CD-XP110H - Hi-Fi System SHARP - Free user manual and instructions

Product Type	Mini Component System
Model Number	CD-XP110H
Speaker System Model	CP-XP110H
Disc Playback	CD, CD-R, CD-RW
Cassette Deck	Yes (Tape 1 & Tape 2)
Radio Tuner	AM/FM
Audio Output Power	Approx. 20W per channel (RMS)
Speaker Impedance	6 ohms
Frequency Response	40 Hz - 20 kHz
Power Supply	AC 110-240V, 50/60 Hz
Power Consumption	Approx. 50W
Dimensions (Main Unit)	Approx. 210 x 280 x 310 mm (W x H x D)
Weight (Main Unit)	Approx. 3.5 kg
Dimensions (Speakers)	Approx. 180 x 280 x 230 mm each
Weight (Speakers)	Approx. 2.5 kg each
Remote Control	Included
Connections	AUX In, Antenna, Speaker terminals
Safety Class	Class 1 Laser Product
Repair	Spare parts available; consult manual
Cleaning	Soft dry cloth; avoid liquids

Frequently Asked Questions - CD-XP110H SHARP

What types of discs can the CD-XP110H play?

The system supports CD, CD-R, and CD-RW discs. It can also play MP3 files if burned correctly on CD-R/RW.

Does the system have a tape deck?

Yes, it features two cassette decks (Tape 1 and Tape 2) for playback and recording.

Can I connect external devices like a smartphone?

Yes, there is an AUX input on the front or back panel. Use a 3.5mm audio cable to connect your device.

How do I set the clock on the CD-XP110H?

Press the CLOCK button, then use the TUNING/SEARCH buttons to set hour and minute. Confirm with CLOCK or ENTER.

Why is there no sound from the speakers?

Check that speakers are connected securely to the correct terminals. Also ensure the source is selected and volume is not muted.

How can I improve radio reception?

Extend the FM wire antenna fully. For AM, rotate the loop antenna. Avoid placing near interference sources.

Can I record from CD to cassette?

Yes, insert a blank tape in Tape 2 and press RECORD while playing a CD. The system will synchronize automatically.

What maintenance does the system require?

Clean the exterior with a soft dry cloth. For the tape heads, use a cleaning cassette. Keep discs dust-free.

Is the laser safe?

The unit is a Class 1 laser product that is safe under normal use. Do not open the casing as invisible laser radiation may be emitted.

Where can I find spare parts?

Contact Sharp service centers or authorized dealers. The manual lists part numbers for belts, heads, etc.

USER MANUAL CD-XP110H SHARP

COMPACT disc DIGITAL AUDIO

CD-R/RW Playable 3000 DISC

CD-XP110H Mini Component System consisting of CD-XP110H (main unit) and CP-XP110H (speaker system).

CD-XP110H mini system consisting of CD-XP110H (main unit) and CP-XP110H (speaker system).

CD-XP110H mini component system consisting of CD-XP110H (main unit) and CP-XP110H (speaker system).

Emission Duration: continuous Laser Output: max. 0.6 mW

WARNING! USING THE DEVICE IN A WAY OTHER THAN SPECIFIED IN THIS USER MANUAL MAY EXPOSE THE USER TO INVISIBLE LASER RADIATION EXCEEDING SAFETY CLASS 1. WARNING - IF THE DEVICE IS USED IN A WAY OTHER THAN SPECIFIED IN THIS USER MANUAL, THE USER MAY BE EXPOSED TO INVISIBLE LASER RADIATION EXCEEDING THE LIMIT FOR LASER CLASS 1.

CAUTION - VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. DO NOT LOOK INTO THE BEAM - NOT EVEN WITH OPTICAL INSTRUMENTS. WARNING! WHEN OPEN, YOU ARE EXPOSED TO VISIBLE AND INVISIBLE LASER RADIATION. DO NOT STARE INTO THE BEAM OR VIEW IT WITH OPTICAL INSTRUMENTS. WARNING - VISIBLE AND INVISIBLE LASER RADIATION WHEN THIS PART IS OPEN. DO NOT STARE INTO THE BEAM OR VIEW IT WITH OPTICAL INSTRUMENTS.

Introduction

(AM 12:00 - PM 11:59)

■ TAPE 1 or TAPE 2 cassette playback

© Pinch roller

© Playback head

© Capstan
