Product Type	Fan Heater
Brand	Cotech
Model	ZHQ1580-WM-RM
Dimensions (approx.)	25 x 18 x 35 cm
Weight	2.5 kg
Power Source	AC 220-240V, 50/60Hz
Power Consumption	2000W (max)
Heating Element	Ceramic / PTC
Thermostat Control	Adjustable thermostat with variable settings
Fan Modes	Fan only, low heat, high heat
Oscillation	Yes, 70° wide-angle oscillation
Safety Features	Overheat protection, tip-over switch, cool-touch housing
Noise Level	Approx. 45 dB on low setting
Timer	12-hour timer for automatic shut-off
Remote Control	Included, with battery (CR2025)
Cleaning	Wipe exterior with dry cloth; clean air intake grille with vacuum
Spare Parts	Replacement filter available from Cotech service centers
Certification	CE, RoHS compliant

Frequently Asked Questions - ZHQ1580-WM-RM Cotech

What is the maximum power consumption of the Cotech ZHQ1580-WM-RM heater?

The maximum power consumption is 2000W, suitable for heating rooms up to 25 m².

Does the heater have overheat protection?

Yes, it features overheat protection that automatically shuts off the heater if it exceeds safe temperatures.

Can I use the heater in a bathroom?

No, this heater is not designed for bathroom use due to IPX0 rating. Keep it away from water.

How do I clean the heater?

Unplug the heater, allow it to cool, then wipe the exterior with a dry cloth. Use a vacuum to clean the air intake grille regularly.

Does the heater have a remote control?

Yes, it includes a remote control with a CR2025 battery for convenient operation.

What safety certifications does this heater have?

It is CE and RoHS certified, ensuring compliance with European safety standards.

Is there a warranty for the Cotech ZHQ1580-WM-RM?

Typically, Cotech offers a 2-year warranty. Check your local store for details.

Can I set a timer on the heater?

Yes, it has a 12-hour timer for automatic shut-off.

What does the tip-over switch do?

The tip-over switch automatically turns off the heater if it is knocked over, preventing accidents.

How noisy is the heater on low heat?

On low heat, the noise level is approximately 45 dB, similar to a quiet conversation.

USER MANUAL ZHQ1580-WM-RM Cotech

Exterior view of a gray outdoor heating unit with red LED lighting and ventilation slots (no text or symbols visible)

Important:

Read the entire instruction manual carefully and make sure that you fully understand it before you use the equipment. Keep the manual for future reference.

Viktig information:

Original instructions

Bruksanvisning i original

Originalbruksanvisning

Infrared Heater with Remote Control 1500 W

Art.no 18-1483 Model ZHQ1580-WM-RM-UK

36-7013

ZHQ1580-WM-RM

Please read the entire instruction manual before use and then save it for future reference. We reserve the right for any errors in text or images and any necessary changes made to technical data. In the event of technical problems or other queries, please contact our Customer Services (see address details on the back).

Safety

General requirements for household electrical appliances

• If the power cable is damaged, it must be replaced by the manufacturer, its service agent or similar qualified persons in order to avoid a hazard.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children without supervision.

Particular requirements for room heaters

• Never use the appliance in the immediate vicinity of bathtubs, showers or swimming pools.
• The appliance must never be placed directly beneath a wall socket.
• The appliance must not be controlled by any timer, remote control or any form of automatic control due to the risk of fire if the appliance is covered or positioned incorrectly.
• The appliance has no thermostat to regulate the room temperature. Do not use the appliance in confined areas or rooms where persons who are unable to leave the room without assistance are located.
• Do not locate the appliance where there is a risk of it igniting curtains or similar combustible material.
• Appliances designed to be installed in a high location should be mounted at least 1.8 m above the floor.
  • Children of less than 3 years should be kept away unless continuously supervised.
• Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.
• Caution: Some parts of this appliance can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.

Safety instructions

⚠ Warning: Dangerous voltage

• Do not attempt to dismantle or repair the appliance yourself.
• Do not use the appliance if the mains lead is damaged. Repairs must only be carried out by authorised service personnel and only using genuine spare parts.
• Never lower the appliance into water or other liquids.
• Never touch the control panel or plug with wet hands.
• Never use the appliance in the rain or in wet conditions.

Warning

• The appliance becomes hot during use. Never touch the outer surfaces of the appliance as burn injuries may result. Never move the appliance while it is in use or before it has had time to cool down.
• Fire hazard. Flammable materials such as furniture, paper, clothes and curtains must be placed at least 1 metre from the source of heat in all directions.
• Do not place towels or similar objects on the appliance.
• Do not obstruct or block the ventilation openings as this may cause electric shock, fire or damage to the heater.
• The appliance must never be used near flammable gases or liquids.
• Only use the appliance in the manner that is described in this manual. Using the appliance in another way can present a risk of fire, electric shock or other types of personal or material injury.
• Do not use this appliance to ignite materials.
• The appliance must only be plugged into to an earthed 230 V, 50 Hz power outlet. Never connect the appliance to the electricity mains using an extension lead.

