Product Type	Rotating Belgian Waffle Maker
Brand	Beautiful by Drew Barrymore
Model Number(s)	19393, 19427, 19428, 19429, 19430, 19451
Power Requirements	120 V AC, 60 Hz
Cooking Plates	Nonstick, top and bottom
Rotation	180° rotating design for even baking
Temperature Control	Adjustable dial with READY indicator lights
Drip Tray	Removable for easy cleaning
Handle	Cool-touch rotating handle
Cord Storage	Built-in cord wrap at base
Batter Capacity	Approximately 3/4 to 1 cup per waffle
Preheat Time	Approximately 4 minutes
Safety Features	Polarized plug, short cord, hot surface caution
Cleaning	Wipe nonstick plates with damp cloth; drip tray washable; never immerse in water
Warranty	Limited 2-year warranty (mechanical), 90-day non-mechanical parts
Country of Origin	China (implied by typical manufacturing)
Included Accessories	User manual

Frequently Asked Questions - Rotating Waffle Maker Beautiful

How do I preheat the waffle maker?

Plug in the unit, the POWER light will illuminate. Turn the temperature dial to MAX (+) and wait about 4 minutes until the READY light turns on. Then adjust to desired setting.

What should I do if my waffles stick to the plates?

Before first use and periodically, brush the nonstick plates with vegetable oil. Avoid nonstick sprays. If sticking occurs, clean plates and recondition with oil.

Can I use metal utensils on the cooking plates?

No. To protect the nonstick coating, use only plastic, nylon, or wooden utensils.

How do I clean the waffle maker?

Unplug and let cool completely. Wipe the interior and exterior with a soft, damp cloth or sponge. The drip tray can be removed and washed with mild soap. Never immerse in water or put in dishwasher.

Why does my waffle maker smoke when first used?

A slight smoke or odor is normal during the first use due to manufacturing residues. It will disappear after 1-2 uses. Discard the first waffles.

How much batter should I use?

Start with 3/4 to 1 cup of batter, enough to cover the lower grid peaks. The drip tray catches any overflow. Adjust as needed for your recipe.

Can I make gluten-free or low-fat waffles?

Yes. For gluten-free, use gluten-free flour mixes or alternatives like almond or coconut flour. For low-fat, use skim milk, egg whites only, and vegetable oils instead of butter.

How do I store the waffle maker?

Ensure it is unplugged and fully cool. Wrap the cord loosely around the base; do not wrap tightly or stress the cord entry point. Store on a flat, dry surface.

What is the warranty?

Two-year limited warranty from date of purchase covering mechanical defects. Non-mechanical parts are covered for 90 days. Proof of purchase required. Contact 1-877-775-3564 for service.

Can I repair the waffle maker myself?

No. The appliance contains no user-serviceable parts. Any disassembly beyond cleaning must be performed by a qualified technician. Contact customer service for issues.

USER MANUAL Rotating Waffle Maker Beautiful

Rotating Waffle Maker Waflera Belga Rotativa

Black-and-white photo of a smiling woman sitting on a kitchen counter surrounded by shelves with food items like air fryers and refrigerators (no visible text or symbols)

The kitchen is my family's happy place. It's where we cook and eat and bake and laugh and share our most beautiful moments together. That's what inspired the creation of Beautiful, my new collection of easy-to-use kitchenware that you'll want to keep out on your kitchen counter. So whether your kitchen has flour all over the place from a kid's baking session or you're throwing an adult dinner party, I hope every step will be simple, delicious and beautiful!

www.beautifulbydrew.com

Table of Contents

Section 1: Safety

Important Safeguards....6-8

Additional Important Safeguards....8

Notes on the Cord 8-9

Notes on the Plug 9

Plasticizer Warning 10

Electric Power 10

Section 2: Instructions

Getting to Know Rotating Belgian Waffle Maker 12

Before First Use.... 13

Operating instructions 13-14

Waffle Baking Tips 15-16

User Maintenance Instructions 17

Care & Cleaning Instructions 17

Storing Instructions 18

Warranty 19-20

Índice

When using electrical appliances, basic safety precautions should always be followed, including the following:

1. READ ALL INSTRUCTIONS.

1. The cord to this appliance should be plugged into a 120V AC electrical outlet only.
2. To protect against risk of electric shock, do not immerse the cord, plug or cooking unit in water or any other liquid.
3. Do not touch hot surfaces. Use handles or knob.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from wall outlet when not in use and before cleaning. Allow to cool before cleaning or storing this appliance.
6. Never yank the cord to disconnect the cooking unit from the outlet. Instead, grasp the plug and pull to disconnect.
7. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has been damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or adjustment.
8. The use of accessories or attachments not recommended

by the manufacturer may cause fire, electrical shock or injury.

