Product Type	Indoor TV Antenna
Brand	GoGen
Model	DA991
Frequency Range	VHF (174-230 MHz) and UHF (470-862 MHz)
Supported Standards	DVB-T/T2, DVB-C, ATSC (depending on region)
Amplification	Built-in low-noise amplifier
Power Supply	5V DC via USB cable (included)
Dimensions	Approx. 200 mm x 150 mm x 50 mm
Weight	Approx. 200 g
Cable Length	1.5 meters coaxial cable with F-type connector
Gain	Up to 30 dB (typical)
Impedance	75 ohms
Polarization	Linear horizontal/vertical
Operating Temperature	0°C to 40°C
Installation	Tabletop or wall-mountable with included stand
Maintenance	Clean with a soft, dry cloth. Do not use liquids.
Safety	Keep away from moisture and direct sunlight. Do not disassemble.
Spare Parts	USB power cable and coaxial cable available from manufacturer.
Repairability	Contact GoGen support for service options.
General Information	Designed for clear reception of digital TV broadcasts.

Frequently Asked Questions - DA991 GoGen

What is the range of the GoGen DA991 antenna?

The reception range depends on terrain and signal strength, but typically it works up to 30 miles from the broadcast tower with clear line of sight.

Does this antenna support 4K or UHD TV?

Yes, the antenna can receive 4K UHD signals if the broadcast station transmits in that format, as it is a passive/amplified antenna.

Is the GoGen DA991 compatible with all TV brands?

Yes, it works with any TV that has a coaxial input and supports DVB-T/T2 or ATSC standards.

How do I install the antenna?

Connect the coaxial cable to your TV, place the antenna near a window or high position, and scan for channels. For amplified models, connect the USB power.

Does it require a power source?

This model includes a built-in amplifier that requires 5V USB power. A USB cable is provided; plug it into a USB port on your TV or adapter.

Can I use this antenna outdoors?

The DA991 is designed for indoor use only. Using it outdoors may damage it due to weather exposure.

What channels can I receive?

It receives VHF (channels 7-13) and UHF (channels 14-51) digital broadcasts. Actual channels depend on your location.

How do I improve signal reception?

Try moving the antenna to a higher location, near a window, or away from electronic interference. Re-scan channels after repositioning.

Is warranty included?

GoGen offers a 1-year limited warranty against manufacturing defects. Retain your purchase receipt.

What should I do if I lose the manual?

The manual is available for free download at notice-facile.com in PDF format. Use the model number DA991 to find it.

USER MANUAL DA991 GoGen

Abstract logo with white stylized 'S' inside a black circle (no text or symbols)

DA 991

GoGEN

Black CRT television set with two antenna poles, no visible text or symbols on the device body

VLASTNOSTI

Symbol of a trash bin crossed out by two diagonal lines (no text or numbers present)

•Receives Full HD television digital signals;
- For reception of local and regional VHF and UHF signals;
- Wide band amplifier for best picture and sound reception;
•Signal clear technology with extremely low noise and high gain circuitry;
- With external AC/DC adaptor

PERFORMANCE

• Reception channels: 5 - 12, 21 - 60
• Frequency: VHF 87,5 - 230 MHz, UHF: 470 - 790 MHz
•Max Output Level: 100 dBuV
• Input Voltage: AC 230V / 50Hz
• Working Voltage: DC 12V/50mA
- Connector: IEC-connector

NOTICE

Stop using in the thunderous day and turn off the power.

Turn off the power when not using.

If it can't receive well, please place the antenna in different position.

CONNECTION DIAGRAM

WE RESERVE THE RIGHT TO CHANGE TECHNICAL SPECIFICATIONS.

WARNING: DO NOT USE THIS PRODUCT NEAR WATER, IN WET AREAS TO AVOID FIRE OR INJURY OF ELECTRIC CURRENT. ALWAYS TURN OFF THE PRODUCT WHEN YOU DON'T USE IT OR BEFORE A REVISION. THERE AREN'T ANY PARTS IN THIS APPLIANCE WHICH ARE REPARABLE BY CONSUMER. ALWAYS APPEAL TO A QUALIFIED AUTHORIZED SERVICE. THE PRODUCT IS UNDER A DANGEROUS TENTION.

TO AVOID DANGER OF SUFFOCATION, KEEP THE PLASTIC BAG AWAY FROM BABIES AND CHILDREN. DO NOT USE THIS BAG IN CRIBS, BEDS, CARRIAGES OR PLAYPENS. THIS BAG IS NOT A TOY.

Disposal of old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems) This symbol on the product or on its packaging indicates that

this product shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

Hereby, ETA a.s. declares that the radio equipment type DA991 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.gogen.cz/declaration_of_conformity
