PS581 - Shredder Duronic - Free user manual and instructions

Type of product	Document shredder
Dimensions (H x W x D)	Approx. 45 x 35 x 20 cm
Weight	Approx. 4 kg
Power supply	230 V / 50 Hz
Power consumption	200 W
Shred type	Cross-cut
Shred size	4 x 40 mm
Sheet capacity	8 sheets (70 gsm)
Bin volume	15 litres
Security level	P-4 (DIN 66399)
Shred speed	2 m/min
Noise level	≤ 60 dB
Duty cycle	2 minutes on / 30 minutes off
Safety features	Overheat protection, auto reverse, safety lock
Maintenance	Oil blades every 30 minutes of use
Cleaning	Unplug and use a soft damp cloth to clean exterior
Spare parts	Blades not user-replaceable; contact support for gear or motor parts
Repairability	Limited; mainly replace entire unit for serious issues
Manufacturer	Duronic
Model	PS581

Frequently Asked Questions - PS581 Duronic

What type of shredder is the Duronic PS581?

The Duronic PS581 is a cross-cut paper shredder designed for home or small office use. It shreds documents into small pieces for enhanced security.

How many sheets can the PS581 shred at once?

The PS581 can shred up to 8 sheets of 70 gsm paper simultaneously. For thicker or glossy paper, reduce the number to avoid jams.

What is the bin capacity of the PS581?

The shredder comes with a 15-litre bin, which holds approximately 100-150 shredded sheets before needing to be emptied.

How do I clean the PS581 shredder?

First, unplug the shredder. Use a soft, damp cloth to wipe the exterior. For the blade area, use a shredder lubrication sheet or oil every 30 minutes of continuous use.

What should I do if the shredder jams?

If the shredder jams, press the reverse button to clear the paper. If that doesn't work, unplug and gently remove paper from the entry slot. Avoid pulling forcefully.

Can the PS581 shred credit cards or staples?

Yes, the PS581 can shred credit cards and small staples. However, remove large binder clips or thick metal items to prevent damage.

What security level does the PS581 offer?

The shredder provides security level P-4 according to DIN 66399, meaning it cuts paper into 4x40 mm particles, suitable for confidential documents.

How often should I oil the blades?

It is recommended to oil the blades every 30 minutes of continuous use or whenever the shredder becomes noisy. Use a vegetable-based shredder oil.

Does the PS581 have overheating protection?

Yes, the PS581 is equipped with overheat protection. If the motor gets too hot, it will automatically shut off. Allow it to cool for at least 30 minutes before restarting.

Where can I find a replacement parts for the PS581?

Spare parts such as gears or motors can be obtained by contacting Duronic support. The blades are not user-replaceable. Check the manual or official website for spare parts requests.

USER MANUAL PS581 Duronic

Creative Consumer Products

Exterior view of a modern, black and white portable electronic device with a textured back panel (no visible text or symbols)

PS581

duronic.com

duronic

@duronicmedia

Duronic

@duronicmedia

Contents

English Manual 4

Technical line drawing of a multi-stage cleaning or assembly process, showing structural changes from inner to outer casing (no text or symbols)

SPECIFICATIONS

Shred Type: Crosscut Shred Size: 4mm x 39mm Shredding Capacity: 15 Sheets Duty Cycle: 2 min ON / 40 min OFF Feed Opening: 220mm Input: 220 - 240V, 50-60Hz, 2A

SETUP

1. The PS581 shredder should be placed on a flat, level surface.
2. Carefully place the shredder into the upright position on a flat level surface.
3. Be careful not to place your fingers near the cutter blades.
4. With the wastebasket removed from the shredder, place the shredder head over the cabinet, then firmly push down on the four corners of the shredder head to lock it into place.
5. Slide the wastebasket into the shredder cabinet. Make sure that the wastebasket is completely inserted into the shredder and that it fits flush with the cabinet.
6. Plug the power cord into any standard 230-Volt AC outlet which shall be installed near the equipment and should be easily accessible.
7. Place the switch in the AUTO position. The READY LED should light up. You are now ready to start shredding.

OPERATION

With the electrical cord plugged in, the switch in the AUTO position and wastebasket properly inplace the READY LED will light up. This signals that the shredder is now ready for use. When the paper is inserted into the feed opening, the shredding process will start automatically and stop when the paper has completed its travel through the feed opening.

The PS581 mode selection switch is located on top of the shredder. Also located on top of the shredder is the READY LED light.

• AUTO: The shredding process will start when the paper is inserted into the feed ioening and will continue until it has completely passed through.
• REV: In the event of a paper jam, this reverses the shredding process in order to assist in the removal of a paper jam. Thus clearing the cutters.

DURONIC

• OFF: It is recommended to turn the shredder off when it is not being used for a prolonged period of time.
• READY: When the READY LED is lit up, it lets the user know that the wastebasket is correctly inserted and the shredder is on and ready for use. If the READY LED does not light up, make sure the shredder is plugged in and the wastebasket is inserted correctly.

