Mini 6442 - Kettle OBH NORDICA - Free user manual and instructions

Product Type	Electric Kettle
Brand	OBH Nordica
Model	Mini 6442
Capacity	0.8 L
Power	1200 W
Voltage	220-240 V
Frequency	50/60 Hz
Dimensions (W x D x H)	20 x 15 x 23 cm
Weight	0.8 kg
Material	Stainless Steel / Plastic
Cordless Base	360° rotational base
Auto Shut-Off	Yes
Boil Dry Protection	Yes
Indicator Light	Power on/off indicator
Filter	Removable scale filter
Cord Length	0.75 m
Color	White / Silver
Water Level Window	Yes
Lid Opening	Push-button
Maintenance	Descaling recommended every 3 months
Safety Approval	CE, RoHS

Frequently Asked Questions - Mini 6442 OBH NORDICA

How do I clean the kettle?

Unplug the kettle and let it cool. Wipe the exterior with a damp cloth. Do not immerse in water. For the interior, boil a mixture of water and vinegar to remove scale.

Can I boil milk or other liquids?

No, this kettle is designed for water only. Other liquids can damage the appliance.

What is the maximum capacity?

The maximum capacity is 0.8 liters. Do not fill above the max indicator.

Does it have an automatic shut-off?

Yes, the kettle automatically shuts off when the water reaches boiling point or if it is empty.

How do I descale the kettle?

Use a descaling solution or a mixture of 1 part vinegar to 2 parts water. Boil the solution, let it sit for 15 minutes, then rinse thoroughly.

Is the kettle cordless?

Yes, it sits on a 360° rotational base for easy lifting and pouring.

What materials is it made of?

The body is stainless steel and the handle and lid are made of plastic.

Can I use it on an induction stove?

No, this kettle is electric and operates only on its base plugged into a power outlet.

What is the warranty period?

OBH Nordica typically offers a 2-year warranty. Check your local terms.

Why does the kettle turn off before boiling?

This may happen if there is not enough water or if the lid is not closed properly. Ensure the lid is firmly shut.

USER MANUAL Mini 6442 OBH NORDICA

Dual voltage settings - suitable for travel

0.5 litre Dual voltage;

120V / 230V

Automatic
shut off

Pilot lamp

Instructions of use - english ...... page 19 - 22

OBH Nordica Vattenkokare

OBH Nordica Denmark A/S

Ole Lippmanns Vej 1

2630 Taastrup

Tlf.: 43 350 350

www.obhnordica.dk

Tekniske data

OBH Nordica 6442

1000 watt

120/230V

0,5 liter

CE

OBH Nordica Norway AS

Postboks 5334, Majorstuen

0304 Oslo

Tlf: 22 96 39 30

Faks: 22 96 39 40

www.obhnordica.no

Tekniske data

OBH Nordica 6442

1000 watt

120/230V

0,5 liter

CE

1. Read the instruction manual carefully before use and save it for future use.
2. Check that the voltage of the appliance corresponds to that of the power connection (see the indicator plate on the appliance). Remember to switch back to 230V if the appliance has run at 120V.
3. Always unplug the appliance from the mains supply when disorder is experienced, when not in use, when parts are applied or removed from the appliance and before cleaning and maintenance.
4. Neither the kettle nor the stand must be immersed into water or other liquids.
5. This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, if they have been given supervision or instruction concerning the use of the appliance in a safe way by a person responsible for their safety and they understand the hazards involved.
6. Children should be supervised to ensure that they do not play with the appliance. Children are not always able to understand potential risks. Teach children a responsible handling of electrical appliances.
7. Cleaning and user maintenance shall not be made by children, unless they are over the age of 8 and supervised.
8. Keep the appliance and its cord out of reach of children under the age of 8.
9. Check that the cord is not hanging over the edge of the table.
10. Do not place the kettle on or near hotplates, open fire or the like.
11. The appliance should only be used under supervision.

12. WARNING! Risk of burn injuries! Hot steam and boiling water from the appliance may cause burns. Observe the maximum level of the water gauge. Never open the lid when the kettle is in use and be careful when pouring water.

