IAN 354751 - Uncategorized Livarno Lux - Free user manual and instructions

Product Type	Decorative Solar Light
Brand	Livarno Lux
Model	IAN 354751
Power Source	Solar panel + rechargeable battery
Solar Panel	Integrated, converts sunlight to electrical energy
Battery Type	Ni-MH rechargeable battery (2/3 AAA size)
Battery Voltage	1.2 V
Battery Capacity	300 mAh
LED Count	1
LED Power	Max. 0.025 W
Lighting Duration (full charge)	Approx. 8 hours
Protection Rating	IP44 (splashproof)
Operating Temperature	-21 °C and above
Automatic Dusk-to-Dawn	Yes
ON/OFF Button	Yes
Suitable for	Outdoor decoration, private household use
Not suitable for	Room illumination, commercial use
Battery Replaceable	Yes, every 12 months for optimal performance
LED Replaceable	No; replace entire product if LED fails
Maintenance	Clean solar panel with dry lint-free cloth; remove snow/ice
Scope of Delivery	1 LED solar lamp with rechargeable battery, 1 assembly instruction
Warranty	3 years from date of purchase

Frequently Asked Questions - IAN 354751 Livarno Lux

How does the decorative solar light work?

The solar panel converts sunlight into electrical energy and stores it in a rechargeable battery. When the ON/OFF button is set to ON, the light automatically turns on at dusk and off at dawn.

What should I do if the light does not turn on at night?

Ensure the ON/OFF button is set to ON. Check that the solar panel is clean and not obstructed. Also, make sure the product is placed away from artificial light sources like street lamps, which can prevent automatic activation.

How long does it take to fully charge the battery?

In constant sunlight, a completely drained battery takes about 2 to 4 days to fully recharge, depending on sunlight intensity and temperature. The battery reaches maximum capacity after several charge cycles.

Can I replace the rechargeable battery?

Yes. The battery should be replaced every 12 months. Open the battery compartment by loosening the fastening screws, remove the old battery, and insert a new Ni-MH battery with the same specifications (1.2 V, 300 mAh). Pay attention to polarity.

What type of battery should I use?

Use a Ni-MH rechargeable battery of type 2/3 AAA, 1.2 V, with a capacity of 300 mAh. Do not use non-rechargeable batteries.

Is the LED replaceable?

No, the LED is not replaceable. If the LED fails at the end of its life, the entire product must be replaced.

How should I clean the solar light?

Clean the solar panel and housing regularly with a dry, lint-free cloth. For stubborn dirt, use a slightly dampened cloth. Avoid abrasive cleaners. In winter, remove snow and ice from the solar panel to maintain performance.

Why does the light only stay on for a short time?

The battery may be old or not fully charged. Try replacing the battery if it's more than 12 months old. Also, ensure the solar panel receives direct sunlight for as long as possible during the day.

Can the product be used indoors?

No, the product is designed for outdoor decoration only and is not suitable for household room illumination. It requires sunlight to charge.

How do I dispose of the product or battery?

Dispose of the product and battery according to local regulations. Rechargeable batteries must be recycled separately (Directive 2006/66/EC). Do not dispose of them in household waste. Return them to a collection point.

USER MANUAL IAN 354751 Livarno Lux

Black-and-white photo of two owl figurines in snowy ground, alongside three small decorative items: a small squirrel, a wooden 'WELCOME' house, and a small hedgehog (no text or symbols visible)

Assembly, operating and safety instructions

RS

DEKORATIVNASOLARNA SVETILJKA

GB / CY Assembly, operating and safety instructions Page 5

HR Upute za montažu, uporabu i sigurnost Stranica 12

Simple line drawing of a rectangular tray with three geometric shapes (cube, circle) and a numbered label '6' on the right side (no text or symbols on the shapes themselves)

List of pictograms used....Page 6

Introduction......Page 6

Proper use....Page 6

Description of parts and features....Page 6

Scope of delivery....Page 6

Technical data....Page 6

Safety instructions......Page 7

Product-specific safety instructions ...... Page 7

Safety instructions for batteries/rechargeable batteries Page 7

Functioning......Page 8

Operation Page 8

Setting up the product....Page 9

Replacing the rechargeable battery....Page 9

Charging the rechargeable battery....Page 9

Maintenance and care Page 9

Troubleshooting Page 9

Disposal Page 10

Warranty Page 11

Warranty claim procedure....Page 11

Service Page 11

List of pictograms used
	Direct current/voltage Splashproof
	Includes battery		This product is suitable for extreme tem peratures up -21 °C.

