10027671 - Fridge Klarstein - Free user manual and instructions

Brand	Klarstein
Model Number	10027671 (also compatible with 10027672, 10027673, 10032870, 10032871, 10033119, 10033120, 10033121)
Product Type	Refrigerator with Freezer Compartment
Power Supply	220-240 V ~ 50/60 Hz
Refrigerant	R600a (Isobutane) - flammable, environmentally friendly
Temperature Control	Rotary dial with settings from 0 (Off) to 5
Recommended Temperature Setting	3 or 4 for home or office use
Freezer Star Rating	2-star (suitable for storing pre-frozen food, making ice cream and ice cubes; not for freezing fresh food)
Defrost Method	Manual defrost recommended at least once a month
Door Seal	Magnetic; keep free from debris to ensure proper sealing
Shelves	Removable for separate cleaning
Interior Cleaning	Use soft cloth with mild detergent solution; dry thoroughly
Installation Clearance	At least 5 cm clearance at sides, 10 cm at back
Safety Features	Grounded plug; do not use extension cord or power board
Energy Saving Tips	Place in cool area, away from heat sources and direct sunlight; let hot foods cool before storing
Restart Delay	Wait 3 to 5 minutes after turning off or power loss before restarting
Refrigerant Warning	Contains flammable R600a; avoid damaging cooling circuit; keep away from fire sources
Noise Level	Normal operation includes compressor noise and coolant flow sound; slight increase due to R600a
Usage	Indoor household use only
Disposal	Do not dispose as household waste; recycle at appropriate collection point per WEEE directive

Frequently Asked Questions - 10027671 Klarstein

How do I adjust the temperature?

Turn the temperature control dial located at the upper right of the compartment. Settings range from 0 (Off) to 5. For initial use, set to 5, then after 24-48 hours adjust to 3 or 4 for normal home/office use.

How do I defrost the freezer?

Defrost the freezer at least once a month when frost buildup is excessive. Turn the temperature control to 0 to stop cooling, remove all food, and allow frost to melt. Do not use mechanical devices to accelerate defrosting. Clean and dry before restarting.

Why is there condensation on the outside of the door?

Condensation occurs when humidity in the room is high, especially in warm conditions. This is normal and not a defect. Wipe it dry and reduce door openings.

How do I clean the refrigerator?

Unplug the unit. Clean exterior and interior with a soft cloth moistened with mild detergent solution. Do not use abrasive or chemical cleaners. Dry thoroughly. Removable shelves can be washed separately.

What clearance is needed around the refrigerator?

Ensure at least 5 cm clearance on the sides and 10 cm at the back for proper ventilation. Do not block ventilation openings.

Can I store hot food directly in the refrigerator?

No, let hot food cool to room temperature before placing it inside. Storing hot food raises internal temperature and forces the compressor to work harder.

What should I do if the refrigerator stops working?

Check the power cord, power supply, and on/off switch. Ensure the unit is plugged into a working grounded outlet. If power was lost, wait 3 to 5 minutes before restarting.

Is the refrigerant flammable?

Yes, the refrigerant is R600a (isobutane), which is flammable. Handle with care: avoid damaging the cooling circuit, keep away from fire sources, and follow disposal regulations.

How can I save energy?

Place the unit in the coolest area away from heat sources and direct sunlight. Let hot foods cool before storing. Wrap foods properly and wipe containers dry. Minimize door openings.

What are the safety precautions for children?

Children aged 3 to 8 years can load and unload the refrigerator. Children aged 8+ can use the appliance with supervision. Do not allow children to play with or clean the appliance without supervision.

USER MANUAL 10027671 Klarstein

INHALTSVERZEICHNIS

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints to avoid damages. Any failure caused by ignoring the mentioned items and cautions mentioned in the instruction manual are not covered by our warranty and any liability. Scan the QR code to get access to the latest user manual and other information about the product.

CONTENT

Technical Data 9

Declaration of Conformity 9

Safety Instructions 10

Getting Started 12

Energy Saving Tips 12

Cleaning and Care 13

Troubleshooting 13

Hints on Disposal 14

TECHNICAL DATA

Item number	10027671, 10027672, 10027673, 10032870, 10032871, 10033119, 10033120, 10033121
Power supply 220-240 V ~ 50/60 Hz

DECLARATION OF CONFORMITY

Producer:

Chal-Tec GmbH, Wallstraße 16, 10179 Berlin, Germany.

This product is conform to the following European

Directives:

2014/30/EU (EMC)

2014/35/EU (LVD)

2011/65/EU (RoHS)

643/2009/EC (ErP)

1060/2010/EU (ErP)

SAFETY INSTRUCTIONS

- Check that the voltage of the power supply in your home is the same as the voltage shown on the rating label of this product.

- This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

- Keep ventilation opening, in the appliance enclosure or in the built-in structure, clear of obstruction.

- Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

- Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

- Do not damage the refrigerant circuit.

- If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.

- It is recommended to check regularly the supply cord for any sign of possible deterioration, and the appliance should not be used if the cable is damaged.

- To avoid injury or death from electrical shock, do not operate the appliance with wet hands, while standing on a wet surface.

- It is not recommended to use this refrigerator with an extension cord or power board. Please ensure that the appliance is plugged directly into the electrical outlet.

- When positioning the appliance, ensure that there is at least a 5 cm clearance at the sides and a 10 cm clearance at the back as this is the main outlet for heat. This will allow for adequate ventilation.

