Product Type	Waterproof Compact Digital Camera
Brand	PENTAX
Model	OPTIO WPI
Dimensions (W x H x D)	102 x 51 x 22 mm
Weight (without battery or card)	120 g
Weight in working order	135 g
Power supply	Rechargeable lithium-ion battery D-LI8 (supplied); AC adapter D-AC8 (optional)
Sensor	CCD 1/2.5 inch, 6.36 total megapixels, 6.0 effective megapixels
Lens	3x optical zoom, 6.3-18.9 mm (equiv. 38-114 mm in 35 mm), aperture f/3.3-4
LCD screen	2 inch, TFT color, approx. 115,000 pixels
Water resistance	JIS Class 8 water (IP58), immersion up to 1.5 m for 30 minutes; JIS Class 5 dust
Main functions	Shooting modes (program, green, night, underwater, etc.), video recording (MOV), voice memo, stabilisation, built-in flash, self-timer, burst
Memory	Internal memory approx. 10.5 MB; compatible SD memory card
File formats	Photos: JPEG (Exif 2.2); videos: MOV (Motion JPEG); audio: WAV
Photo resolution	Up to 2816 x 2112 pixels (6M)
Video resolution	Up to 320 x 240 pixels at 30 fps
Battery life (CIPA)	Approx. 200 photos; playback: 240 min; video: 80 min
Maintenance and cleaning	Wipe with a dry cloth; do not use solvents or alcohol; rinse with clean water after use in salty environments
Safety	Do not disassemble, avoid shock, do not use with non-rechargeable batteries, respect operating temperatures (0-40°C)
Spare parts and repairability	Battery D-LI8, charger D-BC8, adapter D-AC8, strap; repair by authorized PENTAX service center
General information	12-month warranty; compatible with PictBridge, PRINT Image Matching III; manufactured by PENTAX Corporation

Frequently Asked Questions - OPTIO WPI PENTAX

Can I use the camera underwater?

Yes, the Optio WPI is waterproof according to JIS Class 8 (IP58). It can be used underwater up to 1.5 meters for a maximum of 30 minutes. Make sure to close the battery/card compartment properly and do not open the cover underwater.

What is the battery life?

With a fully charged D-LI8 battery, you can take approximately 200 photos (according to CIPA standard). In playback mode, battery life is about 240 minutes, and about 80 minutes for video recording. Performance may vary depending on usage conditions.

How to clean the camera after use at the seaside?

After use in a salty environment, turn off the camera, make sure the battery/card compartment is properly closed, then rinse it under running water or immerse it in a bowl of clean water for a few minutes. Wipe it with a dry cloth. Do not use chemicals such as alcohol or soap.

What types of memory cards are compatible?

The camera accepts SD memory cards (Secure Digital). It is not compatible with SDHC, SDXC or other formats. The maximum supported capacity is 2 GB.

How to reset to default settings?

In the [Settings] menu, select Reset. This will restore factory settings, except for date, time, language, and world time settings.

Can I use the camera as a webcam?

No, the Optio WPI is not designed to be used as a webcam. It does not offer a live video connection mode to a computer.

What is the maximum photo resolution?

The maximum resolution is 2816 x 2112 pixels, approximately 6 megapixels. You can choose from several sizes in the Recorded Pixels menu.

How to transfer photos to a computer?

Use the USB cable provided to connect the camera to the computer. Set the USB connection mode to PC in the [Settings] menu. The computer will recognize the camera as a removable drive.

Does the camera have a flash?

Yes, it has a built-in flash with several modes: auto, forced, off, red-eye reduction, and slow sync. The range is approximately 0.2 to 3.1 m at wide angle and 0.5 to 2.5 m at telephoto.

What to do if the camera does not turn on?

First, check that the battery is charged and properly inserted. If the problem persists, remove the battery and memory card, wait a few minutes, then reinsert them. If the camera still does not turn on, contact an authorized PENTAX repair center.

