MR560 - Hand blender Maestro - Free user manual and instructions

Product type	Planetary stand mixer
Brand	Maestro
Model	MR560
Power supply	220-240 V AC, 50 Hz
Rated power	500 W
Max locked power	1000 W
Number of speeds	6
Protective class	II
Waterproof protection	IPX0
Maximum continuous operation	5 minutes
Minimum pause time	10 minutes
Bowl capacity (approx.)	3.5 L
Included accessories	Wire whisks, flat beater, dough hook
Mixing system	Planetary: rotation around own axis and bowl circumference
Safety lock	Prevents operation if improperly assembled
Cleaning method	Hand wash removable parts with warm soapy water
Use	Household only
Certification	Compliant with EU standards
Country of origin	Made in P.R.C. for Maestro
Special features	Scraper blade for cleaning and extraction

Frequently Asked Questions - MR560 Maestro

How do I assemble the mixer?

Attach the bowl by rotating it clockwise until it clicks. Then insert the desired accessory (whisks, flat beater, or dough hook) into the grooves and push lightly until it locks. Ensure the switch is in the OFF position before connecting to power.

What is the maximum operating time?

The mixer can operate continuously for a maximum of 5 minutes. After that, let it cool for at least 10 minutes before using again.

How should I clean the mixer?

Always unplug the mixer before cleaning. Clean removable parts (bowl, whisks, etc.) with warm soapy water and a soft sponge, then rinse and dry. Do not immerse the motor body, cord, or plug in water.

What accessories are included with the MR560?

The package includes: wire whisks (for whipping cream, eggs, etc.), flat beater (for mixing batters), and dough hook (for kneading dough). A scraper blade is also included.

Can I mix very thick dough with this mixer?

Yes, use the dough hook for thick dough. However, do not mix solid ingredients like frozen butter or extremely stiff dough to avoid overheating the motor.

Why does my mixer stop working during use?

It may have reached the maximum continuous operation time of 5 minutes. Turn it off and let it cool for at least 10 minutes. If the problem persists, check the power supply and ensure the cord is not damaged.

Is the mixer safe to use?

Yes, if you follow safety instructions: never immerse the motor in liquid, do not touch moving parts during operation, and always unplug before cleaning. The mixer has a safety lock that prevents operation if assembled incorrectly.

How should I store the mixer?

After cleaning and drying, store the mixer in a cool, dry place out of reach of children. Do not leave the cord wrapped tightly around the unit.

What is the planetary mixing system?

The planetary system makes the head rotate around its own axis while simultaneously moving around the circumference of the bowl. This ensures thorough and homogeneous mixing of ingredients.

Can the mixer be used for commercial purposes?

No, this mixer is designed for household use only. Commercial use may damage the appliance and void the warranty.

USER MANUAL MR560 Maestro

EN

DE

PL

RO

RU

UA

Owners manual. Planetary mixer

White kitchen mixer with control knobs and a side panel, no visible text or symbols on the device itself.

Dear customer, we thank you for purchase of goods

EN

Functionality, design and conformity to the quality standards guarantee to you reliability and convenience in use of this device. Please read and comply with these original instructions prior to the initial operation of your appliance and store them for later use of subsequent owners.

Mixer is designed only for handling (mixing, whisking) liquid and not solid products in domestic conditions.

Under condition of observance of user regulations and a special-purpose designation, a parts of appliance do not contain unhealthy substances.

The particularities of this model are:

- the planetary system of mixing which provides the rotation of the head piece around its own axis and simultaneously around the circumference of the inner volume of the cup. The mixer provides a high quality of mixing and homogenous consistence;

- a system of defense from switching on in case of incorrect assembling of the product.

Delivery set:

Name Q-ty, pcs.
Mixer 1
Wire whisks 1
Flat beater 1
Dough hook 1
User manual 1

Technical specifications

Model MR-560

Electrical supply:

Alternating current- AC;

Rated voltage 220-240V;

Rated frequency 50Hz;

Max locked power: 1000 W; Rated power: 500 W;

Number of operative speeds: 6

Protective class II

Protection class IPX0

Regime of operation: continuous operation during max. 5min., pause during at least 10 min. to complete cooling.

Description of the appliance

Picture1 (page 2)

1. Off switch/interchanging switch of velocities.
2. Cup (bowl)
3. Protective hood of the cup with loading orifice.
4. Motor box.
5. The position (inclination) fixing mechanism of the mixer.
6. Wire whisks.
7. Flat beater.
8. Dough hook.
9. Case.
10. The blade for cleaning and extraction of the ready mass of the product.

Safety instructions

When using your appliance, basic safety precautions should always be followed, including the following:

SPECIAL INSTRUCTIONS

EN

ATTENTION!

NEVER immerse the electric drive case, cable or plug in any liquid. NEVER touch the appliance with wet or damp hands.

ALWAYS disconnect appliance before cleaning, assembling, disassembling, loading and unloading products

Failure to observe these rules may result in electric shock!

• DO NOT let children or untrained persons use the appliance without supervision.
• DO NOT leave the appliance unnecessarily plugged in. Disconnect the plug from the mains when the appliance is not being used.
• DO NOT use the power cord or the appliance in order to pull the plug out of the socket.
• DO NOT leave the appliance exposed to the weather (rain, sun, etc.).
• DO NOT leave the appliance without supervision when it is connected to the power supply.
• Close supervision is necessary when the appliance is used near children.
• Always unplug from the plug socket when not in use and before cleaning.
• Do not operate the appliance if damaged, after an appliance malfunctions or it has been damaged in any manner, return to at authorized service engineer for repair.
• In the interest of safety, regular periodic close checks should be carried out on the supply cord to ensure no damage is evident.

