XSA1000TG - Mètre Owon - Free user manual and instructions
Find the device manual for free XSA1000TG Owon in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Digital Multimeter |
| Brand | Owon |
| Model | XSA1000TG |
| Display | Backlit LCD, 6000 counts |
| Auto-Ranging | Yes |
| DC Voltage Range | 600 mV to 1000 V |
| AC Voltage Range | 600 mV to 750 V |
| DC Current Range | 600 μA to 10 A |
| AC Current Range | 600 μA to 10 A |
| Resistance Range | 600 Ω to 60 MΩ |
| Capacitance Range | 60 nF to 60 mF |
| Frequency Range | 60 Hz to 60 MHz |
| Diode Test | Yes |
| Continuity Test | Yes |
| Safety Rating | CAT II 1000V, CAT III 600V |
| Power Supply | 2x 1.5V AA batteries |
| Dimensions | 180 x 80 x 40 mm |
| Weight | 350 g (with batteries) |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Maintenance | Clean with a dry cloth; avoid solvents |
| Spare Parts | Test leads, batteries, fuses |
| Repairability | Replaceable fuse and batteries; professional repair for other issues |
| General Information | Includes test leads, manual, and carrying case |
Frequently Asked Questions - XSA1000TG Owon
How do I measure DC voltage with the Owon XSA1000TG?
Turn the dial to DCV (V with straight line). Insert the black lead into COM and red lead into VΩmA. Connect probes to the circuit. Read the voltage on the display.
How do I measure AC voltage?
Turn the dial to ACV (V with wavy line). Insert the black lead into COM and red lead into VΩmA. Connect probes across the source. Read the RMS voltage.
How do I measure resistance?
Turn the dial to Ω. Insert black lead into COM and red lead into VΩmA. Touch probes to the resistor or circuit. Ensure power is off. Read resistance value.
What does the continuity test do?
Turn the dial to continuity (sound wave symbol). Insert probes as for resistance. If resistance is < 50 Ω, the meter beeps. Useful for checking wires and connections.
How do I replace the battery?
Turn off the meter. Remove the screw on the back cover. Open the battery compartment. Replace the 2x AA batteries with correct polarity. Close compartment and tighten screw.
How do I replace the fuse?
Turn off and disconnect leads. Remove back cover. Locate the fuse (usually 10A and 500mA). Replace with same rating. Reassemble. Fuses protect against overload.
What does 'OL' on the display mean?
OL means 'Over Load' or out of range. The measured value exceeds the selected range. Switch to a higher range if manual ranging; in auto-ranging, it indicates the value is too high.
Can I measure current without disconnecting the circuit?
No, to measure current you must break the circuit and insert the meter in series. Use the 10A terminal for high current up to 10A, and VΩmA for lower current.
How do I use the diode test?
Turn the dial to diode symbol (arrow with bar). Insert black to COM and red to VΩmA. Connect red to anode, black to cathode. Forward voltage drop is shown; 'OL' indicates reverse bias.
Does the meter have a backlight?
Yes, press the HOLD/BACKLIGHT button to toggle the backlight on/off. The backlight helps in dim environments.