Decorative Solar Light

- Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Proper use

The product is only for decoration outdoors and is unsuitable for lighting purposes. The product is suitable for private household use. The product is not intended for commercial use or for use in other applications.

Not suitable for household room illumination.

• Description of parts and features

1 Decoration housing
2 Solar panel
3 LED
4 Fastening screw
5 Battery compartment cover
6 Seal ring
7 ON/OFF button
8 Rechargeable battery
9 Battery compartment

- Scope of delivery

1 LED Solar lamp with rechargeable battery
1 Assembly instruction

Technical data

Operating voltage: 1.2 V ===

Rechargeable

battery: 1 x Ni-MH rechargea-

ble battery/2/3 AAA/

1.2 V==/300 mAh

LED: 1 x LED

Power: max. 0.025 W

Degree of Protection: IP44 (splash proof)

Lighting time

(with full charge): approx. 8 hours

This product is suitable for extreme temperatures up -21 °C.

Safety instructions

PLEASE READ THE INSTRUCTIONS FOR USE PRIOR TO USE! PLEASE KEEP THE INSTRUCTIONS IN A SAFE PLACE! IF PASSING THIS PRODUCT ON TO A THIRD PARTY ALSO INCLUDE ALL DOCUMENTS.

WARNING! DANGER TO LIFE AND RISK OF ACCIDENTS FOR INFANTS

AND CHILDREN! Never leave children alone and unsupervised with the packaging material. There is always a risk of suffocation if children play with the packaging material. Children often underestimate risks. Always keep children away from the packaging material. This product is not a toy.

This product may be used by children age 14 years and up, as well as by persons with reduced physical, sensory or mental capacities, or lacking experience and/or knowledge, so long as they are supervised or instructed in the safe use of the product and understand the associated risks. Children should not be allowed to play with the product. Cleaning and user maintenance should not be performed by children without supervision.

This product is not suitable for children under 14 years. This product is a decorative item, not a toy. The product must be set up outside the reach of children.

Do not use the product if you detect any kind of damage.
■ Always switch off the product, when storing it in dark environment, in order not to discharge the rechargeable battery.
The illuminant is not replaceable.
■ If the illuminant fails at the end of its life, the entire product must be replaced.

Product-specific safety instructions

■ Make sure that the solar panel is free of dirt and free of snow and ice in winter. Otherwise the performance of the solar cell will diminish.

Safetyinstructions for batteries / rechargeable batteries

■ DANGER TO LIFE! Keep batteries / rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention.
■ Swallowing may lead to burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion.

DANGER OF EXPLOSION!

Never recharge non-recharge-able batteries. Do not shortcircuit batteries/rechargeable batteries and/or open them. Overheating, fire or bursting can be the result.

■ Never throw batteries/rechargeable batteries into fire or water.

Do not exert mechanical loads to batteries/rechargeable batteries.

Risk of leakage of batteries / rechargeable batteries

- Avoid extreme environmental conditions and temperatures, which could affect batteries/rechargeable batteries, e.g. radiators/direct sunlight.

If batteries / rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!

WEAR PROTECTIVE

GLOVES! Leaked or damaged batteries/rechargeable batteries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.

In the event of a leakage of batteries / rechargeable batteries, immediately remove them from the product to prevent damage.
Only use the same type of batteries / rechargeable batteries. Do not mix used and new batteries / rechargeable batteries.
■ Remove batteries/rechargeable batteries if the product will not be used for a longer period.

Risk of damage of the product

Only use the specified type of battery / rechargeable battery!
- Insert batteries / rechargeable batteries according to polarity marks (+) and (-) on the battery / rechargeable battery and the product.
Use a dry lint-free cloth or cotton swab to clean the contacts on the

battery / rechargeable battery and in the battery compartment before inserting!
■ Remove exhausted batteries/rechargeable batteries from the product immediately.

Functioning

The solar cell installed in the product converts sunlight into electrical energy and stores it in one rechargeable battery. Switch on the product with the ON / OFF button ^7 . The product will automatically light on as it begins to get dark. The in-built light-emitting diodes are a very long-life and energysaving light source. The light duration depends on the amount of sunlight, the angle of light on the solar cell and the temperature (the battery capacity is temperature-dependent). The battery does not achieve maximum capacity until after several charge and discharge cycles. In summer a completely drained rechargeable battery takes about 2 to 4 days to fully recharge in constant sunlight.