USER MANUAL OPTIO WPI PENTAX

Silver Pentax digital camera with waterproof and megapixel buttons (no visible text beyond branding)

Illustration of two people relaxing in water near a beach with a sailboat and clouds (no text or symbols)

Illustration of a hand holding a smartphone displaying a heart-shaped logo next to a sitting dog (no text or symbols present)

Illustration of a smiling woman using a smartphone to scan a photo with a digital display showing flower patterns (no text or symbols)

Line drawing of a portable OPPO camera with control buttons and lens (no text or symbols)

Appareil photo OptioWPi

Line drawing of a U-shaped object with a loop handle and clasp (no text or symbols)

Courroie O-ST20 (*)

Simple line drawing of a circular object with concentric rings (no text or symbols)

Line drawing of a cable with connectors and connectors (no text or symbols)

Câble USB I-USB7 (*)

Line drawing of a coiled electrical probe with two connectors (no text or symbols)

Câble AV I-AVC7 (*)

Batterie lithium-ion rechargeable D-LI8 (*)

Line drawing of a Pentax device housing with ports and mounting holes (no text or symbols on body)

Coiled electrical plug with three terminal connectors (no text or symbols visible)

Black-and-white beach scene with palm trees, a distant hill, and a small camera icon (no readable text or symbols)

Black-and-white beach scene with palm trees and a distant hilltop, captured by a camera lens (no text or symbols visible)

Black-and-white beach scene with palm trees and a person, no visible text or symbols

Black and white close-up of flower buds with blurred background (no text or symbols)

Black-and-white beach scene with palm trees and a distant island, no visible text or symbols

Black-and-white beach scene with palm trees and a distant building, no visible text or symbols

MENU

Black-and-white beach scene with palm trees and ocean, no visible text or symbols

Black-and-white beach scene with palm trees and distant buildings, no visible text or symbols

Black-and-white beach scene with palm trees, a distant island, and camera interface elements (no readable text or symbols)

Nighttime cityscape featuring illuminated skyscrapers and a prominent tower (no visible text or signage)

③ Vidéo

Black-and-white landscape photo of a river valley with steep cliffs and forested banks (no visible text or symbols)

⑦ Fleur

Black and white close-up of a sunflower with visible petals and center (no text or symbols)

⑧ Portrait

Black-and-white portrait of a woman with long hair, wearing a sleeveless top (no text or symbols visible)

⑨

Sous-marin

Black-and-white photo of a striped fish swimming on sandy ground (no text or symbols visible)

Black-and-white beach scene with a distant vehicle on the water and cloudy sky (no text or symbols visible)

Black-and-white photo of a child kicking up a soccer ball on grass (no text or symbols visible)

Black-and-white photo of two young girls sitting outdoors, one holding a spoon (no text or symbols visible)

Black and white photo of a fluffy dog (no text or symbols visible)

Black-and-white photo of three lit candles in a circular arrangement, possibly candles or lights, with no visible text or symbols.

⑮ SOFT Doux

Black-and-white photo of a plush toy bear holding flowers (no text or symbols visible)

⑯ Aide panorama

Black and white photo of a fireworks display with multiple bright spikes against a dark background (no text or symbols visible)

⑲ Ton chair naturel

Black-and-white photo of two smiling young women (no text or symbols visible)

20 Gastronomie

Black-and-white portrait of a woman with long hair (no text or symbols visible)

⑳ Musée

Black-and-white photo of a plated dish with various dishes and garnishes on a wooden table (no visible text or symbols)

Black-and-white photo of a framed landscape painting on a wall, featuring mountains and trees (no text or symbols visible)

Black-and-white photo of a wooden pier with a pavilion on calm water, labeled 'Mode Vert' and 'Correction IL' (no other text or symbols)

Black-and-white photo of a wooden pier with a gazebo on calm water, no visible text or symbols

Black-and-white beach scene with palm trees, a distant building, and a shoreline (no visible text or symbols)

Black-and-white beach scene with palm trees, a small island, and a camera interface overlay (no readable text or symbols)

Black-and-white photo of a dog resting on a wooden structure, with no visible text or symbols.

