SW-171 - Smartwatch DENVER - Free user manual and instructions

Product type	Smartwatch
Brand	Denver
Model	SW-171
Dimensions (approx.)	45 x 38 x 10 mm
Weight (approx.)	50 g
Power supply	Built-in rechargeable lithium-ion battery (3.7 V / 180 mAh)
Battery life (estimated)	5 to 7 days depending on usage
Display	Color touchscreen, 240x240 pixels resolution
Connectivity	Bluetooth 4.0, range 10 m
Water resistance	Splash and sweat proof (IP67, do not swim)
Main functions	Pedometer, sleep, heart rate, blood pressure, SpO2, 8 sports, weather, notifications, music control, camera shutter, stopwatch, sedentary reminder
Sensors	Accelerometer, optical heart rate sensor
Companion app	DENVER SMART (iOS and Android)
Compatibility	iOS 9.0+ / Android 4.4+
Care and cleaning	Clean with a soft dry cloth, dry the strap after contact with water
Safety	Lithium-ion battery: do not expose to heat, recycle separately
Spare parts and repairability	Interchangeable strap (standard 22 mm), battery not user-replaceable
General information	Manufacturer: Denver Electronics A/S, Denmark. Frequency 2402-2480 MHz, max power 0 dBm. Complies with directive 2014/53/EU.

Frequently Asked Questions - SW-171 DENVER

How do I pair the watch with my phone?

Download the DENVER SMART app from the App Store or Google Play. Enable Bluetooth, open the app, go to Device > Add a Device, then select your watch from the list. If necessary, press and hold the time screen to display the MAC address.

How do I charge the watch?

Use the included charging cable (magnetic pins). Connect it to a USB port (5V). The watch takes about 2 hours for a full charge. Do not use a fast charger.

Is the watch waterproof? Can I swim with it?

The watch is resistant to splashes, rain, and sweat, but it is not designed for swimming. Do not fully submerge and avoid showering.

How do I reset the watch to factory settings?

Go to the Other functions (OTHERS) menu on the watch, then select Factory reset. Confirm the operation.

Why are sports data cleared at midnight?

Step, calorie, and distance data are automatically reset to zero every day at midnight. Sync regularly with the app to keep the history.

How do I activate the sedentary reminder?

In the app, go to the watch settings and enable the Sedentary reminder option. The watch will vibrate after 1 hour of inactivity.

Can I receive notifications from all apps?

Through the app, you can choose which apps can send notifications to the watch (Twitter, Facebook, WhatsApp, Instagram, etc.). The last 3 messages are stored on the watch.

How do I measure blood pressure?

From the blood pressure screen, touch the screen to start measurement. Keep your arm still. The last 7 measurements are displayed. Note: This is not a medical device.

What should I do if the watch does not turn on?

Make sure the battery is charged. Press and hold the function button for 3 seconds to turn it on. If nothing happens, plug in the charger and wait 5 minutes before trying again.

Where can I find the declaration of conformity?

Go to www.denver-electronics.com, search for model SW-171, then under the Downloads tab you will find the EU declaration of conformity.

USER MANUAL SW-171 DENVER

Bluetooth Smartwatch

DENVER SW-171

User's Manual

www.facebook.com/denverelectronics

Silhouette of two people running, one running and the other running (no text or symbols)

DENVER ELECTRONICS A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark

Contents

English---- 1 - 6

German---- 7 - 12

French---- 13-18

Spanish---- 19—24

Dutch---- 25-30

Polish---- 31-36

Swedish---- 37-42

Finnish----43-48

Danish 49-54

Portuguese---- 55-60

Italian---- 61-66

Norwegian---- 67-72

Note: If the user manual is not printed in your local language, then please enter our website to see if it is found online under the model you have. The website address is: www.denver-electronics.com

USER MANUAL

SW-171

SMART WATCH

Note: Please upgrade the software to the latest version on the APP before use. Please charge the smart watch before use.

Download App

Scan the following QR code, download and install the App.

Scan QR Code and Download

Pairing

Open the App and set up your profile.

Go to the [Device], Click [Add a Device].

Choose your device on the scanning list.

Finish

Long press the [time page] on your device, and go to the detail page. The MAC address on the detail page can help you identify your device on the scanning list.

