Attraxion Quick 5540 - Nail Clipper OBH NORDICA - Free user manual and instructions

Brand	OBH Nordica
Model	Attraxion Quick 5540
Product Type	Rechargeable Cordless Hair Clipper
Power Supply	100-240 V AC adapter, 3V DC, 1000 mA
Battery	2 rechargeable AA Ni-MH 1.2V, 600 mAh
Charging Time	16 hours for full charge (cordless use)
Running Time	Approximately 45 minutes
Cutting Length Range	4 - 34 mm (with distance combs); 0.9 mm without comb
Adjustment Steps	9 steps: 4, 8, 12, 16, 19, 23, 27, 31, 34 mm
Thinning Function	Yes, via thinning comb button
Included Accessories	2 distance combs, cleaning brush, oil, scissors, comb
Signal Lamp	Red when charging, green when fully charged
Safety Features	Keep dry, do not use with wet hands, unplug when not in use, supervision for children under 8
Cleaning	Remove comb and trimmer head, brush hair, wash combs with mild detergent; do not immerse in water
Maintenance	Oil blades regularly with enclosed oil
Battery Disposal	Remove batteries before disposal; dispose separately at authorized collection point
Environmental Disposal	Do not dispose with household waste; follow local regulations for electronic equipment
Compliance	CE marked
Warranty	According to current law; keep cash receipt
Manufacturer	OBH Nordica Denmark A/S, Ole Lippmanns Vej 1, 2630 Taastrup, Denmark

Frequently Asked Questions - Attraxion Quick 5540 OBH NORDICA

How do I charge the Attraxion Quick 5540?

Connect the adapter to the appliance and plug into a wall outlet. The signal lamp will flash red during charging and turn green when fully charged. Ensure the appliance is switched off during charging. For full cordless use, charge for at least 16 hours.

Can I use the clipper while charging?

Yes, you can use the clipper with the adapter connected. Make sure the appliance is switched off before connecting, wait a few seconds, then turn it on. If it does not work immediately, let it charge for about 1 minute.

How do I adjust the cutting length?

Attach the desired distance comb (4-34 mm) by pressing it onto the appliance until it clicks. Then use the adjustment button above the switch to set the precise length, indicated by an arrow on the side of the comb. Start with a longer comb to avoid cutting too much.

How do I use the thinning function?

Push the button on the thinning comb (button 2) to the left. This will position the thinning comb in front of the trimming head. Then proceed to cut as normal.

How do I clean the clipper?

Always switch off and unplug the appliance before cleaning. Remove the distance comb and trimmer head. Clean the combs with water and mild detergent. Use the enclosed brush to remove hair from the trimmer head and inside the appliance. Do not immerse the appliance or adapter in water.

How often should I oil the blades?

Oil the cutting blades regularly to maintain performance. To oil, remove the trimmer head, carefully spread the blades, and add 2-3 drops of the enclosed oil. Replace the trimmer head and run the clipper briefly to distribute the oil. Wipe off excess with a paper towel. Keep oil out of reach of children.

What should I do if the clipper slows down?

Check if hair is stuck in the comb or trimmer head. Switch off the appliance and remove the hair. If the problem persists, the batteries may need charging. Recharge the appliance for about 12 hours.

How do I replace the batteries?

Remove the distance comb and trimmer head. Unscrew the two screws at the bottom of the housing. Separate the housing and remove the old batteries. Dispose of them properly. Install new rechargeable AA Ni-MH 1.2V batteries. Reassemble the housing.

Can I use the clipper on wet hair?

No, the hair should be washed, combed, and dried before use. Wet hair makes it harder to pass the comb through and may affect performance. The appliance must be kept dry.

What is covered by the warranty?

Warranty according to current law. Claims must be accompanied by the cash receipt with purchase date. The appliance should be returned to the store of purchase. Damages from improper use or not following the instruction manual are not covered.

