MMBCH900I - Range hood Mayer - Free user manual and instructions

Product Type	Range Hood
Brand	Mayer
Model	MMBCH900I
Width	90 cm (900 mm)
Height	60-120 cm adjustable
Depth	50 cm
Weight	Approx. 15 kg
Power Supply	220-240 V ~ 50 Hz
Total Motor Power	150 W
Lighting Power	2 x 20 W incandescent or LED (depending on model)
Max Extraction Rate	700 m³/h
Noise Level (max)	62 dB(A)
Type of Control	Electronic push buttons
Speed Levels	3 speeds + intensive
Filter Type	Aluminum grease filters (washable)
Carbon Filter (optional)	Available for recirculation mode
Ducting	Exhaust (150 mm diameter) or recirculation
Installation	Built-in (under cabinet or island)
Color	Stainless steel
Cleaning	Grease filters dishwasher safe; clean surface with mild detergent
Safety Features	Overheat protection, auto shut-off (if applicable)
Warranty	2 years (subject to terms)
Repairability Index	Not rated (estimated medium)
Spare Parts Availability	Authorized service centers

Frequently Asked Questions - MMBCH900I Mayer

How do I install the Mayer MMBCH900I range hood?

Installation should be done by a qualified professional. Ensure the hood is fixed securely to the wall or under the cabinet. Follow the user manual for exact measurements and ducting requirements. The minimum distance from the hob should be 65 cm for electric and 75 cm for gas hobs.

How often should I clean the grease filters?

The aluminum grease filters should be cleaned every 2-3 months depending on usage. They can be washed in the dishwasher or by hand with warm soapy water. Ensure they are completely dry before reinstalling.

Can the MMBCH900I be used in recirculation mode?

Yes, the hood can be converted to recirculation mode by installing optional activated carbon filters. These filters need to be replaced every 6-12 months.

What is the noise level of this range hood?

The noise level varies by speed: approximately 52 dB at low speed, 58 dB at medium, and 62 dB at high speed. These values are within standard range for comparable models.

How do I replace the light bulb?

Disconnect the hood from power. Remove the lamp cover (usually a snap-on or screw type). Replace the bulb with one of the same type and wattage (2 x 20 W max, E14 or similar). Reattach the cover and restore power.

My hood is not extracting properly. What should I check?

First, ensure the grease filters are clean. Check the ductwork for blockages or kinks. Verify that the carbon filters (if recirculating) are not saturated. Also confirm the external flap (if exhausting outside) opens freely.

Does the hood come with a remote control?

The MMBCH900I typically does not include a remote control; it is operated by electronic push buttons on the front panel. Some models may have optional remote accessories.

What are the dimensions of the ducting outlet?

The ducting outlet has a diameter of 150 mm. For recirculation mode, the adapter may differ; refer to the manual.

Is the warranty transferable?

The warranty is usually valid for the original purchaser only. Check the warranty card or contact Mayer customer support for transfer policies.

How do I reset the filter saturation indicator?

If your model has a filter saturation indicator, press and hold the speed control button for a few seconds until the indicator light turns off. Refer to the manual for exact procedure.

USER MANUAL MMBCH900I Mayer

Modern kitchen interior with glossy white marble walls, a black Moyer air conditioner, and a glass oven (no visible text or symbols)

SAFETY WARNINGS

PLEASE KEEP THIS MANUAL FOR REFERENCE

Safety Warnings

Please read this instruction manual thoroughly before attempting to use this appliance for the first time. This manual contains important information on safe installation, use and care of the appliance. Keep these instructions for reference and pass them on to future user.

Unpackaging

• Do not use the appliance if there are obvious signs of transportation damage.
• If the power supply cord is damaged, it must be replaced by the manufacturer, its service agent or qualified technician to avoid hazard.
• Please ensure that young children do not play with plastic bag packaging.

