SMV50E00GC - Dishwasher BOSCH - Free user manual and instructions

Type	Fully integrated dishwasher
Dimensions (H x W x D)	815 x 598 x 550 mm
Net weight	26.6 kg
Gross weight	28.7 kg
Current	13 A
Plug type	GB plug
Energy consumption (Eco programme)	0.835 kWh per cycle
Water consumption (Eco programme)	11.1 L per cycle
Programme time (Eco)	210 min
Number of place settings	12
Programmes	Intensive 70°C, Eco 50°C, Quick wash 65°C, Quick wash 45°C, Pre-Rinse
Cleaning temperatures	4
ActiveWater hydraulic system	Yes
DosageAssist	Yes
Loading sensor	Yes
BLDC motor	Yes
Self-cleaning filter system	3-fold corrugated filter
AquaStop	Yes, prevents water leakage
Child lock	Yes, on door
Servo-lock	Yes
Adjustable upper basket	Rackmatic 3-stage
Cutlery basket	Standard
Inner tub material	Stainless steel (Polinox)
Warranty	10-year guarantee against rusting of inner tub
Optional accessories	SGZ1010, SMZ2014, SMZ2056, SMZ5000, SMZ5001, SMZ5002, SMZ5003, SMZ5006

Frequently Asked Questions - SMV50E00GC BOSCH

How do I start a wash cycle?

Press the On/Off button, select the desired programme using the programme selector, then press the Start button. Ensure the door is fully closed and latched.

What detergent should I use?

Use only detergent specifically designed for dishwashers. Tablets or powder are suitable. For best results, use a detergent with rinse aid and salt for hard water areas.

How do I clean the filter?

The self-cleaning filter system requires minimal maintenance. However, you should periodically remove the coarse filter and clean it under running water. The fine filter is self-cleaning during operation.

What is AquaStop?

AquaStop is a safety system that prevents water leaks. It includes a double-walled hose and a safety valve. If a leak is detected, the water supply is automatically shut off. Bosch offers a 100% lifetime warranty against water damage.

How do I adjust the upper rack?

The upper basket has a Rackmatic 3-stage adjustment. To adjust, pull the rack out, then press the levers on the sides and raise or lower the rack to the desired height. This allows you to fit larger items in the lower basket.

What programmes are available?

The dishwasher offers five programmes: Intensive 70°C for heavily soiled pots and pans, Eco 50°C for normally soiled dishes, Quick wash 65°C for lightly soiled loads, Quick wash 45°C for delicate items, and Pre-Rinse for rinsing dishes before a full wash.

What are the required niche dimensions for installation?

The dishwasher requires a niche with a height of 815 mm, width of 598 mm, and depth of 550 mm. Ensure the niche is level and has proper electrical and water connections.

Does the dishwasher have a child lock?

Yes, the door has a child lock that prevents unintended opening during a cycle. To activate, press and hold the Child Lock button (if available) or refer to the manual. This ensures safety for households with children.

Which accessories are compatible?

Compatible optional accessories include: SGZ1010 (vapor barrier plate), SMZ2014, SMZ2056, and various cutlery baskets and racks. For a full list, refer to the user manual.

How do I reset the dishwasher?

To reset, turn off the dishwasher using the On/Off button, wait for 30 seconds, then turn it back on. If the issue persists, check for error codes or consult the troubleshooting section of the manual.

USER MANUAL SMV50E00GC BOSCH

Serie | 4, fully-integrated dishwasher, 60 cm SMV50E00GC

Front view of a Bosch 1998 dual-chamber washing machine (no visible text or symbols)

The ActiveWater 60 with height-adjustable top rack: Gives you extra space for large and bulky items.

• AquaStop: 100% lifetime warranty for water damages guaranteed.
• Glass protection: for gentle care of your glasses and delicate dishes.
• Child lock on door: prevents undesigned door opening during rinsing.
• 10-year guarantee: our convincing promise of quality against rusting of the inner tub.

