L 15-11 125 - Grinder Flex - Free user manual and instructions
Find the device manual for free L 15-11 125 Flex in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Angle grinder |
| Brand | Flex |
| Model | L 15-11 125 |
| Disc diameter | 125 mm |
| No-load speed | 11000 rpm |
| Power consumption | 1200 W |
| Voltage | 230 V - 50 Hz |
| Weight | 2.1 kg |
| Dimensions (L x W x H) | 270 x 110 x 90 mm |
| Spindle thread | M14 |
| Main functions | Grinding, cutting, sanding |
| Restart protection | Yes |
| Speed regulator | No |
| Spindle lock | Yes |
| Auxiliary handle | Removable, with vibration damper |
| Adjustable guard | Yes |
| Safety switch | Yes, slide switch |
| Vibration level (grinding) | < 5 m/s² |
| Sound pressure level | 85 dB(A) |
| Maintenance | Clean ventilation slots, replace carbon brushes |
| Spare parts available | Carbon brushes, guard, handle, discs |
| Repairability | Repairability index not provided (manual included) |
| Included accessories | Auxiliary handle, protective guard, pin wrench |
Frequently Asked Questions - L 15-11 125 Flex
What is the maximum disc diameter for the Flex L 15-11 125?
The maximum disc diameter is 125 mm.
How to change the grinding disc?
Press the spindle lock button, then unscrew the clamping nut using the supplied wrench. Replace the disc and retighten the nut.
Does the grinder have restart protection?
Yes, the Flex L 15-11 125 is equipped with restart protection after a power failure.
What is the power of this grinder?
The power consumption is 1200 W.
Is the speed variable?
No, this grinder is not equipped with a speed regulator. The no-load speed is fixed at 11000 rpm.
How to maintain the grinder?
Regularly clean the ventilation slots with a soft brush. Replace the carbon brushes when their length is less than 5 mm.
What accessories are supplied with the grinder?
The grinder comes with an auxiliary handle, a protective guard, and a pin wrench.
What is the maintenance frequency for carbon brushes?
Check the carbon brushes after approximately 50 hours of use or as soon as excessive sparks appear.
Can I use the grinder for cutting metal?
Yes, with a cutting disc suitable for the 125 mm diameter, it can cut metal and other materials.
Where to find the complete user manual?
The complete manual is available for free at notice-facile.com in PDF format.