Operation

1. Take out the solar panel compartment.

Note: If necessary, please use a tool for help.

1. Switch the ON / OFF button 7 to ON position, the product will automatically switch on at dusk.
2. Put the solar panel compartment back into decoration housing 1.
3. Your product is ready for use.

Setting up the product

In order to achieve the best result, set the product up in a place where the solar panel 2 will get direct sunlight for as long as possible.

Make sure that the solar panel is not influenced by any other source of light such as yard or street lighting as otherwise the light will not come on in twilight.

☐ The light automatically switches on in twilight conditions and off again when normal outdoor lighting conditions return.

● Replacing the rechargeable battery (see Fig. B + C)

The battery should be replaced every 12 months to ensure optimum performance.

1. Take out the solar panel compartment.

Note: If necessary, please use a tool for help. Switch the ON / OFF button 7 to OFF position to switch off the product. Loosen the fastening screws 4 by using a small cross head screwdriver and then lever out the battery compartment cover 5 with the help of a slot screwdriver.

1. Exchange the old rechargeable battery 8 to a new one. Take care to the correct polarity, when inserting the new rechargeable battery. The polarity is indicated in the battery compartment 9. The new rechargeable battery has to have the same technical data like the old one (see "Technical data").

2. Now again fasten the battery compartment cover 5, fasten the fastening

screws 4 by using a small cross head screwdriver. Switch the ON / OFF button 7 to ON position to enable the product switching on during darkness.

Note: Pay attention to the seal ring otherwise the IP protection is not guaranteed.

- Charging the rechargeable battery

Note that the product must be switched on when the rechargeable battery is charging. The charging time of the rechargeable battery when the solar cell is used depends on the intensity of the sunlight and the angle of incidence of the light on the solar panel 2. Place the product so that the solar panel 2 is exposed to the sun for as long as possible. In this way you will receive the highest light levels.

● Maintenance and care

The LED 3 cannot be replaced. The product is maintenance-free, except for any necessary change of rechargeable battery.

☐ Clean the product regularly with a dry, lint-free cloth. Use a slightly dampened cloth to remove more stubborn dirt.

Troubleshooting

Note: This product has delicate electronic components. This means that if it is placed near an object that transmits radio signals, it

could cause interference. If you notice that the product is malfunctioning, remove any sources of interference from the area of the product.

Note: Electrostatic discharges may cause product to malfunction. In the event of such malfunctions, remove the rechargeable battery briefly and reinsert them.

Error Cause	Solution
The light will not switch on even though the sun shone on the product all day.	Artificial sources of light, e.g. street lighting, are interfering with the product.	Set up the product in a place where it cannot be disturbed by other sources of light.
The light does not come on or comes on only briefly.	The rechargeable battery is broken or empty or there was not enough daylight.	Replace the rechargeable battery or place the product in a location where it can receive more sunlight.

●Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics /

20-22: paper and fibreboard / 80-98: composite materials.

The product and packaging materials are recyclable, dispose of it separately for better waste treatment. The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Defective or exhausted rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Return the battery and / or the product through the appropriate collection facilities.

Improper disposal of rechargeable batteries can damage the environment!

Rechargeable batteries must not be disposed of with the household refuse. They may contain toxic heavy metals and require to be handled as special waste. The chemical symbols of heavy metals are: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries at a local collection point.

- Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase.

Should this product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty applies to defects in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.

- Warranty claim procedure

To ensure quick processing of your case, please observe the following instructions:

Please have the till receipt and the item number (e.g. IAN 123456_7890) available as proof of purchase.

You will find the item number on the rating plate, an engraving on the front page of the instructions for use (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, please contact the service department listed either by telephone or by e-mail.

You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (till receipt) and information about what the defect is and when it occurred.

Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

CYServiceCyprus

Tel.: [phone]

E-Mail: [e-mail]

CE IP 44

Serbian mark of conformity

LED dioda: 1 x LED dioda

Acumulator: 1 x accumulator

Ni-MH/2/3 AAA/

1,2V==/300mAh

LED: 1 x LED

Putere: max. 0,025 W
