Product Type	LED Light Strip
Model	YLDD01YL
Power Consumption	12W
Input Voltage	100-240V ~ 50/60Hz, 0.5A
Output Voltage	12V, 1A
Color Mode	RGB (16 million colors)
Wireless Connectivity	Wi-Fi IEEE 802.11 b/g/n 2.4GHz
Control Methods	Physical button, smartphone app (Yeelight app)
Smart Home Integration	Supports MIUI system and other smart platform products
Operating System Compatibility	Android and iOS
Lifetime	Approximately 25,000 hours
Operating Temperature Range	-10°C to +40°C
Operating Humidity Range	0% - 85%
Installation	Adhesive backing, glue to clean surface
LED Module Replaceability	Not replaceable, do not disassemble
Warranty	7-day return, 8-15 day exchange, 12-month repair (conditions apply)
Safety Precautions	Ensure proper voltage; allow ventilation to dissipate heat
Maintenance	Clean with dry cloth; avoid moisture
Hazardous Substances Compliance	Meets SJ/T 11364 standard; some parts contain hazardous elements
Manufacturer	Qingdao Yilianke Information Technology Co., Ltd

Frequently Asked Questions - Yeelight Xiaomi

How do I reset the Yeelight light strip?

Disconnect the power adapter, press and hold the power button for 5 seconds. When the light strip runs colors (red, green, blue), release the button. The indicator light will change to yellow, indicating a successful reset.

Can I use the light strip without Wi-Fi?

Yes, you can use the physical button to turn the light on/off and cycle through colors. However, smart features and app control require a Wi-Fi connection.

What is the lifespan of the Yeelight light strip?

The LED module has a rated lifetime of approximately 25,000 hours, which equals several years of normal use.

How do I connect the light strip to the Yeelight app?

Download the Yeelight app from the App Store or Google Play. Ensure the light strip is powered on, then open the app and follow the in-app instructions to connect via Wi-Fi.

Does the Yeelight light strip work with voice assistants?

The product supports MIUI system and can integrate with other smart platforms. Compatibility with Alexa or Google Assistant may require additional setup via the Yeelight app or Mi Home.

Is the LED strip replaceable if it stops working?

No, the LED module is not replaceable. Do not disassemble the product. If it fails, contact Yeelight after-sales service for warranty or replacement.

What are the warranty terms for the Yeelight light strip?

Within 7 days of purchase, you can return or exchange. Within 8-15 days, you can exchange or get repair. Within 12 months, service center decides on return, exchange, or repair. Exclusions apply for unauthorized repairs, misuse, etc.

Can I cut the light strip to a shorter length?

The manual does not specify cutting options. Most LED strips have designated cut points; check the strip for marked lines. Cutting elsewhere may damage the strip.

How should I clean the light strip?

Use a dry, soft cloth to wipe the surface. Avoid water or liquid cleaners, as they could damage the electronics.

Does the light strip work with 220V?

Yes, the input voltage range is 100-240V, so it works with both 110V and 220V systems. Ensure the adapter matches your local voltage.

USER MANUAL Yeelight Xiaomi

The light power IPL Yeelight User Manual

Due to use of this product, Yeelight LED rice lamps with high quality, and to use of new interactive mode in conjunction with algorithmic mix of natural light, with support of 16 million colors, your home will be decorated to your taste.

Usage

Clean and prepare a surface for installation

Glue to a surface of installation

Insert the power adapter into the socket

Press once "□", light strip lights on. One more time press «□», light strip is off. Press and hold «□», to choose light color.

Intellectual operation

1. Scan two-dimensional code or download Yeelight mobile application in App store.
2. To ensure that the power light is switched on, open a program and follow the instructions in the application.
   * Make sure that Wi-Fi and Internet connection are available.

This product and intellectual platform support MIUI system, and be in a network relationship with the rest of intellectual platform products.

Reset to factory settings

Disconnect the power adapter, press and hold a power button for 5 seconds, and when the light strip run colors - red, green, blue, release a button. When indicator light will change color to yellow, it would mean that the reset was successful.
* When the light strip used in new scheme, update the factory settings and connect the light strip with this scheme.

Main parameters

Model: YLDD01YL;

Color mode: RGB;

Lifetime: about 25000 hrs;

OS: Android i OC IOS;

Wireless connection: Wi-Fi IEEE 302.11 B / G / N 2,4 GHz;

Temperature range: -10- + 40'C;

Humidity range: 0% - 85%;

Input voltage: 12 B, 1 A (-)-(•-(+);

Power: 100-240 V, \~ 50/60 Hz, 0.5 A;

Capacity: 12 Wt (60 x 0,2 elements / LED module).

Cautions

1. Before using this product, check the voltage that is supplied to him; voltage mismatch can cause damage to the product and present danger.
2. The LED module is not replaceable, disassemble the product without permission.
3. Light power allocates heat during exploitation, so you need to ensure environmental air ventilation to cool the light strip.

Content of harmful substances in the product

Name of part	Harmful elements
	(Pb)	(Hg)	(Cd)	(Cr (VI))	(PBB)	(PBDE)
Light strip
Controller
Adaptor	×
Cable	×
Box
This table meets SJ / T 11364 standard : It indicates that an amount of hazardous substances in the material of the part is less, than the limit specified by GB / T 26572. × : Indicates that at least one of the components of dangerous substances are present in excess of the limits specified in GB / T 26572.

Color adjusting

Light adjusting

Adding function

Scene change

Time relay

Delay

Operation by smartphone

Soft update

Warranty

The guarantee is provided according to «Consumer Rights Law of China» and the «Law on product quality of China», service Yeelight products based on the following three positions:

1. Within 7 days from purchase, in case of problems from «Table of malfunction of the product» Yeelight after-sales service center decide whether to take the goods back and reimburse a cost or replace it with a new.

2. Within 8-15 days from purchase, in case of problems from «Table of malfunction of the product» Yeelight after-sales service center decide whether to replace it with a new or do maintenance.

3. Within 12 months from purchase, in case of problems from «Table of malfunction of the product» Yeelight after-sales service center decide whether to take the goods back and reimburse a cost or do maintenance.

The warranty does not cover such cases:

1. Unauthorized repair, misuse, interference touch, neglect, ill-treatment, the effect of fluid accident, alterations or destruction, modification, ignoring labels and safety instructions.
2. Expiration of the warranty period.
3. Damage, caused by force majeure.
4. Problems, that does not meet «Table of product faults».
5. When failures appropriate to «Table of product faults» but caused by human. For example, using wrong voltage, use a custom adapter, use in an environment, that does not meet the conditions of operation, etc., which leads to malfunction of the product.

Please read the manual before using the product

Welcome to the web site Yeelight http://www.yeelight.com Or call Yeelight telephone service: 400-619-7969 about after-sales issues Implementation of standards: Q / QDYLK0001-2015 Manufacturer: Qingdao Yilianke Information Technology Co., Ltd Address: B4, Block B, Qingdao International Innovation Park, No. 1 Weiyi Road, Laoshan District, Qingdao, China (China) Phone service: 400-619-7969

Table of product faults

Device	Fault
Light strip	No light
	Colors not change
Controller	Light strip not found
	Buttons not work
	Unable to reset
Adaptor	No power in light strip
