PS591 - Shredder Duronic - Free user manual and instructions

Product Type	Paper Shredder
Brand	Duronic
Model	PS591
Shred Type	Crosscut
Shred Size	4 mm x 44 mm
Shredding Capacity	20 sheets
Duty Cycle	30 minutes ON / 40 minutes OFF
Feed Opening Width	220 mm
Input Voltage	220 - 240 V AC, 50/60 Hz
Rated Current	2 A
Power Consumption	Approx. 460 W (calculated)
Basket Capacity	Not specified in manual, typical for this size
Basket Full Sensor	Yes
Auto Start/Stop	Yes, via paper insertion
Reverse Function	Yes, for clearing paper jams
Motor Overload Protection	Automatic thermal overload protection
Materials Accepted	Paper, credit cards, CDs, DVDs (in designated slot)
Safety Features	No fingers/hands, no hair, no loose clothing, no children, no aerosol products
Cleaning	Unplug, wipe with damp cloth, no sharp instruments or flammable fluids
Warranty	1 year (UK only)

Frequently Asked Questions - PS591 Duronic

What is the shredding capacity of the Duronic PS591?

The PS591 can shred up to 20 sheets of paper at a time in crosscut mode (4x44 mm).

How do I clear a paper jam in the PS591?

For minor jams, press the REV button while gently pulling out the paper. For major jams, unplug the shredder, wait 40 minutes for the thermal overload to reset, then use REV to extract the paper.

What is the duty cycle of this shredder?

The duty cycle is 30 minutes continuous operation followed by a 40-minute cool-down period.

Can the PS591 shred credit cards and CDs?

Yes, it can shred credit cards, CDs, and DVDs, but only through the designated slot on the feed opening.

What should I do if the shredder stops working?

The shredder may have activated thermal overload protection. Unplug it and wait at least 40 minutes for it to reset. If the problem persists, contact Duronic (Shine-Mart) for assistance.

What safety precautions should I take when using the shredder?

Keep fingers, hair, loose clothing, and jewelry away from the feed opening. Do not allow children to use the shredder. Never spray aerosol products into it. Always unplug when cleaning or not in use.

How do I clean the Duronic PS591?

Unplug the shredder. Use a cloth dampened with lukewarm water to wipe the cabinet and wastebasket. Do not use abrasive cleaners, soap, or flammable fluids.

Does the PS591 have a basket full indicator?

Yes, it has a basket full sensor that lets you know when the wastebasket needs emptying.

What is the warranty on the Duronic PS591?

The PS591 comes with a 1-year guarantee from Shine-Mart Ltd, valid in the UK only. Proof of purchase is required.

Can the PS591 shred envelopes or receipts?

Yes, but you should insert them into the middle of the feed opening to ensure proper shredding.

USER MANUAL PS591 Duronic

Creative Consumer Products

Exterior view of a modern cylindrical water filter unit with black and white casing (no visible text or symbols)

PS591

duronic.com

duronic

@duronicmedia

Duronic

@duronicmedia

DURONIC

Contents

English Manual 5

Technical line drawing of a multi-stage cleaning or assembly process, showing structural changes from inner to outer casing (no text or symbols)

SPECIFICATIONS

Shred Type: Crosscut

Shred Size: 4mm x 44mm

Shredding Capacity: 20 Sheets

Duty Cycle: 30 min ON / 40 min OFF

Feed Opening: 220mm

Input: 220 - 240V, 50-60Hz, 2A

SETUP

1. The PS591 shredder should be placed on a flat, level surface.
2. Carefully place the shredder into the upright position on a flat level surface.
3. Be careful not to place your fingers near the cutter blades.
4. With the wastebasket removed from the shredder, place the shredder head over the cabinet, then firmly push down on the four corners of the shredder head to lock it into place.
5. Slide the wastebasket into the shredder cabinet. Make sure that the wastebasket is completely inserted into the shredder and that it fits flush with the cabinet.
6. Plug the power cord into any standard 230-Volt AC outlet which shall be installed near the equipment and should be easily accessible.
7. Place the switch in the AUTO position. The READY LED should light up. You are now ready to start shredding.

OPERATION

With the electrical cord plugged in, the switch in the AUTO position and wastebasket properly inplace the READY LED will light up. This signals that the shredder is now ready for use. When the paper is inserted into the feed opening, the shredding process will start automatically and stop when the paper has completed its travel through the feed opening.

The PS591 mode selection switch is located on top of the shredder. Also located on top of the shredder is the READY LED light.

- AUTO: The shredding process will start when the paper is inserted into the feed ioening and will continue until it has completely passed through.

- REV: In the event of a paper jam, this reverses the shredding process in order to assist in the removal of a paper jam. Thus clearing the cutters.

- OFF: It is recommended to turn the shredder off when it is not being used for a prolonged period of time.

- READY: When the READY LED is lit up, it lets the user know that the wastebasket is correctly inserted and the shredder is on and ready for use. If the READY LED

DURONIC

does not light up, make sure the shredder is plugged in and the wastebasket is inserted correctly.

• FULL: The PS591 has a basket full sensor to detect when it needs empying.

CAPACITY

The PS591 will shred up to 20 sheets up paper and will accept paper widths up to 220mm. When shredding envelopes or receipts, insert them into the middle of the feed opening. CD's, DVD's and credit cards should be placed in the designated slot.

