Product Type	Oil-filled Radiator
Power	1500W
Voltage	220-240V~50Hz
Heating Element	9/11 fins
Temperature Control	Automatic thermostat with adjustable setting
Heat Settings	2 power levels (Heat I and II)
Mobility	4 castor wheels
Handle	Plastic handle for carrying
Oil Type	Special heat conducting oil (precise quantity)
Cord Storage	Power cable & plug storage compartment
Safety Features	Do not cover; keep upright; avoid water and bathrooms; do not use immediately below socket outlet
Cleaning	Wipe with soft damp cloth; do not use detergents or abrasives
Maintenance	Unplug and allow to cool before cleaning; repairs only by qualified service agent
Warranty	2 years from date of purchase against manufacturing defects
Included Accessories	Wheel plates, wing nuts, castor wheels
Indoor Use Only	Yes

Frequently Asked Questions - NDD-30C1500 Kunft

How to set the desired room temperature?

Turn the thermostat (B) to the highest setting and switch on both power buttons (C). When the desired temperature is reached, turn back the thermostat until the indicator lamp goes out. The thermostat will then maintain that temperature.

How to fit the wheels?

Turn the radiator upside down on a soft surface. Screw the wheel plate onto the radiator using wire loops and wing nuts. Push the castor wheels onto the wheel pins until they click into place. Then turn the radiator upright.

Can I use the heater in a bathroom?

No. The heater must not be used in a bathroom or near a source of water to avoid electric shock or fire hazard. Do not install near bath tubs, showers, or swimming pools.

Why does the radiator make noise when first used?

It is normal for the radiator to make a noise when used for the first time. This is due to the expansion of the oil and materials as they heat up. The noise should subside after initial use.

How to clean the oil radiator?

Unplug the radiator and let it cool completely. Wipe the casing with a soft, damp cloth. Do not use detergents or abrasive cleaners. Do not spray water onto the radiator.

What is the power consumption of this heater?

The heater uses 1500W at 220-240V~50Hz. It has two heat settings, but the maximum power is 1500W.

Is it safe to leave the heater unattended?

While the heater has safety features like automatic temperature control, it is recommended not to leave it unattended for long periods. Never cover the heater or place it near flammable materials. Keep at least 50mm clearance from furniture and curtains.

How do I know if the heater is working?

The indicator lamp on the thermostat illuminates when the heater is operating. When the lamp goes out, the heater has reached the set temperature and is cycling off. The lamp will turn back on when heating resumes.

What should I do if the power cord is damaged?

Do not use the heater. The power cord must be replaced by the manufacturer, its service agent, or a similarly qualified person to avoid hazard. Contact Worten or Kunft support for assistance.

Can I cover the radiator to dry clothes?

No. Never cover the radiator with any object, including clothes. Covering can cause overheating and fire hazard. The radiator must be kept uncovered at all times.

USER MANUAL NDD-30C1500 Kunft

MANUAL DE INSTRUÇÕES

White KLED water heater with cooling fan and wheels, no visible text or symbols on the device itself.

oil radiator 1500W

NDD-30C1500

Dear client,

We thank you for purchasing this product.

This appliance was submitted to several laboratorial tests, which certify its quality. To simplify the use of this appliance, this instruction manual has been provided. The instructions must ensure a quick and safe use.

Please read carefully the instructions and safety measures described in this manual.

We wish our clients great satisfaction in using their new appliance.

INDEX

1. SAFETY INSTRUCTIONS ....4

1.1. Power Energy ....5
1.2. Power Cord and Other Cables .....5
1.3. Humidity and Water ....5
1.4. Cleaning ....5
1.5. General Precautions ....5

1. UTILIZATION AND FUNCTIONING ....6

2.1. Product Description ......6
2.2. Introduction ......6
2.3. Features ....7
2.4. Operation ......7
2.5. Fitting the Wheels ....7

1. MAINTENANCE ....7
2. TECHNICAL SPECIFICATIONS ....7
3. AFTERMARKET 7
4. ENVIRONMENT CONSERVATION ....8

1. SAFETY INSTRUCTIONS

	ATTENTION
	Risk of Electric ShockDo Not Open

Attention: to avoid the risk of electric shock, do not remove the cover. The interior does not contain any parts that may be repaired by the user. Ask for assistance to qualified personnel.

Important Warnings

Before using your appliance, read carefully this instruction manual and keep it in a safe place, as you may need it for future consultations.

Before you start your appliance, and to ensure a correct use, do not use it if:

- It has fallen on the ground;

- You notice any evidence of damage;

- Any anomaly occurs during its operation;

To avoid hazards and deterioration of your appliance by an incorrect use, it is advisable to read the instructions carefully and attentively. Your appliance must not be used to other ends than the ones foreseen in the instructions manual. Your safety is only guaranteed in a household use and not for commercial use. The incorrect use will not be covered and automatically cancels the right to warranty.

Assistance

Be sure that, in case of malfunction, you take your appliance to a qualified technician for assistance.

This appliance can be used by children from 8 years old and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and maintenance shall not be made by children without supervision.

These instructions are also available on www.suporteworten.pt

1.1. Power Energy

Make sure the voltage of the electric network is compatible with the one of the appliance. If it does not match, consult the vendor or Customer Support Service.

