| Product Type | Riflescope |
| Model | M8Xi 1-8x24 |
| Magnification | 1x - 8x |
| Objective Lens Diameter | 24 mm |
| Reticle | Illuminated MSR-D2 or similar |
| Field of View at 100 yards (1x) | ~115 ft |
| Field of View at 100 yards (8x) | ~14 ft |
| Eye Relief | 3.5 inches |
| Exit Pupil | 3 mm (8x) to 24 mm (1x) |
| Click Value | 0.1 MRAD per click |
| Turret Travel per Revolution | 10 MRAD |
| Total Elevation Adjustment | 30 MRAD |
| Total Windage Adjustment | 30 MRAD |
| Parallax Setting | 100 yards fixed |
| Length | 10.6 inches |
| Weight | 22.9 ounces (650 g) |
| Main Tube Diameter | 30 mm |
| Battery Type | CR2032 (for illumination) |
| Waterproof / Fogproof | Yes, nitrogen purged |
| Shockproof | Up to 1000 G |
| Mounting | 30 mm rings (not included) |
| Illumination Settings | 11 levels, off between each |
| Lens Coating | Anti-reflective, hard coated |
| Warranty | Steiner Heritage Warranty (limited lifetime) |
| Application | Tactical, hunting, sport shooting |
Frequently Asked Questions - M8Xi 1-8x24 Steiner
How do I zero the scope?
Zero your Steiner M8Xi at a known distance (typically 100 yards) using the elevation and windage turrets. Follow the manual's zeroing procedure for best results.
What battery does the illumination use?
The illuminated reticle uses a CR2032 battery. Rotate the illumination knob counterclockwise to access the battery compartment.
How do I clean the lenses?
Use a lens brush or air blower to remove dust. Apply a small amount of lens cleaning solution to a microfiber cloth and gently wipe in circular motions. Avoid touching the lens with fingers.
Is the scope waterproof?
Yes, the M8Xi is waterproof and fogproof thanks to nitrogen purging. It can withstand submersion up to 1 meter for 30 minutes.
What is the eye relief?
The eye relief is approximately 3.5 inches (89 mm) at all magnifications, providing comfortable viewing even with high-recoil rifles.
Can I use this scope for close-range engagements?
Absolutely, the 1x setting provides a wide field of view similar to a red dot sight, making it ideal for close-quarters shooting.
How do I adjust the reticle brightness?
Rotate the illumination knob (on the left side of the eyepiece) to select one of 11 brightness levels. An off position exists between each level to quickly toggle on/off.
What mounting rings do I need?
The scope has a 30 mm main tube, so you need 30 mm rings. Ensure they are properly torqued to avoid damaging the scope.
How often should I check the turret zero stops?
After initial zeroing, check the zero stops periodically (especially after rough handling). The turrets have positive resettable zero for easy return.
What is the total elevation adjustment range?
The M8Xi offers 30 MRAD (102 MOA) of total elevation adjustment and the same for windage, allowing for long-range shooting.