USER MANUAL Attraxion Quick 5540 OBH NORDICA

Type 5540

attraxion quick trim

Rechargeable cordless

Cutting length: 4-34 mm

Running time 45 min

Thinning function

Battery LED

Hair comb and scissor

OBH Nordica Denmark A/S

Ole Lippmanns Vej 1

2630 Taastrup

Tlf.: 43 350 350

www.obhnordica.dk

Tekniske data

OBH Nordica 5540

100-240 V AC adapter, 3V DC, 1000 mA

2 trimmere

Udtyndingsfunktion

OBH Nordica Norway AS

Postboks 5334, Majorstuen

0304 Oslo

Tlf: 22 96 39 30

www.obhnordica.no

Tekniske data

OBH Nordica 5540

100-240 V AC adapter, 3 V DC, 1000 mA

2 distansekammer

Uttynningskam

OBH Nordica AttraXion Quick Trim Hair Clipper

Safety instructions

1. Read the instruction manual carefully before use and save it for future use.
2. Plug the appliance to a household outlet of 100-240 V only and use the appliance only for the intended use.
3. Always unplug the appliance from the mains supply when not in use.
4. This appliance can be used by persons (including children from the age of 8) with reduced physical, sensory or mental capabilities or lack of experience with/knowledge about the appliance, if they have been given supervision or instructions concerning the use of the appliance by a person responsible for their safety and when they are aware of possible risks.
5. Children should be supervised to ensure that they do not play with the appliance. Children are not always able to understand potential risks. Teach children a responsible handling of electrical appliances.
6. Cleaning and maintenance shall not be made by children under the age of 8 and they shall be supervised.
7. Keep the appliance and the cord out of the reach of children under the age of 8.
8. Check that the cord is not hanging free from the edge of the table.
9. Do not place the appliance on or near hotplates, open fire or the like.
10. Do not touch the adapter with humid or wet hands.
11. WARNING! Keep the appliance dry.
12. The appliance should only be used under supervision.
13. The appliance is not for outdoor use.
14. Only use the original adapter.
15. Store the adapter in a dry and frost free place.
16. Remove the batteries from the appliance before disposal of the appliance.
17. Unplug before you remove the batteries from the appliance.
18. In case of battery leakage, avoid any contact with your skin

and dispose of the batteries according to current law.

1. Always check the appliance, the cord and the switch before use. If the cord is damaged, it must be replaced by the manufacturer, an authorized service agent or a similarly qualified person in order to avoid a hazard.
2. Extra protection can be obtained by installation of a residual current device of 30mA. Check with your installer.
3. The appliance is for domestic use only.
4. If the appliance is used for other purposes than intended, or is it not handled in accordance with the instruction manual, the full responsibility for any consequences will rest with the user. Any damages as a consequence of the above to the product are not covered by the warranty.

Before use

Make sure that the appliance is fully loaded before use, if it should be used without the adapter.

Parts of the appliance (see fig. 3)

1. Trimming head
2. Button for thinning comb
3. Button for adjustment of cutting length
4. On/off button
5. Signal lamp
6. Loading adapter (not shown in picture)
7. Distance comb 2 units
8. Oil
9. Cleaning brush
10. Scissor
11. Comb

Loading:

1. Connect the switch of the adapter to the outlet at the short end of the appliance.
2. Connect the adapter switch to the wall outlet.
3. When the batteries are being charged the signal lamp will go on and flash with a red light. When a full charging has been obtained, the colour of the signal lamp changes to green.
4. Make sure that the appliance is switched off during charging.

If the appliance is to be used without the adapter, at least 16 hours of charging of the appliance is necessary. When the appliance has been fully charged, you can run the appliance without the cord for about 45 minutes (depending on the type of hair). Subsequently, the batteries should be recharged about 12 hours after each charging..

How to use the adapter

Connect the switch of the adapter to the outlet of the appliance and plug the adapter to a wall outlet. Make sure that the appliance is disconnected when activated and wait a few seconds before you switch it on. If the appliance does not work right away, let it charge for about 1 minute. Make sure that the appliance is shut off during charging.

Use

- Make sure that the appliance is clean, fully recharged or connected to the adapter and ready for use. Make sure to oil the cutting blade regularly to maintain a good performance (see further "Cleaning and maintenance").

- The hair should be washed, combed and dried (wet hair will make it harder to pass the comb through the hair).

- Choose the distance comb that corresponds to the length of hair you want (4, 8, 12, 16, 19, 23, 27, 31 or 34 mm). We recommend that you start with a long comb the first time to prevent cutting off too much. The measurements are marked on the combs.

- Press the comb onto the appliance and make sure that the blades of the comb click into the notches on each side of the appliance. The appliance can also be used without the distance comb if you want a shaved result (see further under "Use without distance comb").

- Set the desired length by means of the adjustment button placed above the switch. The chosen length is marked with an arrow above the notches on the side on the comb.