CAPACITY

The PS581 will shred up to 15 sheets up paper and will accept paper widths up to 220mm. When shredding envelopes or receipts, insert them into the middle of the feed opening. CD's, DVD's and credit cards should be placed in the designated slot.

PAPER JAMS AND OVERLOADS

The PS581 is equipped with an automatic motor overload protection circuit. The duty cycle for the PS581 is rated for 2 Min ON / 40 Min OFF. The PS581 will automatically terminate power in case of the following situations.

1. Operating the shredder at the maximum capacity of fifteen (15) sheets continuously for a prolonged period of time.
2. Exceeding the shredding capacity by inserting more than 15 sheets of paper in one pass or if the paper is not fed squarely into the feed opening.

Both abnormal operations may result in the activation of the automatic thermal motor overload protection circuit, which terminates the power to the shredder. A paper jam could cause the thermal motor overload protection to terminate AC to power the motor. Never allow the shredder to remain in a jammed condition with the AC power turned on. If this occurs you should:

DURONIC

In case of a minor paper jam:

1. Grasp the excess paper from the top and pull it out as you depress the REV button. Be careful not to place your fingers near the feed opening or else serious harm could occur.

2. Make sure that all of the excess paper has been removed from the feed opening.

3. You are now ready to resume normal shredding.

In case of a major paper jam:

1. Turn off or unplug the power cord from the AC outlet and wait at least 40 minutes for the thermal overload protection to reset.

2. Plug in the AC power cord and place the switch back into the AUTO position. If paper was left inside the feed opening prior to the overload, place the switch in REV and grasp the excess paper from the top and pull it out. Be careful not to place your fingers near the feed opening or serious harm could occur.

3. Place the switch back into the AUTO position. You are now ready to resume normal shredding.

WARNING

1. ALWAYS keep out of the reach of children as serious injury could occur.
2. DO NOT place fingers too close to the feed slot as serious injury could occur.
3. AVOID keeping loose articles of clothing; ties, jewelry, hair or other items near from the feed opening, in order to prevent injury.
4. ALWAYS keep the shredder off and unplugged when not in use.
5. ALWAYS unplug the shredder when moving, cleaning or emptying the waste receptacle.
6. DO NOT attempt to feed more sheets of paper into the feeder than specified.
7. DO NOT attempt to shred materials other than paper and credit cards in the provided feed slots.
8. ALWAYS install the shredder near the socket-outlet and have it easily accessible.

DURONIC

1. ALWAYS limit continuous shredding to the specified time as suggested in the instruction manual.
2. ALWAYS empty the waste receptacle prior to the receptacle becoming full.
3. DO NOT attempt to operate the shredder if the shredder is experiencing any kind of problem.
4. DO NOT use flammable synthetic oil, petroleum-based or aerosol products of any kind on the shredder.

WARNING

READ INSTRUCTION BEFORE USE

NO FINGERS OR HANDS

NO HAIR

NO LOOSE CLOTHING

NO CHILDREN

NO AEROSOL PRODUCTS

13 - 15 MAX

DURONIC

Warranty

1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products. NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A CONSUMER

This product has been manufactured under the strictest or quality control procedures, and using the highest quality of materials, to ensure excellent performance and reliability. It will give very good and long lasting service, provided it is properly used and maintained. The product is guaranteed for 1 years from the date of original purchase. If any defect arises due to a faulty materials or poor workmanship, the faulty product must be returned to the original place of purchase. Refund or replacement is at the discretion of that company.

Duronic Products are offered with a 1 year guarantee under the following conditions:

1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions contained in this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect, inexpert repairs or consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work, under the guarantee
7. Valid in the UK only

This product is fitted with CE:1363 plug and fuse Imported by Shine-Mart Ltd, RM3 8SB

Information on waste Disposal for Consumers of

Electrical & Electronic Equipment.

This mark on a product and/or accompanying documents indicates that when it is to be disposed of, it must be treated as Waste Electrical & Electronic Equipment, (WEEE).

Any WEEE marked products must not be mixed with general household waste, but kept separate for the treatment, recovery and recycling of the materials used.

For proper treatment, recovery and recycling; please take all WEEE marked waste to your Local Authority Civic waste site, where it will be accepted free of charge.

If customers dispose of Waste Electrical & Electronic Equipment correctly, they will be helping to save valuable resources and preventing any potential negative effects upon human health and the environment, of any hazardous materials that the waste may contain.

Follow Us

duronic.com

duronic

@duronicmedia

Duronic

@duronicmedia

Technical line drawing of a multi-stage cleaning or assembly process, showing structural changes from inner to outer casing (no text or symbols)

SPECIFICATIONS

Shred Type: Crosscut

Shred Size: 4mm x 39mm

Shredding Capacity: 15 Sheets

Duty Cycle: 2 min ON / 40 min OFF

Feed Opening: 220mm

Input: 220 - 240V, 50-60Hz, 2A

SETUP

1. The PS581 shredder should be placed on a flat, level surface.
2. Carefully place the shredder into the upright position on a flat level surface.
3. Be careful not to place your fingers near the cutter blades.
4. With the wastebasket removed from the shredder, place the shredder head over the cabinet, then firmly push down on the four corners of the shredder head to lock it into place.
5. Slide the wastebasket into the shredder cabinet. Make sure that the wastebasket is completely inserted into the shredder and that it fits flush with the cabinet.
6. Plug the power cord into any standard 230-Volt AC outlet which shall be installed near the equipment and should be easily accessible.
7. Place the switch in the AUTO position. The READY LED should light up. You are now ready to start shredding.