Smart watch features

Sports track

The smart watch automatically measures steps taken, calories burned and distance traveled. The measured data is synchronized to the App.

Note: The sport data stored on the watch is cleared at midnight every day.

Sleep monitor

By wearing the smart watch during sleep, it will measure your sleep time and quality. The measured data is synchronized to the App.

Note: The sleep data stored on the watch is cleared at 8:00 pm the next day.

Heart rate monitor

Touch the heart rate page to start measuring your heart rate.

The page can display heart rate data of the latest 7 measurements.

Multi-sport training

Touch the training page to start a new training measure recording. 8 sport modes are available. The last training data is displayed on the training page.

Blood pressure monitor

Touch the blood pressure page to start measuring your blood pressure. The page can display blood pressure data of the latest 7 measurements.

SpO2/blood oxygen monitor

Touch the SpO2 page to start measuring your SpO2/blood oxygen. The page can display the measured data of the latest 7 measurements.

Weather forecast

The weather page displays the weather information of the current and next day. The latest weather information from the App can be synchronized to the watch if the watch is connected to the App.

Message reminder

The watch can synchronize incoming notifications from Twitter, Facebook, Whatsapp, Instagram etc.

Latest 3 messages can be stored on the watch.

Note: You can switch on or off the incoming notification in the App.

Remote shutter

After the watch is connected to the App, the watch can remotely control the camera from your mobile phone.

Music play controller

After the watch is connected to the App, the watch can remotely control the music player from your mobile phone

Other features

Other features include stopwatch, screen brightness adjustment, mute mode, factory resetting, and power off.

Stop watch

Touch the stopwatch page to start timing, and long press again to stop timing.

Simple icon of a jar with a window and label, no readable text or symbols

Alarm

If you set and activate alarm on the App, and the watch is connected to the App, the watch vibrates when the alarm time is up.

Sedentary reminder

The watch vibrates to remind you to walk after 1 hour sitting.

Note: You can switch on or off the feature in the APP.

More information about the smart watch

Using in wet conditions

The smart watch is water-resistant, which means it is rain-proof and splash-proof and can stand up to even the sweatiest workout.

Note: Do not swim with the smart watch. It is not recommended to shower with the smart watch, though it does not hurt the watch. Remove the watch periodically to allow your skin to dry and breathe. Whenever you get your bracelet wet, dry it thoroughly before putting it back on.

Using the function button and the touch screen

Press and hold the function button for 3 seconds to turn on the device, press briefly the function button to wake up the device.

To turn off the device, press and hold the function button, and tap "Power off" on the display.

Tap the screen, slide left for next screen page and slide right for previous screen page. Tap the screen page to start measuring.

Using quick view

When the watch screen is turned off, just turn your wrist towards you and the screen turns on for you to check the time and message from your phone. The watch screen automatically turns off after being idle for a few seconds.

Warning Lithium battery inside

Please notice - All products are subject to change without any notice. We take reservations for errors and omissions in the manual.

ALL RIGHTS RESERVED, COPYRIGHT DENVER ELECTRONICS A/S

DENVER

www.denver-electronics.com

Electric and electronic equipment and included batteries contains materials, components and substances that can be hazardous to your health and the environment, if the waste material (discarded electric and electronic equipment and batteries) is not handled correctly.

Electric and electronic equipment and batteries is marked with the crossed out trash can symbol, seen below. This symbol signifies that electric and electronic equipment and batteries should not be disposed of with other household waste, but should be disposed of separately.

As the end user it is important that you submit your used batteries to the appropriate and designated facility. In this manner you make sure that the batteries are recycled in accordance with legislature and will not harm the environment.

All cities have established collection points, where electric and electronic equipment and batteries can either be submitted free of charge at recycling stations and other collection sites, or be collected from the households. Additional information is available at the technical department of your city.

Hereby, Inter Sales A/S declares that the radio equipment type SW-171 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.denver-electronics.com and then click the search ICON on topline of website. Write modelnumber: SW-171 Now enter product page, and red directive is found under downloads/other downloads Operating Frequency Range: 2402-2480MHZ

Max Output Power: 0 dBm

DENVER ELECTRONICS A/S

Omega 5A, Soeften

DK-8382 Hinnerup

Denmark

www.facebook.com/denverelectronics
