AttraXion - Electric Blanket / Heating Pad OBH NORDICA - Free user manual and instructions

Product Type	Electric Heating Plaid / Blanket
Brand	OBH Nordica
Model	AttraXion (4090, 4091)
Dimensions	160 x 120 cm (63 x 47 in)
Power Supply	230-240 V AC, 150 W
Temperature Settings	9 levels (1 low to 9 high)
Timer Function	Automatic shut-off after 3 hours (±4 min)
Material	Micro plush (100% polyester)
Washing Instructions	Machine wash delicate at 40°C; hand wash possible; do not dry clean, tumble dry, or iron
Washing Frequency	Max 2-3 times per year
Safety System	Electro-block safety system, short circuit and overheating protection
Switch Part Number	F20A1 (removable)
Intended Use	Under plaid only; domestic use
Lifespan	Discard 10 years after purchase date due to safety reasons
Warranty	As per current law; contact store of purchase with receipt

Frequently Asked Questions - AttraXion OBH NORDICA

How do I use the heating plaid for the first time?

Before first use, read the manual carefully. Connect the switch to the plaid's socket, ensure the switch is set to OFF, then plug into a 230-240 V outlet. Turn the switch to 3h and select a temperature from 1 to 9. For optimal warmth, start the appliance at least 10 minutes before use.

What does the timer function do?

The heating plaid has a built-in timer that automatically turns it off after 3 hours (±4 min). To activate, set the switch to 3h. The unit will switch off, and the pilot lamp will blink. You can turn it off earlier by setting the switch to OFF and unplugging.

How should I clean the heating plaid?

Always remove the switch and cord before cleaning. The plaid can be machine washed on a delicate cycle at 40°C or hand washed with mild detergent. Do not dry clean, tumble dry, or iron. Let it drip-dry flat, and do not use until completely dry. Wash only 2-3 times per year.

Can children use this heating plaid?

The plaid should not be used by children unless an adult has set the switch and instructed them properly. Never leave children unsupervised with the appliance. It is not intended for infants or persons insensitive to heat.

What safety features does it have?

The plaid is equipped with an Electro-block safety system that cuts power within milliseconds in case of short circuit or high power consumption. It also has overheating protection. If the safety system activates, the plaid must be disposed of.

How long is the heating plaid safe to use?

For safety reasons, the heating plaid must be discarded 10 years after the purchase date, regardless of usage, due to natural aging. Regularly inspect for wear, damage, or dark spots.

Can I use the heating plaid on a bed?

Yes, the plaid is designed for use as an under plaid on a bed. However, do not place it between the mattress and the bed edge, and avoid folding or creasing it during use. Do not cover the switch with the plaid.

What should I do if the plaid gets extremely hot or shows damage?

If the plaid becomes excessively warm at a low setting, shows discoloration, makes crackling sounds, or has visible damage to the switch, plug, or cord, unplug it immediately and do not use. The plaid may need to be discarded.

How should I store the heating plaid?

Allow the plaid to cool completely before storing. Fold it loosely and place in its original package in a dry place. Do not place heavy items on top that could cause creases and damage the safety system.

Can I repair the heating plaid if it stops working?

No, do not attempt to repair the plaid yourself, as it involves high safety risks. If the supply cord is damaged, it must be replaced by the manufacturer, service agent, or qualified person. For other issues, return to the store of purchase if under warranty.

USER MANUAL AttraXion OBH NORDICA

OBH NORDICA Wellness

heating plaid //

warm & cosy //

Nine temperature settings //

Soft micro plush //

Washable (40°C) //

Fast heating technology //

Timer 3h //

160 x 120cm //

Vigtig information

VIGTIGE OPLYSNINGER – SKAL OPBEVARES TIL FREMTIDIG BRUG

OBH Nordica Denmark A/S

Ole Lippmanns Vej 1

2630 Taastrup

Tlf.: 43 350 350

www.obhnordica.dk

Tekniske data

OBH Nordica 4090, 4091

230-240 V vekselstrøm

150 watt

9 temperatur-indstillinger

Viktig information

VIKTIGA UPPLYSNINGAR!

OBH Nordica Sweden AB

Box 58

163 91 Spånga

Tfn 08-445 79 00

www.obhnordica.se

Tekniska data

OBH Nordica 4090, 4091

Plysch 100% polyester.

Överhettningsskydd

Viktig informasjon

VIKTIGE OPPLYSNINGER - MÅ OPPBEVARES FOR SENERE BRUK

OBH Nordica Norway AS

Postboks 5334, Majorstuen

0304 Oslo

Tlf: 22 96 39 30

www.obhnordica.no

Tekniske data

OBH Nordica 4090, 4091

230-240 V vekselstrøm

150 watt

9 temperaturinnstillinger

Tärkeää

TÄRKEITÄ TIETOJA!

- SÄILYTÄ MYÖHEMPÄÄ TARVETTA VARTEN.

OBH Nordica Heating plaid

Before use

Before you use the appliance for the first time, read the instruction manual carefully, and save it for future use.

This product is equipped with a safety system that within milliseconds cuts the current if there is short circuit or exceptional high power consumption. If the safety system is activated it is not possible to use the product due to safety reasons. The heating plaid should then be disposed according to section “Disposal of the appliance”.

Use

Check that the switch is in off position (OFF) and that the switch and its socket is connected to the plug on the underside of the heating plaid. The heating plaid can only be used with switch supplied.

To reach optimal temperature we recommend that you start the appliance at least 10 minutes before use.

Timer

This heating plaid has a timer function that automatically switches off the unit after 3 hours ( ± 4 min). Connect the plug to the outlet. Push the switch to setting “3h” to start the appliance. Choose temperature 1-9 by turning the temperature regulator, the temperature display illuminates. We recommend that you start at the highest setting (9) and lower if necessary.

