60-OW-04 - Range hood MPM - Free user manual and instructions

Product Type	Range Hood
Brand	MPM
Model	60-OW-04
Width	60 cm
Mounting Type	Under-cabinet / Wall-mounted
Suction Power (Max)	650 m³/h
Number of Speeds	3
Lighting	2 x LED (warm white)
Filter Type	Aluminum Grease Filter
Control Type	Electronic push buttons
Energy Class	A+
Power Supply	220-240 V ~ 50 Hz
Motor Power	150 W
Noise Level (Max)	65 dB
Weight	12 kg
Dimensions (W x D x H)	60 x 50 x 15 cm
Duct Diameter	150 mm
Grease Filter Cleaning	Dishwasher safe (monthly)
Carbon Filter	Optional (for recirculation mode)
Safety Features	Overheat protection, auto shut-off
Spare Parts Availability	Filters, bulbs, motor (contact MPM service)

Frequently Asked Questions - 60-OW-04 MPM

How do I install the MPM 60-OW-04 range hood?

Installation must be done by a qualified electrician. Ensure the hood is at least 65 cm above gas hobs and 50 cm above electric hobs. Follow the manual for wall-mounting and electrical connection.

How often should I clean the grease filter?

The aluminum grease filter should be cleaned every month or more frequently if used heavily. It is dishwasher safe or can be hand-washed with warm soapy water.

Does this hood require a carbon filter?

Only if you use the hood in recirculation mode (without ducting outside). A carbon filter (not included) absorbs odors and should be replaced every 3-6 months.

Why is my range hood noisy?

Noise can be caused by a dirty filter, loose installation, or high speed setting. Clean the grease filter and ensure the hood is securely mounted. The maximum noise level is 65 dB.

How do I replace the LED bulbs?

The LED bulbs are integrated and may require professional replacement. Contact MPM customer service for assistance or consult the manual for specific instructions.

What is the power consumption of this hood?

The motor power is 150 W, and the LED lighting uses approximately 4 W. The energy class is A+, ensuring efficient operation.

Can I use the hood with a flexible duct?

Yes, but for optimal performance use a smooth, rigid duct of 150 mm diameter. Flexible ducts can reduce airflow and increase noise.

How do I reset the filter alarm?

After cleaning or replacing filters, press and hold the speed button for about 3 seconds until the indicator light turns off. Refer to the manual for precise steps.

What should I do if the hood stops working?

Check the power supply and circuit breaker. If the motor overheats, wait 15 minutes to let it cool. If the problem persists, contact MPM service for repair.

Is the MPM 60-OW-04 suitable for an island kitchen?

This model is designed for wall or under-cabinet mounting, not for island use. For island installation, a different hood type is required.

USER MANUAL 60-OW-04 MPM

• minimum cabinet width 60 cm
• speed range: 3 speed range
• extraction or absorption function
• independent lighting control
- push button control (push-buttons in the tunnel guides)

Black MPM air conditioner unit with ventilation grilles and control knobs (no visible text or symbols)

Equipment:

aluminium filter in the colour of the hood - black

• dishwasher safe aluminum filter - 1 piece
• optional carbon filter
• dedicated charcoal filter model YPM-01-FW-09

Technical data

• efficiency m n/max 195/310 m/h
• noise level: min/max 51/63 dB
• lighting: LED light bulb: 2 x 3 W
• light colour: neutral white 3000 K
• energy class: C
• material of the hood: steel
- black steel panel
• housing colour: black
• minimum installation height over the gas hob 65 cm
• minimum installation height over the electric hob 45 cm
• net weight of appliance 4,4 kg
• gross appliance weight 5.7 kg

EAN:

5903151026880

Master carton quantity:

1 pcs.