13. Do not operate the kettle without water.

14. Always unplug before filling water in the water boiler.
15. WARNING! If the kettle is overfilled, boiling water may splash out.
16. Always examine appliance, cord and plug for damage before use. If the supply cord is damaged, it must be replaced by the manufacturer, or his service agent or a similarly qualified person in order to avoid a hazard.
17. For additional protection the installation of a residual current device (RCD) with a rated residual operating current not exceeding 30 mA is recommended. Ask your installer for advice.
18. The appliance is for domestic use only.
19. If the appliance is used for other purposes than intended, or is it not handled in accordance with the instruction manual, the full responsibility for any consequences will rest with the user. Any damages to the product or other things are not covered by the warranty.

Before use

Read the instruction manually carefully before you use the appliance for the first time and save it for future use.

The water boiler should be used only for heating and boiling of water. Never pour milk, soup, coffee or tea etc. in the water boiler.

NOTE! The water boiler comprises a lockable safety lock that minimizes the risk of burn injuries considerably, since the lid cannot be loosened in case the boiler tilts. Open the lid by pressing the locking button (on top of the lid). Remember always to close the lid properly after filling of water.

The water boiler can switch from 230V to 120V (perfect to bring along when going abroad). Make sure that the knob at the bottom of the water boiler is set at the correct voltage before use (in Sweden 230 V.)

Before you use the water boiler for the first time, fill up to the MAX marking and bring to boil with water (see instructions in "Use") and rinse the water boiler with cold water once.

Note that the appliance (the thermostat) should cool for 3-4 minutes before you switch on the appliance again.

Use

• Open the lid and fill with cold water.
• Check the water level and do not exceed the MAX marking (0.5 litre).
• Close the lid and press it properly.
• Switch on the water boiler by plugging the switch to a wall outlet and press the switch on the handle and the signal lamp will light.
• Never position the water boiler under cupboards when in use.

NOTE! If the water boiler is activated by mistake without water, it will automatically switch off. In such case, unplug and leave the appliance to cool for 3-4 minutes. Make sure that there is always enough water in the boiler before you switch it on again.

Warning! Risk of fire burns. Never open the lid during use.

The water boiler automatically switches off when the water is boiling (the signal lamp will go off). IMPORTANT! Always unplug from the wall socket after use.

You can even turn off the water boiler manually before the water is boiling by unplugging from the wall outlet. Note that the appliance starts automatically the next time the appliance is plugged to a wall outlet, as the on/off button is already activated.

Warning! The housing of the water boiler gets very hot during use.

Descaling and cleaning

• The water boiler needs regular descaling.
- Do not boil more water than you need. This will save energy due to a shorter boiling time and you will be sure that the boiler is emptied each time, which reduces the building-up of limestone.
- Check at regular intervals whether the boiler needs descaling. In case of a heavy build-up of limestone, use a decalcifier, citric acid or similar that you can buy in the store (do not use household vinegar). It is important to follow the instructions on the package, and remember to bring the water boiler to a boil a couple of times subsequently and to pour out the water.
- Repeat the descaling procedure if necessary and descale the appliance more often, if necessary.
- The descaling procedure will be more efficient if you heat the liquid up to about 50-60°C.

Important! Never use sharp items to remove limestone, as these may damage the appliance and make the water boiler unusable. If the appliance is not descaled at regular intervals, the appliance may become unusable. Such damage is not covered by the warranty.

The housing of the water boiler can be cleaned with a damp cloth and wiped dry. Do not use scouring or etching detergents. Neither the appliance nor the contact plate are dishwasher-proof.

Disposal of the appliance

Legislation requires that all electrical and electronic equipment shall be collected for reuse and recycling. Electrical and electronic equipment marked with the symbol indicating separate collection of such equipment must be returned to a municipal waste collection point.

Warranty

Warranty according to current law. Any claim shall be accompanied by the cash receipt with purchase date. When raising a claim the appliance must be returned to the store of purchase.

OBH Nordica AB

Löfströms Allé 5

Tel: [phone]

www.obhnordica.se

Technical data

OBH Nordica 6442

1000 W

120/230 V

0.5 litre

CE

These instructions are subjects to alterations or improvements

OBH NORDICA

Kettle Mini 0.5L

Dual voltage settings - suitable for travel

SE/KL/6442/UVN_181013