When the timer setting has passed the unit switches off and the pilot lamp next to the switch twinkles. If you want to switch off the appliance before the times has passed, set the switch to OFF and unplug the appliance. Note that the switch always should be set to OFF and the appliance should be unplugged when it's not in use.

Settings:

0 = Off
1 = Low heat
2
3
4
5 = Medium heat
6
7
8
9 = Maximum heat

Warning! The heating plaid may not be used by children if the switch is not set by an adult or the child has been thoroughly instructed how you use the switch. Never let children use the heating plaid without supervision. Children are not always able to understand potential risks. Teach children responsible handling of the heating plaid.

Important!

Since the switch gets warm during use it is important that the switch is not covered or placed under the heating plaid during use.

Cleaning and maintenance

Always remove the switch and cord before cleaning. Remove the socket from the heating plaid by pressing the clips on either side of the plug. The heating plaid can be hand washed or machine washed (delicate wash) in 40° C. The heating plaid should only be washed if it is particularly dirty and max 2-3 times a year since too many washes can wear out the product. Small stains and dirt can be washed off with a damp cloth and some mild detergent. Note that the heating plaid may not be dry cleaned.

IMPORTANT!

The switch and cord may not come in contact with water or any other liquids.

If you hand wash the product. Carefully soak the heating plaid into the water with mild detergent. Rinse the heating plaid in clean water afterwards so that all remaining detergent rinses off.

Let the heating plaid drip-dry without wringing or squeezing. Do not tumble dry or iron the heating plaid. Do not start the appliance to make it dry. Place the heating plaid flat and leave it to dry. Do not fasten it with clothespins or similar. The heating plaid may not be used until it's completely dry, otherwise the safety system will automatically shut the heating plaid off.

After cleaning and before each use, check the appliance and its cord for damage.

Safety instructions

IMPORTANT INFORMATION RETAIN FOR FUTURE USE

1. Read the instruction manual carefully before use, and save it for future use.
2. Plug the appliance to a household outlet of 230-240V only, and use the appliance only for the intended use.
3. Always unplug the appliance from the mains supply when not in use.
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
5. Children should be supervised to ensure that they do not play with the appliance. Children are not always able to understand potential risks. Teach children a responsible handling of electrical appliances.
6. The heating plaid should only be used under supervision.
7. Do not use with infants, helpless persons or persons insensitive to heat.

8. To use the appliance continuously during a long time can cause burns on the skin that can appear long after.

9. When not in use, store in the original package in a dry place. When storing the appliance, allow it to cool down before folding.

10. Never pull or carry the heating plaid in the cord.
11. Do not roll up the cord, and do not place the cord over the heating plaid.
12. Do not put the heating plaid in between the mattress and the edge of the bed.
13. Do not use crumpled, folded or rucked.
14. Avoid creasing the heating plaid by placing items on top of it during storage as this can destroy the safety system.
15. Do not insert pins or the like in the heating plaid.
16. Examine the plaid frequently/when changing the linen for signs of wear, damage or dark spots. If such signs are found, the heating plaid must be discarded or returned to the place of purchase for repair.
17. Regardless of the extent of use the appliance must be discarded and disposed of 10 years after the purchase date for safety reasons due to natural ageing of the appliance
18. Under no circumstances must the regulator and cord be immersed into water or other liquids.
19. The heating plaid must not be used in sanitary areas.
20. When washing the heating plaid the instruction manual should be observed.
21. Do not use when humid or wet – wait until the heating plaid is completely dry.
22. The plug on the supply cord must be unplugged immediately if

- the heating plaid becomes extremely warm although a low temperature level has been selected.

- the heating plaid becomes so warm that certain areas become discoloured.

- crackling is heard from the switch, or in the case of visible damages to the switch, the heating plaid, the plug or the cord.

- the plaid has not become warm/warmer after 10 minutes at maximum temperature. However, first check at another outlet.

1. The heating plaid must only be used as under plaid.
2. The appliance is for domestic use only.
3. The heating plaid is not intended for use within the field of application of the pharmaceutical product law; i.e. not for treatment, palliation or prevention of illness, injuries, handicaps, including especially

- medical treatment in hospitals, nursing homes or other institutions

- medical treatment within professional or commercial nursing

1. Under no circumstances should attempts be made to repair the plaid since it involves high safety risk. Without special tools it is not possible to restore the safety of the parts.
2. Always examine appliance, cord and plug for damage before use. If the supply cord is damaged, it must be replaced by the manufacturer, or his service agent or a similarly qualified person in order to avoid a hazard.
3. The electrical installation must comply with the present legislation concerning additional protection in the form of a residual current device (RCD) with a rated residual operating current not exceeding 30 mA). Check with your installer.
4. If the appliance is used for other purposes than intended, or is it not handled in accordance with the instruction manual, the full responsibility for any consequences will rest with the user. Any damages to the product or other things are not covered by the warranty.

Disposal of the appliance

Legislation requires that all electrical and electronic equipment must be collected for reuse and recycling. Electrical and electronic equipment marked with the symbol indicating separate collection of such equipment must be returned to a municipal waste collection point.

Warranty

Claims according to current law. Cash receipt with purchase date shall be enclosed with any claims. When raising a claim the appliance must be returned to the store of purchase.

OBH Nordica Sweden AB

Box 58

163 91 Spånga

Phone [phone]

www.obhnordica.se

Technical data

OBH Nordica 4090, 4091

230-240V AC

150 watt

9 temperature settings

Timer function 3 hours.

Soft micro plush (100% polyester).

Electro-block safety system.

Removable switch F20A1.

160 x 120 cm.

With reservation for running changes.

Date of purchase:

Year

Month Day
