Product Type	Horizontal Freezer
Brand	Orima
Model	ORS 129 C
Energy Efficiency Class	A+
Annual Energy Consumption	168 kWh/year
Total Gross Volume	102 L
Climate Class	ST
Noise Level	41 dB(A)
Dimensions (H x W x D)	850 x 565 x 523 mm
Net Weight	Approx. 28 kg
Power Supply	220-240 V / 50 Hz
Temperature Control	Adjustable thermostat (-18°C to -24°C)
Defrosting	Manual
Interior Light	Not included
Lock	Yes
Refrigerant	R600a
CFC-Free	Yes
Warranty	See documentation for details

Frequently Asked Questions - ORS 129 C Orima

How do I defrost my Orima ORS 129 C freezer?

To defrost, unplug the freezer and remove all food. Leave the lid open to allow ice to melt. Do not use sharp objects to scrape ice. Clean and dry before use.

What is the annual energy consumption of the ORS 129 C?

The annual energy consumption is 168 kWh per year, based on standard test conditions.

How do I adjust the temperature?

Turn the thermostat dial located on the control panel. The higher the number, the colder the temperature. Usually, setting 3-4 is recommended for normal use.

Why is my freezer making noise?

Noise can be caused by the compressor running, refrigerant flow, or vibration. Ensure the freezer is on a level surface and not touching walls. Some noise is normal.

Can I use an extension cord with this freezer?

It is not recommended to use an extension cord due to fire hazard. Plug the freezer directly into a properly grounded outlet.

How do I clean the freezer?

Unplug the freezer, remove food, and clean the interior with a mild detergent and warm water. Rinse and dry thoroughly. Clean the exterior with a damp cloth.

What should I do if the power goes out?

Keep the lid closed as much as possible. A full freezer will keep food frozen for about 24 hours. Do not refreeze thawed food.

Is the ORS 129 C lockable?

Yes, the freezer has a lock to secure the lid for safety, especially to prevent children from climbing inside.

What is the warranty for Orima freezers?

Warranty details are provided in the documentation. Typically, Orima offers a limited warranty. Contact the retailer or Orima support for specifics.

How to properly dispose of the freezer?

Do not dispose with household waste. Use a designated collection point for electrical appliances, as per local regulations, to ensure proper recycling of materials.

USER MANUAL ORS 129 C Orima

MANUAL DE INSTRUÇÕES

INSTRUCTION MANUAL

Congelador Horizontal

Horizontal Freezer

White rectangular refrigerator with control panel and indicator lights (no visible text or symbols)

ORS 258 C / ORS 185 C /

ORS 129 C

Black-and-white photo of a woman sitting cross-legged outdoors under a bright sky (no text or symbols visible)

SERVICO DE APOIO A CLIENTES

PROBLEMAS E SOLUÇÕES

Before using your product, please read this manual carefully and keep it for future reference.

White refrigerator with open lid and ventilation grille, shown with mounting points (no text or symbols visible)

▶

▶

□

Model	ORS 129 C
Total Gross Volume, L	102
The current consumption depends on how the appliance is used and its location
Energy efficiency class	A+
Energy consumption: kWh/year	168
Climate Class ST
Dimensions (H x W x D), mm	850*565*523
Noise Level, db(A) re 1pw	41
Electrical Information	Check Rating Label
Note: The manufacturer reserves the right to make future changes in specifications and Technical parameters.

Model	ORS 185 C
Total Gross Volume, L	146
The current consumption depends on how the appliance is used and its location
Energy efficiency class	A+
Energy consumption: kWh/year 190
Climate Class	ST
Dimensions (H x W x D), mm	850*730*523
Noise Level, db(A) re 1pw	41
Electrical Information	Check Rating Label
Note: The manufacturer reserves the right to make future changes in specifications and Technical parameters

Modelo	ORS 258 C
Total Gross Volume, L	218
The current consumption depends on how the appliance is used and its location
Classe de eficiência energética	A+
Energy consumption: kWh/year	219
Climate Class	ST
Dimensions (H x W x D), mm 850*945*523
Noise Level, db(A) re 1pw	41
Electrical Information	Check Rating Label
Note: The manufacturer reserves the right to make future changes in specifications and Technical parameters

9

Correct Disposal of this product

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recyclin
