-15 HDBaseT,(1) 3.5 mm IR,(2) BI-45 (Ethernet) for pass-through or control,(1) 3-position Phoenix connector (RS-232, TX, RX, DVD),(2) USB type & frame fragment;Output:(1) HDMI Out,(1) 3.5 mm IR,(1) RCA SPOF,(1) 3-position Phoenix audio left, right, ground
Input/Output Resolution Support	Input Up to 3840 x 7160 @30 Hz (UHD);Output UH-330, 3840 x 2180 @30 Hz,FI-D: 1320 x 1080 @60 Hz,HDI: 1280 x 720 @60 Hz,WAXCA: 1920 x 1200 @60 Hz,WAXEA: 1280 x 800 @60 Hz
Maximum Distance	Via CAT50Hz cables:Up to 328 feet (100 m) at 3840 x 2180 @30 Hz, 4.2Ω,or 1080p @60 Hz output resolution.Via CAT50Hz cables:Up to 224 feet (70 m) at 2840 x 2180 @30 Hz;Up to 328 feet (100 m) at 1080p @30 Hz resolution
Indicators
LEDs (5) front-panel LEDs
	(1) Power,(1) Solder,(1) Status,(1) DDR,(1) Link LED for HDBaseT,(2) back-panel LEDs on BI-15 connectors:BI Link,(2) Status
Environment
Operating Temperature 32 to	18°F (0 to 65°C)
Storage Temperature -4 to +15	60°F (-20 to +70°C)
Humidity 10 to 90%, noncondensing
Power
Power Input 100-240 VAC, 50V/Hz, 1.5 A
Input Connector Type IEC320, C14
Power Output 12 VDC, 3.0 A
Power Supply Cord Length of fL (1.8 m)
Mechanical
Dimensions 0.98 H x 9.21"W x 5.67 D(73.4 x 14.4 x 2.5 cm)

Chapter 2: Overview

2. Overview

2.1 Introduction

The VX-1003 RX (VX1000 Series Extender Scaling Receiver - 4K, HDMI,

HDBaseT, Audio1 is a 4K HDBaseT receiver with a 4KΦ30 Hz Scale. It

districts uncompressed or video, Internet, RS-232, and functional fit together up to 338 feet (193 m) over a single CAT6v7 cable.

Vtra a /k @ 30 Hz crystal built in, the mother combines the benefits of an

extended distance HDBaseT receiver with the capabilities of automatic display control by CEC or RS-232, volume adjustment, Ethernet switching, and optional third-party control.

When used with a presentation switcher (AVSC-0401H), the scaling receiver

offers a multi-room AV switching system with vario scaling that enables old

100p and NEW 4K displays to show 4K sources simultaneously.

Use the scaling receiver in applications where high-quality video scaling to 4K

To stop cross-scaling is required because of mix of displays in different aspect ratios or preferred timing.

Notes of prior to change

2.2 Features

- Via CAT6s7 cables, the contenders support 4K 4830 Hz up to 330 feet

(100 meters).

- Offers a single CATs cable solution that transmits 4K AudioVideo, RS-232,

Ethernet, and FcH power.

- Complies with HDMI 1.4 with 4K @ 30 Hz and HDCP 2.2.

• Supports USB-KV/V control

• Supports Power over HDBaseT (PoH). The scaling receiver can send power to

an HDBaset Transmitter via 48-VDC FoH

• Provinces RS-232 passthrough.

• Manages EDID automatically

• Cable termination follows IEEE-568B standards.

Chapter 1: Specifications

2.3 What's Included

Your package should include the following items. If anything is missing

or damaged, contact Black Row Technical Support at 877-877-2269

VX-1701-2X:

1. 2024年

- VX1500 Series Barrier Transmitter -X, HDMI, HBBase, Audio (VX-1031-FX)

• (1) VX-1003-RX Presentation on Switcher Scaling Receiver

• (1) (1) 12-VDC, 1.5-A power supply with US, EU, UK, and AU power dips

• (2) IR sensors

• (2) mounting brackets

5

- 10.45%

2.4 Hardware Description

Figures 2-1 and 2-2 show the front and back parts of the receiver. Table 2-1

describe its components.

Figure 2.2 Scaling Receiver back panel

Chapter 2: Overview
Table 2-2 Receiver components.

Number Component Description
1 Power LED	ON: The receiver is powered on. OPT: The receiver is powered off.
2	Scaler LED	ON: The receiver is scaling. OPT: The receiver is not scaling.
3	Status LED	Blinking: The receiver is working properly. OPT: The receiver is not working properly.
4 HDCP LED	ON: HDCP video is being transmitted. Fishing quickly: Non-HDCP video is being transmitted.
5 Link LED	ON: HDBaseT Ink is normal. OPT: No HDBaseT Ink.
6 USB Type	A connector	Used for firmware upgrades.
7 (1) Barrel connector		Links to 12+DC power input (optional).
8,9 (1) R-4G port and (2) HDs		R-4G port connects in an Ethernet device. Splice LED (Ambror). Link/Activity LED (Kemri).
10 HDBase	IN Connect to HDBase OUT port of HDBase® transmter.
11,12 IR IN	IR OUT Infrared signal HDBAT
13 HDMI OUT port Connect to an HDMI display device
14	S/PDIF OUT	Connect to audio OUT.
15 (1) 3 pin terminal block		Connect to a audio OUT.
16 (1) 3 pin terminal block		RS-232 serial control and pass-through

Chapter 3: Initial Installation

1. Initial Installation

2. Using quality HDMI cables, connect an HDBsetT transmitter (VX-1001-TX, VX-1002-TX) or presentation switcher (AVSC-04D1-H) to the HDBsetT IN port of the scaling receiver.
   NOTE: Make sure that the source and display are 4K compatible if you are attempting to transmit an Ultra HG signal—check that all devices are correctly configured for input/output compatibility.

3. Connect a good quality, well-terminated CAT5c or higher cable between the HDBase1 OUT of the transmitter or switcher to the HDBase1 N of the VX-100B-RX Scaling Receiver.
   NOTE: The maximum transmission distances for the extenders are 230 feet (76 meters with CAT5eCAT6 or 326 feet (105 meters with CAT5eCAT7). This value applies to perfect transmission conditions including straight cable runs with no electrical interference, berms, links, patch panes, or wall outlets.
   If any of the above is a factor in your installation, transmission range may be affected—avoid this where possible.
4. Connect the HDMI display device (LED/LCD display or projector) to the HDMI OUT of the VX-1023 RX Scaling Receiver.
5. Connect the audio system to the SPBIF OUT or Audio OUT port of the VX 1003 RX.
   NOTE: We strongly recommend using the supplied mounting brackets to secure the receiver to a flat surface behind near the display device. Sudden movement of these devices could lead to loss of pictures/sound if connections loss or strain, resulting in unnecessary source call-backs.
6. Connect the induced 12-VDC power supply to the VX-1001-TX Transmitter or AVSC D401H Presentation Switcher and power it an. The PAH function carries power along the length of the cable one way to power the Receiver. No additional power supply is required at the display end of the cable run. Power, Status, and HDCP, and Link LEDs illuminated on transmission/switcher and scaling receiver units indicates a successful connection. An HDCP light illustrates the presence of encryption within the signal. The Power and Link LEDs are static lights. The Status LCD should be blinding.

Chapter 3: Initial Installation

Figure 3: Installation diagram.

NOTES