Should there be any signs that the cord is damaged in the slightest degree, the entire appliance should be returned be authorized service engineer.

• Do not let the cord hang over the edge of a table or counter or touch hot surfaces. Allow unit to cool before storage.

• Do not use harsh abrasives, caustic cleaners or oven cleaners when cleaning this appliance.

• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance.
• Do not use damaged nozzles.

ATTENTION!

• Do not touch moving parts during the mixer operation
• Always disconnect appliance before cleaning, assembling, disassembling, loading and unloading products
• Perform assembly and disassembly only after full stop of moving parts.
• Do not try to clean the container or the accessories when the mixer is in operation.

In case of failure to observe the rules a danger of serious damages may arise!

- THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY. DO NOT USE THE APPLIANCE FOR ANYTHING OTHER THAN INTENDED USE.

Purchase industrial devices for commercial use.

Actions in extreme situations:

• If a device tumbled into water, immediately, unplug the device, not touching to the device or water.
• In case of appearance from appliance of smoke, sparkling, strong smell of a burn isolation, immediately stop use the device, unplug the device, appeal to the nearest service center.

Operation

General rules

- Do not use the device for mixing solid ingredients, for example, frozen butter or very dense dough.

EN

• To avoid overheating the motor, do not use mixer longer than minutes without interruption. Leave it for 5-10 minutes to cool before the next use.
• Use whisks (6/Picture1) to whip cream, egg white, pudding, cocktail, mayonnaise, puree, sauce.
• Accessories for mixing (8/ Picture1) shall be used for agitating dough, minced meat, yeasts.
• Use the mixer only with the accessories supplied. Do not plunge the accessories in the product deeper than the work surface of the whisks, do not withdraw the accessories from liquid without having switched off the mixer; wait till the mixer completely stops.

A head piece for mixing (7/Fig.1) suits for mixing of not dense products, for preparing of mashed potatoes, of tomato paste, of confectionary mixtures.

Recommended regimes of products processing

ACCESSORY SPEED	TIME
Dough hook 1~4 1—2 1 mins, then 3—4		3~4 mins
Flat beater 1~4 1~2 30 mins, then 3~4		3~6mins
Whisk 5~6 3-7 mins

Preparation for work

• Before the first use of accessories, wash them with warm water and detergents and dry them thoroughly. Wipe the outside of the mixer case with soft wet cloth, then rub it dry.
• Assure yourself that the switch of operating regimes (1/ Picture1) is in position «0» - OFF

Establish the mixer on the even stable surface.

- By assembling (dismounting) of the mixer, for mounting of head pieces and also by necessity of addition of ingredients during the

process of work, the rising and sinking of the motor box (4/Fig.1) is realized by way of retention of the mixer position (inclination) fixing mechanism button. (5/Fig.1).

• Establish the cup (the bowl) on the housing base, rotate clockwise against stop and till the click of the holder. For removal of the cup it is necessary, correspondingly, to rotate it counterclockwise and to rise it upwards.
• Choose proper accessories for your products.
• Insert the shank end of each of the head pieces into the grooves of the miser body. By way of a slight touch fix the head pieces in the openings till the click.
• Connect the male contact of the feed cable to the electric network.
• Switch on the mixer and select the needed velocity with the help of the interchanging switch (1/Fig.1). Use the recommendations for selection of velocity in dependence of the kind if the used head piece. (Table 1).

ATTENTION!

Don't create obstacles by the hand or by any other subjects to the free rotation of the head pieces. Avoid the hit of the mixed fluid to the mixer body.

• After the ingredients reach the required consistency move the switch to position «0» OFF.
• Wait until the full stopping of the moving parts.
• After the finishing of usage unplug the male contact from the electric network.

Cleaning and maintenance

ATTENTION!

• Never clean the device while it is connected to the mains.
• Before cleaning disconnect the device and wait for full stop of moving parts.
• Do not use abrasive and aggressive detergents, solvents, alkaline, metal objects and wash-ups.

EN

- Never submerge electric drive, its mains cable and plug in water or other liquid, do not wash the drive in water or in a dish washing machine.

• Immediately after terminating the use wash all removable parts with warm soapy water using soft nylon sponge, then rinse with clean water and wipe with dry and clean towel.
• Leave the accessories till they are completely dry.

Wipe the case of the electric drive with a soft cloth and rub it dry with a clean towel.

Storage

• Wipe and dry the appliance before storage.
• Store the appliance in a cool, dry and clean place beyond the assess of children and people with limited physical and mental abilities.

Environmental protection

The equipment is labeled in accordance with the European Directive 2012/19/EC «On the disposal of electrical and electronic waste» crossed-out garbage container sign This label indicates that this equipment must not be disposed of with other household waste at the end of its useful life. The user is obliged to hand it over to the collection point for electrical and electronic equipment waste. Electrical equipment waste is hazardous to the environment. Proper handling of used electrical and electronic equipment avoids harmful effects on human health and the environment resulting from the presence of hazardous components, as well as improper storage and recycling of such equipment. The manufacturer shall not be liable for any damage caused by the intended or improper use of the equipment. The manufacturer has the right to change product specifications at any time without prior notice for design, commercial, aesthetic or other reasons.

Current electric alternativ;

Frecventa nominala: 50 Hz;

Certificated in Ukraine

Made in P.R.C. for Maestro

Apollo Corporation Limited ADD: Room801-2, 8/F., Easey Commercial Building, 253-261 Hennessy Road, Wanchai, Hong Kong,