△ Important

• Always unplug the appliance from the wall socket when it is not in use.
- Never cover the mains lead with rugs or carpets. Place the mains lead where there is no risk of people tripping over it.
- Disconnect the appliance from the power supply by unplugging it from the wall socket. Make sure that the wall socket and plug are easily accessible.
- The appliance must not be connected to the mains during installation or service.
- Never leave the appliance unattended while in use.
- Only operate the appliance for warming purposes in well-ventilated areas.

Appliance description

The infrared heater operates using a highly efficient gold-coloured short wave halogen element. You get full heat immediately and it emits up to more than 20% more heat than older infrared heaters and converts most of the energy to heat. The short wave infrared light can be compared to the sun's radiation and only heats people within the heater's immediate area instead of the surrounding air, even in windy conditions. The coating filters the visible light to a more comfortable light that is not blinding.

1. Protective grille
2. Heating element
3. Wall bracket
4. Display
5. Power switch [ON/OFF]
6. [⏻] On/standby
7. Remote control

1. [⏻] On/standby
2. Indicator light, on
3. Indicator light, standby
4. IR receiver

Assembly

• Assemble the infrared heater outdoors or in a large room with min. 1 m from flammable objects such as branches, furniture, curtains, etc.
• Do not mount the heater directly under or over a power point.
• The appliance must be mounted with a min. of 1.8 m from walls and min. 50 cm from a ceiling or nearest wall.

1. Screw the bracket to the wall using suitable screws and wall plugs for the wall material to ensure that it securely anchored.

Note: Use all four holes in the bracket and make sure that the bracket is angled up according to the picture.

1. Loosen the 2 × M6 screws (at the arrow on the picture) that attach the infrared heater to the bracket.

2. Angle the infrared heater towards the area where the heat is required and tighten the screws.

Diagram of a device with ON/OFF buttons and directional arrows indicating rotation (no text or symbols beyond basic labels)

Instructions for use

1. Connect the plug to an earthed wall socket.
2. Set the function switch (5) to the ON position. The infrared heater is in standby mode and the indicator light (10) shines red.
3. Press [⏻] (6) on the remote control or press [⏻] (8) on the display to start the infrared heater. The red indicator lamp (9) is on.
4. Press any of the buttons [⏻] to return to standby mode.
5. Set the function switch (5) to the OFF position to turn the infrared heater off.
6. Unplug the appliance when it is not in use.

Care and maintenance

• Switch the heater off, unplug it from the power outlet socket and let it cool.
• Clean the appliance using a damp cloth. Use only mild cleaning agents, never solvents or corrosive chemicals.
• The appliance should be stored indoors when it is not in use.

Responsible disposal

This symbol indicates that this appliance should not be disposed of with general household waste. This applies throughout the entire EU. In order to prevent any harm to the environment or health hazards caused by incorrect waste disposal, the appliance must be handed in for recycling so that the material can be disposed of in a responsible manner. When recycling the appliance, take it to your local collection facility or contact the place of purchase. They will ensure that the appliance is disposed of in an environmentally sound manner.

Symbol of a trash bin crossed with no text or numbers, accompanied by a horizontal line and a rectangular block below (no text or symbols present)

Specifications

Rated voltage 220–240 V AC, 50 Hz

Power 1500 W

Wavelength 1.2 μm

IP rating IP54

Cable length 1.8 m

Size 60 × 10 × 6 cm

Weight 1.7 kg

Diagram of a device with ON/OFF button and directional arrows indicating rotation (no text or symbols beyond basic labels)

Användning

Symbol of a discarded bin with crossed lines indicating no waste or plastic (no text or labels)

Specifikationer

Nätanslutning 220–240 V AC, 50 Hz

Effekt 1500 W

Våglängd 1,2 μm

Kapslingsklass IP54

Kabellängd 1,8 m

Mått 60 × 10 × 6 cm

Vikt 1,7 kg

Infravarmer med fjernkontroll, 1500 W

Art.nr. 18-1483

36-7013

Diagram of a device with ON/OFF buttons and directional arrows indicating rotation or movement (no text or symbols beyond basic labels)

Bruk

Symbol of a trash bin crossed with no text or labels, accompanied by a blank rectangular block below (no text or symbols present)

Spesifikasjoner

Nettilkobling 220–240 V AC, 50 Hz

Effekt 1500 W

Bølgelengde 1,2 μm

Kapslingsklasse IP54

Lengde ledning 1,8 m

Mål 60 × 10 × 6 cm

Vekt 1,7 kg

Diagram of a device with ON/OFF button and directional arrows indicating rotation (no text or symbols beyond basic labels)

Käyttö

Symbol of a waste bin with crossed lines indicating no waste, and a solid black rectangle below (no text or labels)

Tekniset tiedot

Diagram of a device with ON/OFF buttons and directional arrows indicating rotation or movement (no text or symbols beyond basic labels)

Gebrauch

Symbol of a waste bin with no text or labels, crossed by two crossed lines and a solid rectangle below (no text or symbols present)

Technische Daten