1.2. Power Cord and Other Cables

Do not roll up or pull the cord to disconnect the appliance, and do not use to twine the appliance. Keep the cord far from warm surfaces.

Never use the appliance if it has a damaged cable or socket, or if it is not working properly.

In case of damage of the power cord, do not use your appliance. Take it to technical assistance for its replacement.

1.3. Humidity and Water

Do not use your appliance in humid places. Do not let your appliance to catch water under any circumstance, as it may be dangerous. TO AVOID FIRE HAZARD OR ELECTRIC SHOCK DO NOT EXPOSE YOUR APPLIANCE TO HUMIDITY OR WATER. Do not place your appliance under water (for example for washing).

1.4. Cleaning

Before undertaking any cleaning operation, disconnect the appliance from the power supply.

Wipe the casing with a soft, damp cloth. Don't clean the radiator with detergents or abrasive cleaners.

1.5. General Precautions

• Please follow the instructions of the user manual, which helps properly installing and operating this product and enjoying its advanced features. Please keep the instructions for future reference.
• Read all instructions before using the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• In order to avoid overheating, do not cover the heater.

• The heater must not be located immediately below a socket outlet.

• Do not install the appliance in the immediate vicinity of bath tubs, showers, wash basins, swimming pools, etc.

• This heater is filled with a precise quantity of special oil.
• Repairs requiring opening of the oil container are only to be made by the manufacturer or his service agent who should be contacted if there is an oil leak. When scrapping the heater, follow the regulations concerning the disposal of oil.
  • The radiator should always be kept upright.
• Do not position your radiator near to the flammable materials. Allow a distance of at least 50mm between furniture, curtain, walls, etc.
• If the cord becomes worn out, it must be replaced by a qualified technician.
• Do not lay the cords over the radiator when not in use.
• Do not cover the radiator with any object.
• The radiator must not be used in a bathroom or near a source of water.
• It's normal for the radiator to make a noise when it is being used for the first time.
• In case of problems with the radiator, please do not attempt any repairs. Refer repairs only to qualified service personnel.
• The oil used in this radiator is of a specification particular to this type of radiator and is manufactured with a precisely measured quantity. Only approved agents must open up the oil container section to carry our repairs. Any oil leak must be reported to and repaired by qualified service personnel.
• Check that your supply voltage is the same as the shown on the rating label and that the socket is earthed.

2. UTILIZATION AND FUNCTIONING

2.1. Product Description

A. Plastic handle
B. Thermostat
C. Heat I and II
D. Fins
E. Power cable & plug storage compartment
F. Castor wheels

2.2. Introduction

To get the best from this product and prolong its life, please spare a few minutes to read the user instructions.

2.3. Features

Large 9/11-fins heating surface provides uniform radiation.

Automatic temperature controller for adjusting and maintaining the desired room temperature.

Special heat conducting oil is utilized.

Equipped with castor wheels for ease of movement.

2.4. Operation

1) Turn the thermostat (B) to the highest setting and switch on the two power buttons (C). When the desired temperature has been reached, turn back the thermostat until the indicator lamp goes out.
2) Simply adjust the thermostat to retain the desired temperature.
3) The indicator lamp indicates whether or not the radiator is working.

2.5. Fitting the Wheels

1) Turn the radiator upside down and rest on a soft surface to prevent scratching the radiator housing.
2) Screw the wheel plate onto the radiator, using the wire loops and wing nuts provided.
3) Push the castor wheels onto the wheel pins on the plate until they "click" into place.
4) Turn the radiator back to its correct upright position.

3. MAINTENANCE

Before carrying out any maintenance on your radiator, ensure that it is unplugged and completely cold. Don't spray water onto the radiator.

4. TECHNICAL SPECIFICATIONS

220-240V\~50Hz 1500W

5. AFTERMARKET

KUNFT has designed this appliance in order to guarantee the maximum reliability. However, if a problem occurs, by following the procedures suggested in this section you may be able to determine its cause.

Do not attempt to open the appliance - there is a risk of electrical shock.

If you are not able to solve the problem, please contact your seller or manufacturer.

All users must be familiarized with this section. Knowing what could go wrong can help you avoid the occurrence of problems.

oil radiator 1500W NDD-30C1500

KUNFT®

WARNING: any attempt of fixing the appliance without contacting the manufacturer will nullify the warranty.

In case the problem persists, take your appliance to an aftermarket section of any Worten, Modelo or Continente store in order to solve the problem.

Worten Equipamentos para o Lar ensures for a period of 2 years, counting from the date of purchase of this appliance, a warranty against any found manufacturing defect. The warranty supposes a correct use and maintenance of the appliance, namely according to the instructions expressed in this manual. In case otherwise identified, the malfunctions will not be under the warranty.

The repairing of electrical appliances must only be made by qualified technicians, as otherwise there may occur future complications on the appliances.

To avoid unnecessary risks, in case there are any malfunctions on the wires or on another type of components, repairing must be made on the specialized locations of technical assistance, as appropriate tools are needed.

6. ENVIRONMENT CONSERVATION

Aiming to protect the environment, we try to reduce to a maximum the volume of the packages which are confined to three easy separation materials: cardboard, paper and plastic.

The appliance is made of recyclable material, once disassembled by a specialized company. Follow the local legislation concerning recycling of all materials.