1. Do not use outdoors or for commercial purposes.
2. Do not use this appliance for purposes other than the one for which it was designed.
3. Do not let the electrical cord hang over the edge of the table or countertop, or touch hot surfaces
4. Do not place on or near a hot gas or electric burner or in a heated oven
5. Use on a heat-resistant, flat level surface only.
6. Use extreme caution when moving any appliance containing hot food, water, oil or other liquids.
7. To disconnect, remove plug from outlet.
8. Always unplug after use. The appliance will remain ON unless unplugged.
9. CAUTION HOT SURFACES: This appliance generates heat during use. Proper precautions must be taken to prevent the risk of burns, fire or other damage to persons or property.
10. When using this appliance, provide adequate ventilation above and on all sides for air circulation. Do not allow this appliance to touch curtains, wall coverings, clothing, dish towels or other flammable materials during use.

SAVE THESE INSTRUCTIONS

ADDITIONAL IMPORTANT SAFEGUARDS

CAUTION: this appliance is hot during operation and retains heat for some time after plugging out. Always use oven mitts when handling hot materials and allow metal parts to cool before cleaning. Do not place anything on top of the appliance while it is operating or while it is hot.

1. All users of this appliance must read and understand this Instruction Manual before operating or cleaning this appliance.
2. Do not leave this appliance unattended during use.

NOTES ON THE CORD

A. A short power-supply cord (or detachable power-supply cord) should be used to reduce the risk resulting from becoming entangled in or tripping over a longer cord.

B. Longer detachable power-supply cords or extension cords are available and may be used if care is exercised in their use.
C. If a longer detachable power-supply cord or extension cord is used:

1. The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance;

2. The cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally; and 3. If the appliance is of the grounded type, the cord set or extension cord should be a grounding-type 3-wire cord.

NOTES ON THE PLUG

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not modify the plug in any way.

PLASTICIZER WARNING

CAUTION: To prevent Plasticizers from migrating from the finish of the counter top or table top or other furniture, place NON-PLASTIC coasters or place mats between the appliance and the finish of the counter top or table top. Failure to do so may cause the finish to darken; permanent blemishes may occur or stains can appear.

ELECTRIC POWER

If the electrical circuit is overloaded with other appliances, your appliance may not operate properly. It should be operated on a separate electrical circuit from other appliances.

Section 2

Instructions

Getting to Know Your Rotating Belgian Waffle Maker

Product may vary slightly from illustrations

1. Temperature Control Dial (Top View)
2. READY Light (Top)
3. POWER Light
4. Top Nonstick Cooking Plate

5. Bottom Nonstick Cooking Plate

6. Removable Drip Tray

7. Cool Touch Rotating Handle
8. READY Light (Bottom)
9. Power Cord with Polarized Plug (not shown)
10. Cord Wrap (not shown)

Before Using for the First Time

1. Carefully unpack the Rotating Belgian Waffle Maker and remove all packaging and materials.
2. Before using your Waffle Maker for the first time, wipe the cooking plates with a damp cloth to remove all dust, and then dry. Wipe outer surfaces with a slightly damp, soft cloth or sponge.
   CAUTION: Take care to prevent water from running into the appliance. Never immerse Rotating Belgian Waffle Maker unit in water or any other liquids!
3. Set the appliance on a dry, clean and flat surface.

Operation

1. Lift top cooking plate. Make sure the Rotating Belgian Waffle Maker's bottom cooking plate is positioned flat and locked into a stable position. Before baking the first waffles of the day, use a pastry brush to lightly coat the top and bottom waffle plates with vegetable oil. Do not use non-stick sprays as they can cause build-up on the cooking plates.
2. Plug unit into a 120 V AC electrical outlet. The POWER light will illuminate and remain lighted during use.
   NOTE: When your Rotating Belgian Waffle Maker is heated for the first time, it may emit slight smoke or odor. This is normal and should disappear after one or two uses. This does not affect the safety of the appliance. However, as it may affect the flavor of the first waffles prepared in the Waffle Maker, it is recommended that these be discarded.
3. Turn the temperature control dial to the MAX (+) setting to preheat.
4. While preheating, prepare waffle batter. (Figure 1)
5. After approximately 4 minutes, the READY light will illuminate, indicating the unit is preheated and is ready for use. (Figure 2)
6. Set the waffle temperature control to the desired setting. A lower setting produces a lighter browned waffle, while waffles made at a higher setting are darker and crispier. When preparing a recipe for the first time, set the control to the middle; then adjust according to preference. Recipes will vary in cook time and brownness; batters with

more sugar will brown quicker. Note the perfect setting for each batter recipe for future use.

