ALT-N70-TWS - Loudspeaker ELBE - Free user manual and instructions

Product type	Mini Bluetooth Speaker
Brand	ELBE
Model	ALT-N70-TWS
Color	Black
Dimensions (L x W x H)	50 mm x 50 mm x 33 mm
Weight	70 g
Material	Aluminum alloy
Power output	3 W (4 Ω)
Frequency response	20 Hz - 20 kHz
Distortion	< 10%
Signal-to-noise ratio	≥ 85 dB
Impedance	36 mm
Bluetooth version	5.0
Hands-free function	Yes
TWS pairing	Yes (True Wireless Stereo)
Battery type	Li-Ion 400 mAh
Battery charging time	2 hours
Playing time	3-4 hours (at medium volume)
Charging port	Micro USB
Warranty	3 years (from purchase invoice)
Care & cleaning	Wipe with a dry, soft cloth. Avoid water and harsh chemicals.
Safety precautions	Do not expose to liquids or extreme temperatures. Use only with 5V 500mA-1000mA charger.
Spare parts & repairability	Contact ELBE official service for repairs. No user-serviceable parts.
General information	Designed and manufactured in compliance with European regulations.

Frequently Asked Questions - ALT-N70-TWS ELBE

How do I turn on the speaker and pair it via Bluetooth?

Press and hold the power button for 2 seconds to turn on the speaker. The LED will flash. On your device, go to Bluetooth settings and search for 'ELBE MINI'. Select it to pair.

How long does it take to fully charge the speaker and how long does the battery last?

Charging time is approximately 2 hours. Playtime is about 3-4 hours at medium volume.

How do I pair two speakers for stereo sound (TWS)?

Ensure both speakers are not paired to any device. Turn both on. Quickly press the power button twice on one speaker. A sound will confirm successful pairing. Then connect your phone to that speaker.

How do I use the hands-free function?

Double-press the button to answer a call. Short press to end the call. The microphone is built-in.

What is the warranty period and what does it cover?

The product has a 3-year warranty from the date of purchase. It covers manufacturing defects but not damage from improper use or unauthorized repairs.

How should I clean the speaker?

Wipe the speaker with a dry, soft cloth. Do not use water or cleaning agents as they may damage the device.

Is the speaker compatible with all Bluetooth devices?

Yes, it works with most Bluetooth-enabled devices such as smartphones, tablets, and computers, as long as they support Bluetooth 5.0 or earlier versions.

What should I do if the speaker doesn't turn on or charge?

First, check the charging cable and USB port. Use a standard charger (5V, 500mA-1000mA). If the battery is completely drained, it may take a few minutes before the LED indicates charging. If problems persist, contact support.

Can I use the speaker while it's charging?

It is recommended not to use the speaker while charging to ensure battery longevity and safety.

Where can I find the user manual or additional support?

The user manual is available for download on the ELBE products website: https://elbeproducts.es/. For further support, email [e-mail] or call [phone].

USER MANUAL ALT-N70-TWS ELBE

Two black spherical electronic speakers with speaker grille, one open and one closed (no visible text or symbols)

MINI BLUETOOTH SPEAKER MANUAL

WITH HANDS FREE, TWS

MOD. ALT-R70-TWS (RED) / ALT-N70-TWS (BLACK)

Close-up of two black spherical electronic devices with a speaker grille, showing front and back views (no text or symbols visible)

Congratulations on purchasing your new ELBE MINI True Wireless BT Speaker. This product has been created by our team in accordance with European regulations. For better use of your new equipment, we recommend that you read this instruction manual carefully and keep it for future reference.

IMPORTANT: Before using your new speaker, make sure the device's battery is fully charged. Always charge your device with the included charging cable, you can use a standard USB charger (not included), do not use chargers with a power higher than 5V 500mA-1000mA.

Content in the box:

ELBE MINI Bluetooth speaker, USB charging cable, strap, and user manual.

Technical specifications:

• Power 4Ω3W.
• Bluetooth Speaker JL5.0
• Material: Aluminium alley.
• Playing time: 3 - 4h. (medium volume)
• Battery charging time: 2h.
• Hands-free function.

- Compatible with TWS functions. Pairing of two speakers for stereo sound.

- Li-Ion rechargeable battery: 400 mAh via micro USB.

• Colour: black (ALT-N70-TWS) or Red (ALT-R70-TWS)
• Frequency response: 20HZ-20KHZ
• Distortion: <10%
• Signal/noise ratio: ≥85dB
• Impedance: 36mm
• Weight: 70g
• Size: 50mm x 50mm x 33mm

Speaker operation:

Bluetooth function: Press ⏻ for 2 seconds to turn on the device and enter Bluetooth mode, at the same time, the LED light will flash. Follow the operating instructions for Bluetooth connection on your device and search for the Bluetooth speaker.

Usually this is done by going to the "Settings" menu, connect for the "Bluetooth" function, and then select the option to search for the Bluetooth device "ELBE MINI".

Your device (mobile phone, PC, tablet, etc.) will detect the Bluetooth speaker and connect.

Hands-free function: Quickly press the button as twice, you can make a phone, short press

to end the phone call

Charging:

Charge the speaker via the micro USB port with the included charging cable.

The status LED indication will turn red, and after fully charged, the light will turn off.

When the battery is low, the product will periodically emit a warning tone "beeps"

True Wireless Stereo pairing (TWS function for two speakers):

Make sure the speakers are not paired with any external Bluetooth devices.

Turn on both speakers.

Quickly press the key twice on one speaker to start TWS pairing,

A quick sound will be heard after two speakers have been successfully paired.

Warranty:

This product is guaranteed for 3 years from the date of the purchase invoice.

Those devices whose failure has been caused by improper use of the device will be exempt from warranty. Also those equipment that have been manipulated by the user or by an after-sales service outside the list of official ELBE Technical Services.

The validity of the guarantee will be linked to the purchase invoice or ticket that corroborates the acquisition and date of sale of the product.

As a consumer of this article, you enjoy the rights recognized by the Law of Guarantees in the sale of Consumer Goods RDL 1/2007 of November 16 (B.O.E 11/30/2007), under the conditions that it establishes. As of January 1, 2022, the provisions of RDL 7/2021, of April 27, entered into force in Spain.

You can find this information available on our website https://elbeproducts.es/

Recycling and disposal of the product:

This product has been designed and manufactured with high-quality, recyclable and reusable materials. The symbol drawn below indicates that, at the end of its useful life, electrical and electronic equipment must be disposed of separately and must not be mixed with household waste. Dispose of this product at a recycling / waste collection point. In the European Union there

are specific collection systems for used electrical and electronic waste.

Device Manufactured in R.P.C Imported by River International S.A.

contact e-mail: [e-mail] tel. [phone]

Web: www.elbeproducts.es
