60-OW-01N - Range hood MPM - Free user manual and instructions
Find the device manual for free 60-OW-01N MPM in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Range Hood |
| Brand | MPM |
| Model | 60-OW-01N |
| Installation Type | Built-in under cabinet |
| Width | 60 cm |
| Depth | 50 cm |
| Height (without chimney) | 15 cm |
| Weight | 10 kg |
| Material | Stainless steel |
| Control Type | Mechanical push buttons |
| Number of Speeds | 3 |
| Extraction Capacity | 600 m³/h |
| Noise Level (max speed) | 65 dB |
| Lighting | LED, 3 W |
| Motor Power | 180 W |
| Voltage | 220-240 V |
| Frequency | 50 Hz |
| Energy Efficiency Class | B |
| Filter Type | Aluminum grease filter |
| Ducting Options | Ducted (external) or recirculating (with charcoal filter) |
| Charcoal Filter Included | No (sold separately) |
| Duct Diameter | 120 mm |
Frequently Asked Questions - 60-OW-01N MPM
How do I install the MPM 60-OW-01N range hood?
Installation must be done by a qualified professional. The hood should be mounted at a minimum height of 65 cm above electric cooktops or 75 cm above gas cooktops. Refer to the manual for detailed steps on securing the hood and connecting the ductwork.
Can the hood be used in recirculation mode?
Yes, the MPM 60-OW-01N can be used in recirculation mode with an optional charcoal filter (sold separately). The charcoal filter absorbs odors and must be replaced every 3-6 months.
How do I clean the grease filter?
The aluminum grease filter is removable and washable. Clean it every month with warm soapy water or in a dishwasher at low temperature. Ensure it is completely dry before reinstalling.
Why is the hood making loud noises?
Loud noises may indicate a clogged filter, loose installation, or an issue with the motor. First, check and clean the grease filter. If the noise persists, inspect the ductwork for blockages or contact customer support.
The LED light is not working, what should I do?
The LED light is integrated and not user-replaceable. If it fails, contact MPM customer service for assistance. Do not attempt to open the hood yourself.
What is the warranty period for this hood?
The MPM 60-OW-01N comes with a 2-year warranty against manufacturing defects. The warranty covers parts and labor but does not cover misuse or normal wear (e.g., filters).
How often should I replace the charcoal filter?
If used in recirculation mode, the charcoal filter should be replaced every 3 to 6 months depending on usage. A saturated filter reduces odor absorption efficiency.
Can I use the hood without ducting?
Yes, but only if you install a charcoal filter for recirculation. Without ducting or charcoal filter, the hood will not function properly and may recirculate grease and odors.
How do I reset the filter saturation alarm?
After cleaning or replacing the filters, press and hold the speed button for 3 seconds until the indicator light turns off. This resets the alarm timer.
Is a remote control included with the hood?
No, the MPM 60-OW-01N is controlled via mechanical push buttons on the front panel. No remote control is included or available.
User questions about 60-OW-01N MPM
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Range hood in PDF format for free! Find your manual 60-OW-01N - MPM and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. 60-OW-01N by MPM.
USER MANUAL 60-OW-01N MPM
енергия · ενεργεια
MPM-60-OW-01N
bar
| Category | Value | |---|---| | A+++ | 10 | | A++ | 15 | | A+ | 20 | | A | 25 | | B | 30 | | C | 35 | | D | 40 |
65/2014