- Do not place hot food or drink into the refrigerator before it cools down to room temperature.

- Close the door immediately after putting in any items so the inside temperature will not rise dramatically.

- Keep appliance away from any heat source or direct sunlight.

- To fix stably, the appliance must be placed on a flat and solid surface. It should not be laid on any soft material.

- Do not place any other appliance on top of the refrigerator, and do not wet it.

- Do not store something like ether, methanol, gasoline, which is easy to evaporate burn or explode.

- Do not use outdoors or in wet conditions.

- Never pull the cord to disconnect it from the outlet. Grasp the plug and pull it from the outlet.

- Keep the cord away from heated surfaces.

- This appliance has been incorporated with a grounded plug. Please ensure the wall outlet in your house is well earthed.

- Connect your refrigerator to an independent electrical socket and use a safe ground wire.

- Defrost the freezer at least once a month because too much frost may affect refrigeration.

- Turn on electricity only 5 minutes later after electricity goes off. Otherwise, the compressor may be damaged.

This appliance contains the coolant isobutane (R600a), a natural gas which is environmentally friendly. Although it is fl ammable, it does not damage the ozone layer and does not increase the greenhouse effect. The use of this coolant has, however, led to a slight increase in the noise level of the appliance. In addition to the noise of the compressor, you might be able to hear the coolant flowing around the system. This is unavoidable, and does not have any adverse effect on the performance of the appliance. Care must be taken during the transportation and setting up of the appliance that no parts of the cooling system are damaged. Leaking coolant can damage the eyes.

Special Notes

• Children between the ages of 3 and 8 are allowed to load and unload refrigerators.
• When positioning the unit, make sure that the power cord is not pinched or damaged.
• Make sure that there are no multiple sockets or power supplies on the back of the unit.

To avoid contamination of food, please follow the instructions below:

• A prolonged opening of the door can lead to a significant rise in temperature in the compartments of the appliance.
• Regularly clean surfaces that may come into contact with food. Clean the water drain regularly.
• Store raw meat and fish in suitable containers in the refrigerator so that meat and fish do not come into contact with or drip on other foods.

Notes on the freezer compartments

• Two-star freezer compartments are suitable for storing pre-frozen foods, storing or making ice cream and making ice cubes.
• One-, two- and three-star freezer compartments are not suitable for freezing fresh food.
• If the refrigerator remains empty for an extended period, turn it off, defrost it, clean it, dry it and leave the door open to prevent mould from forming in the appliance.

WARNING

When using, servicing and disposing of the unit, pay attention to the left symbol on the rear of the unit or on the compressor. This symbol warns of possible fires. There are fl ammable substances in the refrigerant lines and in the compressor. Keep the appliance away from sources of fire during use, maintenance and disposal.

GETTING STARTED

Setting the Temperature Control

Your unit has only one control for regulating the temperature in the compartment. The temperature control is located at the upper right hand side of the compartment.

• The first time you turn the unit on, set the temperature control to „5“.
• The range of the temperature control is from position „0“ (Off) to „5“. After 24 to 48 hours, adjust the temperature control to the setting that best suites your needs. The setting of „3“ or „4“ should be appropriate for home or office use. To turn the appliance off, turn the temperature control to „0“.

Note: Turning the temperature control to „0“ position stops the cooling cycle but does not shut off the power to the unit. If the unit is unplugged, has lost power, or is turned off, you must wait 3 to 5 minutes before restarting the unit. If you attempt to restart before this time delay, the unit will not start.

ENERGY SAVING TIPS

• The unit should be located in the coolest area of the room, away from heat producing appliances, and out of the direct sunlight.
• Let hot foods cool to room temperature before placing in the unit. Overloading the unit forces the compressor to run longer.
• Be sure to wrap foods properly, and wipe containers dry before placing them in the unit. This cuts down on frost build-up inside the unit.
• Unit storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners interfere with cold air circulation, making the unit less efficient.
• Organize and label food to reduce door openings and extended searches. Remove as many items as needed at one time, and close the door as soon as possible.

CLEANING AND CARE

Outside

The outside of your refrigerator can be cleaned using a soft cloth moistened with a mild detergent solution. Wipe dry with kitchen towel. Do not use chemical or abrasive cleaners on any part of your refrigerator as these could permanently damage or discolour the surfaces.

Internal Cleaning

Wipe up any internal spills immediately with a soft cloth moistened with a mild detergent solution. Dry thoroughly.

Shelves and Guards

Any shelves can be removed and cleaned separately.

Door Seals

Ensure that the door seals are kept free from debris at all times. If they don't seal properly this can waste energy and cause refrigeration unit to over run

TROUBLESHOOTING

Problem Possible cause and	suggested solution
Condensation on outside of door.	Humidity in the room is high. This is also to be expected if the room is very warm.
Condensation on the inside of the cabinet.	This is also caused by high humidity. You can minimise this by only keeping the door open only as long as you need to.
Too cold / not cold enough inside the cabinet.	Adjust thermostat up or down accord ingly. Make sure nothing is stopping the door from sealing properly.
No power to cooler. Check power	Power cord, power supply or on/off switch.

HINTS ON DISPOSAL

Symbol of a trash bin crossed with a diagonal line, no text or numbers present

According to the European waste regulation 2012/19/EU this symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council or your household waste disposal service.
