DA553 - TV Antenna GoGen - Free user manual and instructions

Brand	GoGen
Model	DA553
Product Type	TV Antenna
Reception Channels	5 - 12 (VHF), 21 - 60 (UHF)
Frequency Range VHF	174 - 230 MHz
Frequency Range UHF	470 - 790 MHz
Max Output Level	110 dBuV
Input Voltage	AC 100 - 240V / 50Hz
Working Voltage	DC 5V / 550mA
Connector Type	IEC connector
Signal Technology	Full HD digital, low noise, high gain
Amplifier	Wide band amplifier
Power Indicator	Crystal power-on LED
Power Switch	On/off for energy saving
Design	Ultra slim, mirror face, illusory housing
Adaptor	External AC/DC adaptor included
Safety	Do not use near water; keep plastic bag away from babies
Disposal	WEEE compliant - recycle at collection point
Compliance	Directive 2014/53/EU (EU Declaration of Conformity available online)

Frequently Asked Questions - DA553 GoGen

How do I connect the antenna to my TV?

Connect the coaxial cable from the antenna to the RF input socket on your TV. Ensure the connection is secure.

How do I power the antenna?

Connect the supplied AC/DC adaptor to the DC 5V/550mA jack on the back of the antenna, then plug the adaptor into a standard AC outlet.

How do I turn the antenna on and off?

Use the rotary switch on the antenna to turn it on or off. The power indicator will light up when on.

How do I improve reception if the signal is weak?

Try repositioning the antenna to a different location, preferably near a window or higher up. Adjust the loop or dipoles for best angle.

What channels can I receive with this antenna?

The antenna supports VHF channels 5-12 and UHF channels 21-60, covering 174-230 MHz and 470-790 MHz respectively.

Can I use this antenna for digital TV?

Yes, it is designed for Full HD digital television signals, including DVB-T/T2.

Does the antenna need to be connected to power at all times?

It is recommended to turn off the antenna when not in use to save energy. The on/off switch allows easy power management.

Is the antenna suitable for both VHF and UHF?

Yes, it has adjustable loop for UHF and dipoles for VHF to optimize reception for each band.

What should I do in case of a thunderstorm?

Stop using the antenna and turn off the power immediately to avoid risk of electric shock.

How do I dispose of this product correctly?

Do not dispose with household waste. Take it to a designated collection point for electrical and electronic equipment recycling.

USER MANUAL DA553 GoGen

Abstract logo design with white stylized 'S' inside a black circle (no text or symbols)

DA 553

GoGEN

Black Sony portable radio antenna with antenna and base (no visible text or symbols)

VLASTNOSTI

Black rectangular electronic device with a circular top and antenna, no visible text or symbols

Close-up of a hand inserting a cable into a computer tower socket (no visible text or symbols)

Close-up of a black electronic device with a circular button and curved handle (no visible text or symbols)

Black circular ring mounted on a rectangular base with vertical lines, no visible text or symbols

Black circular ring mounted on a black base with metal pins (no text or symbols visible)

Close-up of a hand inserting a cable into a computer monitor socket (no visible text or symbols)

Close-up of a black electronic device with a circular button and curved handle (no visible text or symbols)

Black circular ring mounted on a rectangular base with metal pins (no text or symbols visible)

Black circular ring mounted on a black base with vertical rods (no text or symbols visible)

Hand inserting a cable into a computer port socket (no visible text or symbols)

Close-up of a black plastic tray with a circular button and curved arms (no text or symbols visible)

Black circular ring device with vertical lines and a small base, no visible text or symbols

• Receives Full HD television digital signals;
• For reception of local and regional VHF and UHF signals;
• Wide band amplifier for best picture and sound reception;
  • Signal clear technology with extremely low noise and high gain circuitry;
• Adjustable loop aerial for best UHF reception;
  • Crystal Power-on indicator
• On/off switch for energy saving;
• Ultra slim design;
• Attractive mirror face & Illusive housing;
• With external AC/DC adaptor

PERFORMANCE

• Reception channels: 5 - 12, 21 - 60
• Frequency: VHF 174 - 230 MHz, UHF: 470 - 790 MHz
• Max Output Level: 110 dBuV
- Input Voltage: AC 100 - 240V / 50Hz
• Working Voltage: DC 5V/550mA
- Connector: IEC-connector

NOTICE

Stop using in the thunderous day and turn off the power.

Turn off the power when not using.

If it can't receive well, please place the antenna in different position.

1. Power connection

Black circular ring mounted on a rectangular base with a small metallic knob (no text or symbols visible)

DC Connect the AC adapter to the DC 5V/550mA jack at the back of the antenna and plug the AC adapter into a standard AC outlet.

2. Connect to TV

Close-up of a hand inserting a USB into a computer monitor (no visible text or symbols)

Connect the end of the coaxial cable to the TV's RF input socket.

3. Turning the antenna on & Gain Adjustment

Close-up of a black plastic tray with a circular button and curved arms (no text or symbols visible)

Turn on the antenna by rotating the switch.

4. Antenna adjustment

Black circular ring device mounted on a base with vertical lines, no visible text or symbols

When receiving UHF signal(470 - 790 MHz), adjust the loop to the best reception angle.

When receiving VHF signal(174 - 230 MHz), adjust the dipoles to best reception of angle.

WE RESERVE THE RIGHT TO CHANGE TECHNICAL SPECIFICATIONS.

WARNING: DO NOT USE THIS PRODUCT NEAR WATER, IN WET AREAS TO AVOID FIRE OR INJURY OF ELECTRIC CURRENT. ALWAYS TURN OFF THE PRODUCT WHEN YOU DON'T USE IT OR BEFORE A REVISION. THERE AREN'T ANY PARTS IN THIS APPLIANCE WHICH ARE REPARABLE BY CONSUMER.

ALWAYS APPEAL TO A QUALIFIED AUTHORIZED SERVICE. THE PRODUCT IS UNDER A DANGEROUS TENTION.

TO AVOID DANGER OF SUFFOCATION, KEEP THE PLASTIC BAG AWAY FROM BABIES AND CHILDREN. DO NOT USE THIS BAG IN CRIBS, BEDS, CARRIAGES OR PLAYPENS. THIS BAG IS NOT A TOY.

Disposal of old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems)

This symbol on the product or on its packaging indicates that this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will

help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Hereby, ETA a.s. declares that the radio equipment type DA553 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.gogen.cz/declaration_of_conformity
