EMX-010146 - Headphones Huslog - Free user manual and instructions

Product Type	Electronic Device (Uncategorized)
Brand	Huslog
Model	EMX-010146
Dimensions (approx.)	120 x 80 x 30 mm
Weight	150 g
Power Supply	5V DC via USB cable (included)
Battery Backup	2x AAA (not included)
Display	LCD screen with backlight
Main Functions	On/Off button, menu navigation, data display
Connectivity	Bluetooth 4.0
Operating Temperature	0°C to 40°C
Storage Temperature	-10°C to 60°C
Cleaning	Wipe with a soft, dry cloth
Safety	Keep away from water and extreme heat. Not for children under 3.
Spare Parts	Battery compartment cover, screws (M2)
Repairability	User-replaceable batteries; other repairs by qualified technician

Frequently Asked Questions - EMX-010146 Huslog

How do I turn on the Huslog EMX-010146?

Press and hold the power button for 2 seconds until the display lights up.

What type of batteries does it use?

It uses 2x AAA batteries (not included) for backup or primary power when not connected via USB.

Can I use it while charging?

Yes, the device can be used while connected to a USB power source.

How do I reset the device?

Insert a paperclip into the reset hole on the bottom for 5 seconds.

What is the Bluetooth range?

The Bluetooth range is approximately 10 meters (30 feet) in open space.

How do I clean the device?

Use a soft, dry cloth. Do not use any liquids or abrasive cleaners.

Is the device waterproof?

No, it is not waterproof. Keep it away from water and moisture.

What does the blinking light mean?

A blinking light indicates low battery or Bluetooth pairing mode. Charge or replace batteries, or refer to the manual.

Can I replace the battery myself?

Yes, open the battery compartment on the back and replace with 2x AAA batteries observing correct polarity.

Where can I find the full manual?

The full manual is available for free download on notice-facile.com in PDF format.

USER MANUAL EMX-010146 Huslog

-WODA I INNE PŁ YNY-

Bluetooth Headphones

Lot number: 613103

Manufacturer

mPTech Ltd.

Equipment delivery location:

mPTech Ltd.

Krakowska street 119

50-428 Wrocław

Poland

Designed in Poland

Manufactured in China

TABLE OF CONTENTS

1. Safety of use 13
2. Technical Specification 15

2.1 Technical data ....15
2.2 Package content....15

1. Appearance of the device 16
2. Operation of the device....17

4.1 Charging the battery....17
4.2 Bluetooth connection .....17
4.3 Music playback control....17

1. Troubleshooting.... 18
2. Maintenance of the device 18
3. Symbol explanation.... 19
4. The use of the manual ....20
5. Warranty....20
6. EU Declaration of conformity ....20

1. Safety of use

Attention

The manufacturer is not responsible for any consequences caused by improper usage of the phone and not obeying the instructions contained in this manual.

-SAFETY-

Read these guidelines carefully. Not following them may be dangerous or illegal.

-DO NOT RISK-

Do not switch on the device when the use of mobile phones is prohibited or if it might cause interference or danger. Always abide by any kinds of prohibitions, regulations and warnings conveyed by the staff of the entity where you wish to use the device.

-QUALIFIED SERVICE-

This product may only be repaired by qualified service personnel of the manufacturer or by an authorised service centre. Repairing by an unauthorized or unqualified service may cause device damage and warranty loss. The manufacturer is not liable for damages caused by independent alterations.

-CHILDREN AND PHYSICALLY OR MENTALLY DISABLED PEOPLE-

This device should not be operated by people (including children) with limited physical or mental abilities, as well as by people with no earlier experience in operation of electronic equipment. They may only use it under the supervision of persons responsible for their safety after they have read and understood the instructions for safe use.

Keep the device and packaging out of reach of children. Cables and plastic bags may wrap around a child's neck and cause strangulation or other health problems.

-BLUETOOTH-

The device emits electromagnetic waves in the radio frequency range from 2.402 GHz to 2.480 GHz, with a maximum power level of 0.76 dBm EIRP. The Bluetooth wireless speaker complies with safety standards and radio frequency recommendations. All wireless devices may cause interference to other devices.

-SURROUNDINGS-

The device should not be used in dusty conditions. Connect the unit so that it cannot be damaged or endanger people or animals. Do not expose the device to sunlight and do not use it or leave it in close proximity to heat-generating devices (heaters, radiators etc.). Plastic parts may deform, which may affect the operation of the device or cause it to break down completely.

-WATER AND OTHER LIQUIDS-

Do not submerge the device in water, it can adversely affect the electronics and may cause damage to the equipment.

-SAFETY WHILE LISTENING TO MUSIC-

To avoid hearing damage, do not use the device at high volume levels for a long period of time. Try to take a break from listening to music and other sounds with the device, so that you don't risk hearing loss.

-BATTERY-

Avoid exposing the battery to very high/low temperatures ( 0° C - 45 ° C / 32 ° F - 113 ° F). Extreme temperatures may influence capacity and battery life. Avoid contact with liquids and metal

objects as it may cause partial or complete battery damage. The battery should be used according to its purpose. Do not destroy, impair or throw the battery into flames - it might be dangerous and may cause fire. Worn-out or impaired battery should be placed in a dedicated container. Excessive charging the battery can cause damage. Therefore do not charge longer than necessary.

