KK 183 nx - Microphone NEUMANN - Free user manual and instructions
Find the device manual for free KK 183 nx NEUMANN in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Microphone capsule (miniature condenser) |
| Model | KK 183 nx |
| Brand | Neumann |
| Directional Pattern | Cardioid |
| Frequency Range | 20 Hz - 20 kHz |
| Sensitivity | 5 mV/Pa ± 1 dB |
| Impedance | 50 ohms |
| Maximum Sound Pressure Level | 140 dB SPL (THD < 0.5%) |
| Signal-to-Noise Ratio | 75 dB (A-weighted) |
| Power Supply | Phantom power 48 V ± 4 V |
| Current Consumption | 2.5 mA |
| Dimensions | Diameter 22 mm, Length 100 mm |
| Weight | 20 g |
| Connector | 3-pin XLR (male) |
| Temperature Range | -10°C to +70°C |
| Humidity Range | 0% to 95% (non-condensing) |
| Compatible Systems | Neumann KM 180 series bodies (e.g., KM 183, KM 184) |
| Cleaning | Use a soft dry cloth; avoid solvents; protect grille from dust |
| Maintenance | Check contacts regularly; store in dry environment |
| Spare Parts | Replacement grilles and internal shock mounts available |
| Repairability | Serviceable by authorized Neumann centers only |
| Safety | Use only with approved phantom power supplies |
| Warranty | 2 years (subject to local regulations) |
Frequently Asked Questions - KK 183 nx NEUMANN
What is the KK 183 nx compatible with?
The KK 183 nx is designed for use with Neumann KM 180 series microphone bodies such as the KM 183 and KM 184. It is not a stand-alone microphone.
Does the KK 183 nx require batteries?
No, it requires 48V phantom power from a mixer or audio interface. It does not use batteries.
How do I clean the KK 183 nx?
Use a soft, dry cloth to wipe the exterior. Avoid liquids or solvents. The grille can be gently brushed with a soft brush to remove dust.
What is the polar pattern of the KK 183 nx?
It has a cardioid polar pattern, which picks up sound from the front and rejects sound from the sides and rear.
Can I use the KK 183 nx for vocals?
While primarily designed for instrument miking (e.g., acoustic guitars, overheads), it can be used for vocals with proper stand positioning, though it lacks a pop filter.
What is the frequency response of the KK 183 nx?
The frequency response is 20 Hz to 20 kHz, with a slight presence boost around 6 kHz for clarity.
Is the KK 183 nx phantom power safe?
Yes, it is designed to handle 48V phantom power safely. Always ensure your power source is within the specified voltage range (44-52V).
What accessories are included with the KK 183 nx?
The capsule itself is typically sold without accessories. It requires a compatible KM 180 series body and stand. A windscreen is optional.
How do I store the KK 183 nx?
Store in a dry, dust-free environment at room temperature. Use the original case if available. Avoid extreme temperatures and humidity.
Where can I find spare parts for the KK 183 nx?
Contact Neumann authorized service centers for replacement grilles or shock mounts. Do not attempt to open the capsule yourself.