1. Pour 3/4 to 1 cup batter onto the bottom cooking plate. Add just enough batter to fill lower grid so that the peak area is covered. If necessary, use a spatula to spread the batter in to the corners of the plate. Try not to overfill, batter will expand when cooked. The drip tray will catch any spilled-over batter.
2. The READY light will turn off as the baking cycle begins.
3. Lower the top cooking plate to close the Rotating Belgian Waffle Maker and rotate unit 180^ to the bottom side.
4. The Rotating Belgian Waffle Maker will cook until the READY light (on the backside of the Waffle Maker) illuminates. Rotate Waffle Maker 180^ to the top side, until it is flat and locked into a stable position.
5. Lift the top cooking plate gently; if it pulls, continue cooking for 1 minute and test again. Waffles should be baked according to the temperature control setting chosen. If the waffles need to bake to a darker finish, close the lid and continue baking until the desired color is achieved.
6. Remove waffles from the cooking plates using non-metallic utensils.
   NOTE: If additional waffles are to be baked, keep the Rotating Belgian Waffle Maker closed to retain heat. Always be sure the green light is illuminated before baking more waffles.
   NOTE: Waffles made later will bake faster because extra heat has been retained.
7. When baking is complete, unplug the power cord from electric outlet. Lift top cooking plate and allow to cool. Make sure the Rotating Belgian Waffle Maker's bottom cooking plate is positioned flat and locked into a stable position.
8. Do not clean until unit has been fully cooled.
9. Use the cord storage to wrap the cord at the base of the unit.

Figure 1 Figure 2

Line drawing of a mechanical component with 'READY' label and circular connector (no text or symbols beyond the label)

Waffle Baking Tips

• Sift all dry ingredients together. It is not necessary to beat egg yolks and milk separately.
• Beat egg whites until they form stiff peaks. Stir 1/4 of the beaten whites into the batter to lighten it, and then gently fold in the rest. There should be white streaks in the batter. Do not over-mix batter when adding egg whites.
• Some recipes may be doubled. Do not make large batches of batter when whipped egg whites have been used to lighten the waffle.
• Do not open the Rotating Belgian Waffle Maker during the first minute of baking or the waffle will separate. Completely bake waffles before removing.
• When preparing waffle batter with gluten flour, do not over-mix or waffles will be tough. Stir batter only until large lumps of dry ingredients disappear.
• The optimal amount of batter to produce a full-shaped waffle, without overflowing, will vary with different waffle batters. Pouring batter from a measuring cup will help to gauge how much batter to use each time. Fill bottom cooking plate of Rotating Belgian Waffle Maker with enough batter to cover peak areas. Begin with 1 scant cup (1/4 cup per quarter waffle). Add more if needed.
• For more evenly shaped waffles, spread thick batters to the outer edge of the cooking plate using a heat-proof rubber spatula or other non-metallic utensil before closing the lid.
  • To retain crispness, move baked waffles to a wire cooling rack. To keep

waffles warm, place on an ovenproof dish on an oven rack and warm at about 200-250 °F (90-120 °C). Waffles will keep for about 20 minutes before they begin to dry out.

• Baked waffles freeze well. Cool completely on a wire rack. Store in a plastic freezer bag or in a covered container, separating waffles with wax paper.
• Reheat frozen waffles in a microwave, toaster oven, convection or conventional oven or toaster until hot and crisp.

FOR GLUTEN-FREE WAFFLES:

• Use gluten-free baking mixes.
• Use gluten-free flour.
- Replace flour in recipes with combinations of: coconut flour, rice flour, almond flour, oat flour, corn meal.

FOR LOWER FAT, LOWER CHOLESTEROL WAFFLES:

• Use skim milk.
• Replace full fat milk with nut or seed milks: almond, cashew, soy, flax, or hemp seed milk.
  • Use whites only, eliminate the egg yolk.
  • Always use liquid vegetable oils such as canola, coconut, corn or sunflower, instead of butter.
• Replace 1 egg with 3 tablespoons cold water + 1 tablespoon ground flax seed.
• Replace 1 egg with 3 tablespoons cold water + 1/2 tablespoon ground chia seed.

