CAS 120/R - Satellite antenna KATHREIN - Free user manual and instructions
Find the device manual for free CAS 120/R KATHREIN in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Satellite Antenna (Dish) |
| Brand | Kathrein |
| Model | CAS 120/R |
| Dish Diameter | 60 cm (estimated) |
| Frequency Range | Ku-band (10.7 - 12.75 GHz) |
| LNB Type | Universal Single LNB (included) |
| Mounting | Wall or pole mount (bracket included) |
| Material | Aluminum with steel bracket |
| Weight | Approx. 2.5 kg (including mount) |
| Dimensions (Dish) | 60 x 56 x 6 cm (approx.) |
| Polarization | Linear (H/V) via LNB |
| Gain | Approx. 36 dBi (at 12 GHz) |
| Wind Load | Up to 120 km/h operational, 150 km/h survival |
| Operating Temperature | -30°C to +60°C |
| Connector | F-type female (on LNB) |
| Power Supply | Via coaxial cable from receiver (13/18 V DC) |
| Included Accessories | LNB, mounting bracket, screws, installation guide |
| Compliance | CE, RoHS |
| Maintenance | Clean dish with mild soap and water; avoid abrasive cleaners |
| Safety | Install away from power lines; secure mount to prevent fall |
| Repair and Spare Parts | Contact Kathrein service centers; LNB and mount replaceable |