Black-and-white photo of a dog resting on a wooden structure, no visible text or symbols

Black-and-white cityscape photo showing waterfront scene with buildings and streetlights (no readable text or symbols)

Black-and-white photo of a road with a tall building and a camera frame, timestamped 25/09/2005 (no readable text or symbols on the main subject)

Black-and-white photo of a dog inside a heart-shaped frame, captured in a photo frame (no visible text or symbols)

Utilisation du zoom

Black-and-white photo of a coastal town with trees and hills, no visible text or symbols

Histogramme + Info

Camera exposure settings interface showing aperture, shutter speed, and exposure parameters (no readable text or symbols in the image)

Black-and-white beach scene with palm trees, a small boat, and a hand icon (no text or symbols)

Silhouette of a mountain peak against a plain gray background (no text or symbols)

Image correcte

Silhouette of a mountain peak against a plain gray background (no text or symbols)

Image lumineuse

Silhouette of a mountain peak against a plain gray background (no text or symbols)

Black and white photo of a wooden pier with a pavilion on calm water, no visible text or symbols

Black-and-white photo of a wooden pavilion by a lake, no visible text or symbols on the image itself.

Black-and-white photo of a wooden pier at dusk with a gazebo and porthole, no visible text or symbols

Indicateur MF

Black and white photo of a dolphin leaping out of water, with no visible text or symbols on the image itself.

Exterior view of a modern building with a curved roof and adjacent structure, surrounded by trees (no signage or text visible)

Black and white photo of a dolphin leaping out of water, captured in a camera app interface (no readable text or symbols on the image itself)

Grid of six black-and-white beach and beach photos with location markers, no visible text or symbols

Black-and-white photo of a beach scene with directional arrows and UI controls (no readable text or symbols)

Black-and-white photo of a wooden pier by the sea, no visible text or symbols

Black-and-white photo of a wooden pier by the sea, with no visible text or symbols in the main scene.

Black-and-white photo of a wooden pier with a gabled pavilion on calm water, no visible text or symbols

Affichage du menu [✗️ Réglages]

Black-and-white beach scene with palm trees and distant hills under a cloudy sky (no text or symbols visible)

Grayscale abstract pattern with radial symmetry and central arrow (no text or symbols)

Batterie lithium-ion rechargeable D-LI8 (\*)

For customers in USA

STATEMENT OF FCC COMPLIANCE

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Changes or modifications not approved by the party responsible for compliance could void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

* Consult the dealer or an experienced radio/TV technician for help.

For customers in Canada

This Class B digital apparatus meets all requirements of the Canadian Interference - Causing Equipment Regulations.

Declaration of Conformity

According to 47CFR, Parts 2 and 15 for

Class B Personal Computers and Peripherals

We: PENTAX Imaging Company A Division of PENTAX of America, Inc.

Located at: 600 12 ^th Street, Suite 300 Golden, Colorado 80401 U.S.A. Phone: [phone] FAX: [phone]

Declare under sole responsibility that the product identified herein complies with 47CFR Parts 2 and 15 of the FCC rules as a Class B digital device. Each product marketed is identical to the representative unit tested and found to be compliant with the standards. Records maintained continue to reflect the equipment being produced can be expected to be within the variation accepted, due to quantity production and testing on the statistical basis as required by 47CFR §2.909.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. The above named party is responsible for ensuring that the equipment complies with the standards of 47CFR §15.101 to §15.109.

Product Name: PENTAX Digital Still Camera

Model Number: OptioWPi

Contact person: Customer Service Manager

Date and Place: September, 2005, Colorado

Autofocus (AF) AF 81