2. Technical Specification

2.1 Technical data

Bluetooth Headphones
Model	EMX-010146
Wireless connectivity	Bluetooth (up to 10 m)
Connectors	USB, USB-C
Transducer	40mm, 32 Ω
Power supply	5V = 500 mA (USB-C)
Built-in battery	Li-ion 3,7V = 200mAh, 0,74Wh

2.2 Package content

1. Bluetooth Headphones
2. USB-C cable
3. User manual

If any of the above items is missing or damaged, please contact your dealer.

We advise to keep the container in case of any complaints. Keep the container out of reach of children.

The latest version of the user manual is available at the Internet address:

https://mptech.eu/qr/psi-patrol/

1. Appearance of the device

4. Operation of the device

4.1 Charging the battery

The battery should be fully charged before the first use of product. Several charging and discharging cycles may be necessary to achieve full battery capacity.

Avoid excessive battery discharge. This can damage the battery or shorten its service life.

The device can heat up during charging. It is a regular occurrence and should not affect the stability or

performance of the device. Do not leave the device to be charged unattended as this may result in fire, damage to the device or its surroundings etc.

To charge the device, connect the included USB-C cable to the charging connector on the bottom of the device. Connect the other end of the cable to a powered USB adapter or e.g. a power bank, etc. (none of these power devices are included in the set), which provides an output of 5V = 500 mA or higher current. Once charging begins, the status LED will glow red. When charging is complete, the status LED will turn off. Disconnect the USB cable from the device and the power source.

4.2 Bluetooth connection

Turn on your device by pressing ON/OFF button for about 3 seconds. Bluetooth pairing mode will be activated automatically - the status LED will flash blue and red alternately.

Search the source device (smartphone, tablet, laptop) for "EMX-010146" and pair the devices together. If you need to enter the PIN code, enter: 0000. Once paired, you will hear a beep and the status LED will turn off.

4.3 Music playback control

Once the headphones are paired with a Bluetooth sound source

5. Troubleshooting

In case of any problems with the device, please refer to the following tips.

The device cannot be switched on.	Charge the battery in the device.
Bluetooth connection does not work	Make sure that your device (smartphone, tablet, laptop, etc.) is paired correctly with the microphone.Check that the distance between the devices is not more than 10 m/ 33 ft in the open air. Every obstacle (furniture, wall, etc.) affects the distance between devices.
Playing music files from USB memory does not work	Check whether the memory is damaged.Check if the media is formatted to FAT or exFAT file system.Make sure the media is in MP3 or WAV format.
Poor sound quality in audio playback	Check the sound quality of the source.Make sure that the Bluetooth transmission is not disturbed by, for example, a working microwave or other device.
If the problem persists, contact service centre.

6. Maintenance of the device

The device may only be cleaned with a dry cloth or paper towel. It is forbidden to use water or any other liquids to clean the device.

7. Symbol explanation

The packaging of the device can be recycled in accordance with local regulations.

The packaging elements should be disposed of in appropriate containers.

The marking of the container into which the inlay - paper should be discarded.

Symbol for cardboard.

The device is marked with a crossed-out garbage bin, in accordance with the European Directive 2012/19/EU on used electrical and electronic Equipment (Waste Electrical and Electronic equipment - WEEE). Products marked with this symbol should not be disposed of or dumped with other household waste after a period of use. The user is obliged to get rid of used electrical and electronic equipment by delivering it to designated recycling point in which dangerous waste are being recycled. Collecting this type of waste in designated locations, and the actual process of their recovery contribute to the protection of natural resources. Proper disposal of used electrical and electronic equipment is beneficial to human health and environment. To obtain information on where and how to dispose of used electrical and electronic equipment in an environmentally friendly manner user should contact their local government office, the waste collection point, or point of sale, where the equipment was purchased.

In accordance with Directive 2006/66/EC as amended by Directive 2013/56/EU on the disposal of batteries and accumulators, this product is marked with the symbol of a crossed-out waste bin. The symbol indicates that the batteries used in this product should not be disposed with regular

household waste, but treated according to the legal directives and local regulations. It is not allowed to dispose of batteries and accumulators with unsorted municipal waste. Users of batteries and accumulators must use the available collection points of these items, which allows them to return, recycle and disposal.

Within the EU, the collection and recycling of batteries and accumulators is a subject to separate procedures. To learn more about existing procedures of recycling of batteries and accumulators please contact your local office or an institution for waste disposal or landfill.

8. The use of the manual

Without prior written consent of the manufacturer, no part of this manual may be photocopied, reproduced, translated or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording or storing in any systems of storing and sharing information.

All brand names and product names are trademarks or registered trademarks of their respective companies.

9. Warranty

The product is covered by a 2-year warranty, counting from the date of sale of the product. If you need to make use of a warranty claim, please contact the manufacturer's helpline or point of sale. The product returned for warranty claim should be complete and in its original packaging.

10. EU Declaration of conformity

CE mPTech Sp. z o.o. hereby declares that the radio equipment type EMX-010146 is in compliance with Directive 2014/53/EU.

The full text of the EU declaration of conformity is available at the following internet address:

https://mptech.eu/qr/psi-patrol/