OPERATION

With the electrical cord plugged in, the switch in the AUTO position and wastebasket properly inplace the READY LED will light up. This signals that the shredder is now ready for use. When the paper is inserted into the feed opening, the shredding process will start automatically and stop when the paper has completed its travel through the feed opening.

The PS581 mode selection switch is located on top of the shredder. Also located on top of the shredder is the READY LED light.

• AUTO: The shredding process will start when the paper is inserted into the feed ioening and will continue until it has completely passed through.
• REV: In the event of a paper jam, this reverses the shredding process in order to assist in the removal of a paper jam. Thus clearing the cutters.

DURONIC

- OFF: It is recommended to turn the shredder off when it is not being used for a prolonged period of time.

- READY: When the READY LED is lit up, it lets the user know that the wastebasket is correctly inserted and the shredder is on and ready for use. If the READY LED does not light up, make sure the shredder is plugged in and the wastebasket is inserted correctly.

CAPACITY

The PS581 will shred up to 15 sheets up paper and will accept paper widths up to 220mm. When shredding envelopes or receipts, insert them into the middle of the feed opening. CD's, DVD's and credit cards should be placed in the designated slot.

PAPER JAMS AND OVERLOADS

The PS581 is equipped with an automatic motor overload protection circuit. The duty cycle for the PS581 is rated for 2 Min ON / 40 Min OFF. The PS581 will automatically terminate power in case of the following situations.

1. Operating the shredder at the maximum capacity of fifteen (15) sheets continuously for a prolonged period of time.
2. Exceeding the shredding capacity by inserting more than 15 sheets of paper in one pass or if the paper is not fed squarely into the feed opening.

Both abnormal operations may result in the activation of the automatic thermal motor overload protection circuit, which terminates the power to the shredder. A paper jam could cause the thermal motor overload protection to terminate AC to power the motor. Never allow the shredder to remain in a jammed condition with the AC power turned on. If this occurs you should:

In case of a minor paper jam:

1. Grasp the excess paper from the top and pull it out as you depress the REV button. Be careful not to place your fingers near the feed opening or else serious harm could occur.
2. Make sure that all of the excess paper has been removed from the feed opening.
3. You are now ready to resume normal shredding.

In case of a major paper jam:

1. Turn off or unplug the power cord from the AC outlet and wait at least 40 minutes for the thermal overload protection to reset.
2. Plug in the AC power cord and place the switch back into the AUTO position. If paper was left inside the feed opening prior to the overload, place the switch in REV and grasp the excess paper from the top and pull it out. Be careful not to place your fingers near the feed opening or serious harm could occur.
3. Place the switch back into the AUTO position. You are now ready to resume normal shredding.

WARNING

1. ALWAYS keep out of the reach of children as serious injury could occur.
2. DO NOT place fingers too close to the feed slot as serious injury could occur.
3. AVOID keeping loose articles of clothing; ties, jewelry, hair or other items near from the feed opening, in order to prevent injury.
4. ALWAYS keep the shredder off and unplugged when not in use.
5. ALWAYS unplug the shredder when moving, cleaning or emptying the waste receptacle.
6. DO NOT attempt to feed more sheets of paper into the feeder than specified.
7. DO NOT attempt to shred materials other than paper and credit cards in the provided feed slots.
8. ALWAYS install the shredder near the socket-outlet and have it easily accessible.

DURONIC

1. ALWAYS limit continuous shredding to the specified time as suggested in the instruction manual.

2. ALWAYS empty the waste receptacle prior to the receptacle becoming full.

3. DO NOT attempt to operate the shredder if the shredder is experiencing any kind of problem.

4. DO NOT use flammable synthetic oil, petroleum-based or aerosol products of any kind on the shredder.

WARNING

READ INSTRUCTION BEFORE USE

NO FINGERS OR HANDS

NO HAIR

NO LOOSE CLOTHING

NO CHILDREN

NO AEROSOL PRODUCTS

13 - 15 MAX

DURONIC

Garantie

Technical line drawing of a multi-stage cleaning or assembly process, showing structural changes from inner to outer casing (no text or symbols)

TECHNISCHE DATEN

Technical line drawing of a multi-stage cleaning or assembly process, showing structural changes from inner to outer casing (no text or symbols)

ESPECIFICACIONES

Technical line drawing of a multi-stage cleaning or assembly process, showing structural changes from inner to outer casing (no text or symbols)

SPECIFICHE

Technical line drawing of a device interior showing internal components and assembly steps (no text or symbols)

SPECYFIKACJA