FOR HIGHER FIBER WAFFLES:

• Substitute 1/2 cup or more of white flour with whole-wheat flour.
• Substitute 1/4 cup of white flour with wheat or oat bran.
• Replace 1 egg with 3 tablespoons cold water + 1 tablespoon ground flax seed.
• Replace 1 egg with 3 tablespoons cold water + 1/2 tablespoon ground chia seed.

User Maintenance Instructions

This appliance requires little maintenance. It contains no user serviceable parts. Do not try to repair it yourself. Any servicing requiring disassembly other than cleaning, must be performed by a qualified appliance repair technician.

Care & Cleaning Instructions

CAUTION: unplug from electrical outlet and allow to cool thoroughly before cleaning.

1. The Rotating Belgian Waffle Maker does not disassemble for cleaning.
2. If batter has dripped onto the drip tray, remove drip tray immediately after use and rinse with warm water. Wash with mild dishwashing liquid. Remove stubborn stains with a plastic mesh puff or pad. Do not use steel wool or coarse scouring pads.
3. Never immerse appliance in water or other liquids. Never place Rotating Belgian Waffle Maker in dishwasher.
4. The waffle cooking plates should be cleaned and conditioned before each heating.
5. Brush cooking plates with a clean, soft pastry brush or cloth. To condition plates, lightly coat the cooking surfaces with solid vegetable shortening or vegetable oil. Carefully follow suggested cleaning procedures below. After a time, if waffles show signs of sticking, recondition as needed.
6. To protect the premium quality non-stick surfaces, use only plastic, nylon or wooden utensils.
7. To remove any batter baked onto the cooking plates, pour a small amount of cooking oil onto the hardened batter. Allow to set for 5 minutes, then wipe softened batter off with a paper towel or soft cloth. Remove stubborn stains with a plastic mesh puff or pad. For best results, use only products with directions stating that it is safe for cleaning non-stick cooking surfaces. Do not use steel wool or coarse scouring pads.
8. The exterior finish should be cleaned with a non-abrasive cleaner and a soft, damp cloth. Dry thoroughly.

Storing Instructions

Make sure unit is unplugged and fully cooled. Never wrap cord tightly around appliance. Do not put any stress on cord where it enters unit, as this could cause cord to fray and break.

Limited Two-Year Warranty

Sensio Inc. dba Made by Gather™ hereby warrants that for a period of TWO YEARS from the date of purchase, this product will be free from mechanical defects in material and workmanship, and for 90 days in respect to non-mechanical parts. At its sole discretion, Sensio Inc. dba Made by Gather™ will either repair or replace the product found to be defective, or issue a refund on the product during the warranty period.

The warranty is only valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Keep the original sales receipt, as proof of purchase is required to obtain warranty validation. Retail stores selling this product do not have the right to alter, modify, or in any way revise the terms and conditions of the warranty.

Exclusions:

The warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use of the product, use of improper voltage or current, improper routine maintenance, use contrary to the operating instructions, disassembly, repair, or alteration by anyone other than qualified Sensio Inc. dba Made by Gather™ personnel. Also, the warranty does not cover Acts of God such as fire, floods, hurricanes, or tornadoes.

Sensio Inc. dba Made by Gather™ shall not be liable for any incidental or consequential damages caused by the breach of any express or implied

warranty. Apart from the extent prohibited by applicable law, any implied warranty of merchantability or fitness for a particular purpose is limited in time to the duration of the warranty. Some states, provinces or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, and therefore, the above exclusions or limitations may not apply to you. The warranty covers specific legal rights which may vary by state, province and/or jurisdiction.

How To Obtain Warranty Service

You must contact Customer Service at our toll-free number: 1-877-775-3564. A Customer Service Representative will attempt to resolve warranty issues over the phone. If the Customer Service Representative is unable to resolve the problem, you will be provided with a case number and asked to return the product to Sensio Inc. dba Made by Gather™ Attach a tag to the product that includes: your name, address, daytime contact telephone number, case number, and description of the problem.

Also, include a copy of the original sales receipt. Carefully package the tagged product with the sales receipt, and send it (with shipping and insurance prepaid) to SENSIO Inc.'s address. Sensio Inc. dba Made by Gather™ shall bear no responsibility or liability for the returned product while in transit to Sensio Inc. dba Made by Gather™ Customer Service Center.

Beautiful®

Kitchenware

Sección 1

Seguridad

Line drawing of a mechanical component with 'READY' label and circular connector (no text or symbols beyond the label)

PARA WAFLES SIN GLUTEN:

www.beautifulbydrew.com

For customer service questions or comments

19393, 19427, 19428, 19429, 19430, 19451 R0