PAPER JAMS AND OVERLOADS

The PS591 is equipped with an automatic motor overload protection circuit. The duty cycle for the PS591 is rated for 30 Min ON / 40 Min OFF. The PS591 will automatically terminate power in case of the following situations.

1. Operating the shredder at the maximum capacity of twenty (20) sheets continuously for a prolonged period of time.
2. Exceeding the shredding capacity by inserting more than 20 sheets of paper in one pass or if the paper is not fed squarely into the feed opening.

Both abnormal operations may result in the activation of the automatic thermal motor overload protection circuit, which terminates the power to the shredder. A paper jam could cause the thermal motor overload protection to terminate AC to power the motor. Never allow the shredder to remain in a jammed condition with the AC power turned on. If this occurs you should:

In case of a minor paper jam:

1. Grasp the excess paper from the top and pull it out as you depress the REV button.

Be careful not to place your fingers near the feed opening or else serious harm could occur.

1. Make sure that all of the excess paper has been removed from the feed opening.

2. You are now ready to resume normal shredding.

In case of a major paper jam:

1. Turn off or unplug the power cord from the AC outlet and wait at least 40 minutes for the thermal overload protection to reset.

2. Plug in the AC power cord and place the switch back into the AUTO position. If paper was left inside the feed opening prior to the overload, place the switch in REV and grasp the excess paper from the top and pull it out. Be careful not to place your fingers near the feed opening or serious harm could occur.

3. Place the switch back into the AUTO position. You are now ready to resume normal shredding.

SAFETY INFORMATION

Important - Please read these instructions fully before installation

BEFORE USE

• Dispose of all packaging carefully and responsibly.
• This appliance is designed for indoor use only. Do not use outdoors.
• Do not use this shredder for industrial and commercial use, or any other purpose.
• The shredder MUST be positioned on a firm level base before and during use.
• Ensure the power cable is not caught under the appliance.
• Ensure the correct power supply is used (230V AC).
• Keep power cord away from hot surfaces.
• Do not place the shredder near a heat source or in direct sunlight.
• Do not operate under or near curtains or other combustible materials.
• Do not immerse the machine in water or any other liquid to protect against electric shock.
• Keep out of reach of children.
• Do not spray any flammable synthetic oil, petroleum-based or aerosol products onto this shredder as it may cause a fire.
• Do not allow the shredder to be exposed to rain or any other moisture.

DURING USE

• WARNING! Keep loose articles of clothing; ties, jewellery, hair or other objects away from the feed opening in order to prevent injury.
• Never insert fingers into the feed opening. Serious injury may result!
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Do not leave children unattended with the shredder.
• ALWAYS keep the shredder off and unplugged when not in use.
• DO NOT attempt to feed more sheets of paper into the feeder than specified.
• ALWAYS limit continuous shredding to the specified time as suggested in the instruction manual.
• DO NOT attempt to shred materials other than paper and credit cards in the provided feed slot.
• To avoid overheating the shredder, limit continuous shredding to the specified time as suggested in this instruction manual.
• Do not operate the shredder if the cord or plug are damaged or if the shredder has malfunctioned in any way.
• ALWAYS unplug the shredder when moving, cleaning or emptying the wastebasket.
• DO NOT attempt to operate the shredder if the shredder is experiencing any kind of problem.
• If your machine stops working, do not attempt to repair it yourself! Contact Duronic (Shine-Mart) for assistance.

CLEANING AND MAINTENANCE

Important: Always unplug the appliance from the power socket during cleaning and maintenance.

• Never use any sharp instruments or abrasive substances, soap, household cleaner, detergent or wax polish for cleaning.
• Never clean the appliance with flammable fluids. It could cause a damage and fire hazard.
• Use lukewarm water on a cloth to clean the cabinet and wastebasket of the appliance and wipe it dry.
• Ensure the unit is dry before connect to the mains

WARNING

READ INSTRUCTION BEFORE USE

NO FINGERS OR HANDS

NO HAIR

NO LOOSE CLOTHING

NO CHILDREN

NO AEROSOL PRODUCTS

18 - 20 MAX

DURONIC

Warranty

1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products. NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A CONSUMER

This product has been manufactured under the strictest or quality control procedures, and using the highest quality of materials, to ensure excellent performance and reliability. It will give very good and long lasting service, provided it is properly used and maintained. The product is guaranteed for 1 years from the date of original purchase. If any defect arises due to a faulty materials or poor workmanship, the faulty product must be returned to the original place of purchase. Refund or replacement is at the discretion of that company. Duronic Products are offered with a 1 year guarantee under the following conditions:

1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions contained in this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect, inexpert repairs or consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work, under the guarantee
7. Valid in the UK only

This product is fitted with CE:1363 plug and fuse Imported by Shine-Mart Ltd, RM3 8SB

CE

Information on waste Disposal for Consumers of Electrical & Electronic Equipment.

This mark on a product and/or accompanying documents indicates that when it is to be disposed of, it must be treated as Waste Electrical & Electronic Equipment, (WEEE).

Any WEEE marked products must not be mixed with general household waste, but kept separate for the treatment, recovery and recycling of the materials used.

For proper treatment, recovery and recycling; please take all WEEE marked waste to your Local Authority Civic waste site, where it will be accepted free of charge.

If customers dispose of Waste Electrical & Electronic Equipment correctly, they will be helping to save valuable resources and preventing any potential negative effects upon human health and the environment, of any hazardous materials that the waste may contain.
