Product Type	Socket Dimmer
Brand	Bearware
Model	305386
Input Voltage	250V ~ AC 50 Hz
Maximum Load	300 W
Frequency Range	433.050 - 434.790 MHz
Remote Control Battery	Type 27A 12V battery
Max Transmitting Power	< 10 dBm
Ambient Temperature Range	0-35°C
Compatible Bulbs	Incandescent lamps and dimmable LEDs
Functions	Brightness dimming via remote control; pairing multiple units
Pairing Method	Press and hold ON/OFF/CODE DIMMER button until LED flashes, then press remote ON button
Indoor Use Only	Yes
Warranty	2 years
Disposal	WEEE compliant; separate electronic waste
Safety Certifications	Directive 2014/53/EU
Manufacturer	WD Plus GmbH, Wohlenbergstraße 16, 30179 Hannover, Germany

Frequently Asked Questions - 305386 Bearware

How do I pair the remote control with the socket dimmer?

Plug the dimmer into a socket. Press and hold the ON/OFF/CODE DIMMER button on the dimmer until its LED flashes slowly. Then press the desired ON button on the remote control. The LED will flash twice to confirm pairing.

What types of bulbs are compatible with this dimmer?

This dimmer works with incandescent lamps and dimmable LEDs up to a maximum of 300 watts.

Can I control multiple dimmers with one remote?

Yes, you can control up to two different devices with the remote. However, it is not recommended to set more than one dimmer receiver to the same control button.

How do I reset or clear the code memory?

Press and hold the ON/OFF/CODE DIMMER button until the LED flashes continuously. Then release and press it again. The connected lamp will flash twice to confirm.

What battery does the remote control use?

The remote control uses a Type 27A 12V battery. Pull the plastic tab before first use.

Is the dimmer suitable for outdoor use?

No, the dimmer is designed for indoor use only. Protect it from moisture, water, and snow.

What is the maximum power rating?

The maximum switching capacity is 300 watts. Do not exceed this.

Can I use this dimmer with appliances like refrigerators?

No, do not use with consumers that have a motor capacitor (e.g., refrigerators, fans). It is only for incandescent and dimmable LED bulbs.

What is the warranty period?

The manufacturer offers a 2-year warranty on workmanship and materials. Keep the original sales receipt as proof.

How should I dispose of the dimmer?

Dispose of it according to the WEEE Directive 2012/19/EU. Do not mix with household waste. Return it to a collection point or the manufacturer.

USER MANUAL 305386 Bearware

Thank you for choosing a Bearware product. To ensure that you enjoy your purchased device for a long time, please read the following quick start guide carefully

1. Scope of delivery

• Socket dimmer
• Remote control
• User manual

2. Technical data

Electrical voltage 250V ~ AC 50 Hz
Maximum power 300 W
Frequency range 433.050 - 434.790 MHz
Remote control battery Type 27A 12V battery
Max. Transmitting power (e.i.r.p) < 10 dBm
Ambient temperature 0-35° Celsius

3. Important instructions for use

• Only suitable for incandescent lamps and dimmable LEDs
  • The maximum switching capacity is 300 W
• The unit is only suitable for indoor use
• Please plug only into approved sockets, not into extension cables
• Do not plug in one after the other
  • Voltage-free only when the plug is disconnected
• Use the unit only when dry
• Do not exceed the specified maximum electrical power.
• Please do not use for consumers with motor capacitor (e.g. refrigerator etc.)

4. Functions

The Bearware socket dimmer offers you the possibility to individually adjust the brightness of incandescent lamps. The dimming can be conveniently controlled via the remote control and works with most incandescent lamps and dimmable LEDs that have an output of up to a maximum of 300 watts.

5. Commissioning

Take the product from its packaging and remove any packing material. Connect the light bulb or dimmable LED whose brightness is to be controlled by the dimmer to the unit. Then plug the dimmer into a properly installed earthed socket. Pull the plastic tab out of the remote control before using the unit.

6. Teaching remote control

1. Plug the socket dimmer into the socket.
2. Place the remote control near the dimmer and press and hold the „ON/OFF/CODE DIMMER“ button on the socket dimmer until the dimmer's LED flashes slowly.
3. Then press the desired ON button on the transmitter to assign the unit.
4. Once the unit has been successfully paired, the LED of the connected receiver flashes twice, the code is confirmed and the LED stops flashing. The unit is then ready for operation.

7. Operating

Remote control

Please press the remote control key ON to switch on the unit.

Please keep the remote control key ON pressed until the desired brightness is reached. If you press the remote control key OFF, the unit is switched off again.

Controlling several units with one remote control

You can control 2 different devices with the remote control. To do this, connect the remote control to other end devices.

CAUTION! It is not recommended to set ON/OFF receiver and dimmer receiver to the identical control button on the transmitter or to set more than 1 dimmer receiver to the same control button.

Clear code memory

Press and hold the „ON/OFF/CODE DIMMER“ button until the LED flashes continuously. Then release the button and press it again. The lamp of the connected receiver will flash twice for confirmation.

8. Warranty

The manufacturer grants a warranty of two years on this product with regard to workmanship and materials. Repairs may only be carried out by an authorised customer service. The original sales receipt must be enclosed as proof. The following are excluded from this warranty: normal wear and tear, modifications, reworking, damage due to carelessness, external influences, areas of application for which the product is not designed or completely or partially dismantled products.

9. Safety instructions and liability disclaimer

Never try to open the device to carry out repairs or conversions. Avoid contact with mains voltages. Do not short-circuit the product. The device is not certified for use in the open air; only use it in dry conditions. Protect it from high humidity, water and snow. Keep it away from high temperatures. Do not subject the device to sudden changes in temperature or heavy vibration as this might damage electronic components. Examine the device for damage before using it. The unit should not be used if it has received an impact or has been damaged in any other way. Please observe national regulations and restrictions. Do not use the device for purposes other than those described in the instructions. This product is not a toy. Keep it out of the reach of children or mentally impaired persons. Any repair or alteration to the device not carried out by the original supplier, will invalidate the warranty or guarantee. The product may only be used by persons who have read and understood these instructions. The device specifications may change without any separate prior notice to this effect.

10. Disposal instructions

Electrical and electronic devices may only be disposed of in accordance with the European WEEE Directive and not with household rubbish. Components must be disposed of or recycled separately as dangerous, toxic elements can inflict sustained damage on the environment if they are disposed of incorrectly. As a consumer, you are bound by the Electrical and Electronic Devices Act (ElektroG) to return electrical and electronic goods free of charge at the end of their useful life to the manufacturer, the place of purchase or to specially set up, public collection points. The details in each case are governed by national law. The symbol on the product, the operating instructions and/or the packaging refers to these regulations. By separating materials in this way, recycling and disposing of old devices, you are making an important contribution towards protecting our environment.

WEEE guideline: 2012/19/EU

WEEE register number: DE 67896761

WD Plus GmbH hereby declares that the device 305386 is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. A complete declaration of conformity can be obtained from: WD Plus GmbH, Wohlenbergstraße 16, 30179 Hannover, Germany; http://downloads.ganzeinfach.de/search/model/305386