Technical Data

Water consumption (I) : 11.1

Total annual energy consumption (kWh) 220 days : 184

Total annual water consumption (l) 220 days : 2442

Built-in / Free-standing : Built-in

Removable top : No

Door panel options : Not possible

Height with worktop (mm): 0

Height of the product (mm): 815

Adjustable feet : Yes - front only

Maximum adjustability feet (mm): 60

Net weight (kg) : 26.624

Gross weight (kg) : 28.7

Current (A) : 13

Length electrical supply cord (cm) : 175

Plug type : GB plug

Length inlet hose (cm) : 165

Length outlet hose (cm) : 190

Hidden heating element : Yes

Water protection system description :

Triple water protection 24h

Child safety devices : Childlock appliance

Water softener : Yes

Top basket type : low

Adjustable upper basket : Rackmatic 3-stage

Bottom basket type : low

3rd Rack : None

Cutlery Basket : Standard

Optional accessories : SGZ1010, SMZ2014,

SMZ2056, SMZ5000, SMZ5001, SMZ5002, SMZ5003, SMZ5006

Included accessories 2 : vapor barrier plate

Number of place settings : 12

Color / Material panel : Black

Dimensions of the product (width x depth) : 815 x 598 x 550

Dimensions of the packed product (HxWxD) (mm):

860 × 675 × 640

Brand : Bosch

Product name / Commercial code : SMV50E00GC

Number of place settings : 12

Energy consumption (kWh) : 0.83

Reference programme : Eco

Total cycle time of reference programme (min) : 210

Installation typology : Full-integrated

Panel ready : Yes

Current (A) : 13

Energy Star Qualified : No

NSF certified : No

Plug type : GB plug

Required cutout/niche size for installation (in) : x x

Dimensions of the packed product (in) : 33.85 x 25.19 x 26,57

Net weight (lbs) : 59.000

Serie | 4, fully-integrated dishwasher, 60 cm SMV50E00GC

The ActiveWater 60 with height-adjustable top rack: Gives you extra space for large and bulky items.

• SMV50E00GC
• Built under, fully integr.able

General Specification

• 12 place settings place settings
• Energy consumption in programme Eco 50: 234 kWh per year, based on 280 standard cleaning cycles using cold water fill and the consumption of the low power modes. Actual energy consumption will depend on how the appliance is used.
• Energy consumption in programme Eco 50: 0.835 kWh
• Water consumption in programme Eco 50: 3108 litres per year, based on 280 standard cleaning cycles. Actual water consumption will depend on how the appliance is used.
• Consumption in programme Eco 50: 3108 litres water per year / 234 kWh energy per year. Based on 280 standard cleaning cycles using cold water fill and the consumption of the low power modes.
• The information relates to the programme Eco 50. This programme is suitable to clean normally soiled tableware and is the most efficient programme in terms of combined energy and water consumption.
• Programme time in programme Eco 50: 210 min
• 5 programmes: Intensive 70 °C, Eco 50 °C, Quick wash 65 °C, Quick wash 45 °C, Pre-Rinse

Features

• 4 cleaning temperatures
• ActiveWater hydraulic system
• DosageAssist
• loading sensor
• BLDC motor for heat and drain pump
• Stainless steel/Polinox
• Self-cleaning filter system with 3-fold corrugated filter
• Top of door
• End of program audible
• LED colour on indicators red/-
• electrical, external
• LED rinse aid refill indicator
• low

Baskets and Racks

• Rackmatic 3-stage
• 2x flip tines
• fix

Safety

• AquaStop - Prevent Water Leakage
• Servo-lock
• Yes
• Yes
• vapor barrier plate

Technical Information

- Dimensions of the product (HxWxD): 81.5 x 59.8 x 55 cm

Programmes

Serie | 4, fully-integrated dishwasher, 60 cm SMV50E00GC

1.2 m 60 cm 1.6 m (3.7 m) 1.5 m (3.7 m) 1.7 m 1.2 m (3.4 m) 1.5 m (3.5 m)