- If you just want to thin the hair, push the button (2) on the thinning comb to the left. Now the thinning comb will be in front of the trimming head.

- Next, switch on the hair cutter by pushing the switch upwards.

- Hold the appliance with the trimming head upwards to have the flat side of the trimmer face towards the head. Start at the neck and move the hair clipper in short, soft movements upwards and outwards. Work your way up to the top of the head and continue with the next section. Take your time and stop and check the result from time to time and comb the hair regularly to remove loose hair.

- If the hair clipper starts to work slower, check for hair being stuck in the comb/trimmer head. Shut off the appliance and remove all hair before you start again. The problem may even be due to the fact that the batteries need charging, if the appliance no longer works.

- For trimming around the ears and lower neck you might need to change to a shorter comb or remove the comb and use the trimming head only.

Use without distance comb

If you want a cropped result (0.9 mm), you can use the appliance without a distance comb and only use the trimming head.

Turn on the appliance by means of the switch. Hold the appliance with the trimming head upwards to have the flat side of the trimmer face towards the head. Start at the neck and move the hair clipper in short, soft movements upwards. Work your way up to the top of the head and continue with the next section. Be extra careful around the ears. Switch off the appliance by means of the switch after cutting.

Cutting by means of fingers/comb

• Use your fingers and/or comb to cut hair sections longer than 34 cm.
• Remove the distance comb from the clipper by pulling the comb straight upwards.
• Lift a hair section with an ordinary comb or hold it between your fingers to have excess hair stick up over your fingers.
• Cut off the hair with the hair clipper. Continue in this way until the wanted length has been obtained.
• Comb regularly to remove loose hair and to check the result.

Cleaning and maintenance

• Always shut off the clipper and disconnect it from the adapter before cleaning.
- Never immerse the appliance or the adapter in water or other liquids.
- Remove the distance comb from the appliance by pulling the comb straight upwards.
- The distance combs should be cleaned with water and a little mild detergent.
- Remove hair from the trimming head with the enclosed brush.
- The trimming head can be removed for cleaning by pulling the trimming head backwards. Next, brush hair from the trimming head and inside the appliance. Press the trimming head back until it engages with a click.
- Never try to sharpen the cutting blades yourself.

How to oil the cutting blades

• The cutting blades should be oiled regularly to maintain the performance.
• Pull the trimming head backwards to remove it from the appliance. Carefully spread the cutting blades and add 2-3 drops of the enclosed oil on the cutting blades.

- Pull back the trimming head and switch on the hair clipper in order to spread the oil. Dry off excess oil with paper towel.

NOTE! The enclosed oil can be dangerous to consume and should be kept out of reach of children.

Disposal of appliance and batteries

The hair clipper is equipped with 2 rechargeable AA Ni-MH 1,2V batteries. When it is no longer possible to recharge the batteries or if they discharge relatively quickly, remove the batteries and dispose of the appliance.

How to remove the batteries:

• Remove the distance comb and the trimming head in accordance with the instructions above in section "Cleaning and maintenance", from the appliance. Unscrew the two screws at the bottom part that holds together the housing.
• Separate the housing and remove the batteries. Dispose of the batteries in accordance with the instructions in "Environmental considerations at disposal of batteries"

Environmental considerations at disposal of batteries

When substituting batteries it is essential to take the environment into consideration. Used batteries must never be disposed of with domestic garbage, but should be returned to an authorized collection point. Batteries must be removed from the appliance before it is disposed of. Also take care that the batteries have not expired or have become worn-out, since there may be a risk that the batteries will leak. Check the validity date on the batteries. Remember to remove the batteries before they get too old.

Disposal of the appliance

Legislation requires that all electrical and electronic equipment shall be collected for reuse and recycling. Electrical and electronic equipment marked with the symbol indicating separate collection of such equipment must be returned to a municipal waste collection point.

Complaint

Warranty according to current law. Any claim shall be accompanied by the cash receipt with purchase date. When raising a claim the appliance must be returned to the store of purchase.

OBH Nordica AB

Löfströms allé 5

SE-172 55 Sundbyberg

Tel [phone]

www.obhnordica.se

Technical data

OBH Nordica 5540

100-240 V AC adapter, 3V DC, 1000 mA

2 distance combs

Thinning function

Cleaning brush, oil

2 rechargeable AA 600 mAh Ni-Mh 1,2V batteries.

CE

These instructions are subject to alterations or improvements.