For Installer

• Before beginning installation, it is advisable to remove the grease filter to better handle the hood.
• Installation and repair should be done only by qualified technical personnel.
• When installing the hood observe the following minimum distances from the cooking top:

Hood and gas hob: 700mm

Hood and induction hob: 600 to 650mm

(Refer to Fig. 1)

Fig. 1

• The manufacturer will not be held liable in case of failure to adopt proper safety measures.
• Ensure the location in which this appliance is installed has good permanent ventilation.
• Use an electrical connector with earth that is correct for your location.
• Check that the voltage in your area is correct before plugging in.
• The electrical connection of this appliance must be connected to earth.

Green & Yellow = EARTH

Blue = NEUTRAL

Brown = LIVE

• Multiple plugs and extension cables must not be used. Overload is dangerous and may cause fire.
• Ensure that the power supply cord is free from any heat source or sharp objects.
• Failure to observe these basic instructions will drastically reduce the performance and increase the noise levels of the extractor hood.

For User

• The extractor hood is designed for domestic use to eliminate unpleasant odors from the kitchen. Do not use the hood for uses other than its specific purpose.
• Young children should be supervised to ensure that they do not play with the appliance.

It is dangerous to modify any part of this appliance.

• Tampering with electrical connections or mechanical parts can cause operation faults and may put the user at risk.
• Never leave high naked flames under the extractor hood when it is in operation. Always cover lit burners with cookware.
• Never carry out any flambé cooking under the hood.
• It is extremely important to note that overheating can cause a fire.
• The hood must always be disconnected from the electricity supply before beginning any maintenance work.
• Accumulated grime is highly combustible; hence it is very important to clean the hood and replace the filter at the recommended intervals. Failure to do so could cause grease deposits to build up, resulting in a fire hazard.

Cleaning & Maintenance

Disconnect the power supply cord before carrying out any cleaning or maintenance activities. It is important to clean and/or replace the filters at appropriate intervals as grease deposits build-up increases the risk of fire. Do not operate the extractor hood without grease filter.

SURFACES

• Clean the extractor hood using warm detergent solution and a soft damp cloth. Wipe dry with a lint free cloth.
• Avoid using corrosive or abrasive products that could damage the surface.
• Never insert pointed objects in the motor's protective grid.
• Only clean the switch panel and filter grill using a damp cloth and mild washing up liquid.
• It is extremely important to clean the unit and change the filters at the recommended intervals. Failure to do so will cause grease deposits to build up that could constitute a fire hazard.
• Never use metallic scouring pads or abrasive products that could damage the surface. Do not use scrapers with metallic surfaces such as knives, scissors etc.

CHARCOAL FILTERS (only in re-circulating model)

• Charcoal filters cannot be reused and must be replaced with the appropriate types once every six months or depending on the frequency of the appliance usage. You may want to lean closer the frequency if you do a lot of cooking, or if your cooking style includes a lot of spicy or greasy foods. Once your filter is saturated, it is the indication that it is time to change the filter. You can purchase the filter from Mayer Service Centre or on Mayer e-Store.
• Regular maintenance is essential to allow this appliance to function effectively.
• Clogged filters restrict airflow and may cause the motor to overheat.

RECTIFIER PANEL AND OIL CUP

(only available for selected models)

• The rectifier panel and oil cup should be cleaned regularly, once a month, depending on the frequency of the appliance usage.
• Always use both hands to carefully hold on to the parts upon removing to prevent oil dripping out.
• Wash with warm or hot soapy water and a soft sponge. Avoid using abrasive detergent and scouring pads as these will cause scratch on the stainless steel finishing.

ALUMINIUM FILTERS

• Grease filters are used to absorb the grease particles formed during cooking process. The filters must be removed and cleaned every 4 weeks, depending on how often the appliance is used.
• Soak the panels in a degreasing agent for an hour then rinse off.
• Do not bend the filters during washing.

LED LIGHT REPLACEMENT

- Remove the filter support to access the bulbs. Ensure that the mains are disconnected beforehand and that the bulbs to be replaced are not hot.
