SSK 120 A1 - Headphones CRIVIT - Free user manual and instructions

Product Type	Sports Headphones (on-ear)
Model	SSK 120 A1
Brand	Crivit
Weight	Approx. 22 g
Cable Length	120 cm
Connector	3.5 mm jack plug
Impedance	32 Ω ±10%
Sensitivity	100 dB ±10% at 1 kHz
Frequency Range	20 Hz – 20 kHz
Maximum Input Power	60 mW
Wide Band Characteristic Voltage	85 mV ±10%
Ear Cushion Sizes Included	Small, Medium (pre-installed), Large
Operating Temperature	5 – 35 °C
Humidity (non-condensing)	5 – 85%
Intended Use	Non-commercial listening of audio material
Warranty	3 years
Support IAN	93829

Frequently Asked Questions - SSK 120 A1 CRIVIT

How do I change the ear cushions on the SSK 120 A1?

Carefully pull the ear cushions off the ear clips with your fingers. Then press the desired size (small, medium, or large) onto the clips until they snap into the recesses.

How do I properly wear the sports headphones?

Place the neckband around the back of your neck. Ensure the 'R' (right) and 'L' (left) markings are on the correct sides, then lightly press the ear cushions into your ears.

Why is there no sound from the headphones?

Check that the playback device volume is turned up and that the 3.5 mm jack plug is fully inserted into the headphone socket. If the issue persists, try another device.

Sound only comes from one side. What should I do?

Ensure the jack plug is fully inserted. Also check the stereo balance control on your playback device and adjust it to the center or desired setting.

Can I use these headphones while driving or cycling?

No. Using headphones can impair your perception of ambient noise and warning signals, posing an accident hazard. Do not use while driving, cycling, or operating machinery.

How should I clean the SSK 120 A1 headphones?

Wipe the headphones with a slightly damp cloth. Remove the ear cushions and wash them under running water, then dry thoroughly before reattaching. Do not let liquids enter the headphones.

What is the best way to store the headphones?

Store the headphones in a dry environment, away from moisture and extreme temperatures.

How do I dispose of the product?

Do not dispose of it with household waste. Follow local regulations for electronic waste or take it to an approved disposal centre.

Does the product come with a warranty?

Yes, it has a 3-year warranty from the purchase date. Warranty covers material and manufacturing defects, but not transport damage, wear and tear, or improper use. Contact service hotline for claims.

Can I use an adapter with a different connector?

The headphones have a 3.5 mm jack. If your device has a different headphone socket, you may use a suitable adapter (not included) to connect them.

USER MANUAL SSK 120 A1 CRIVIT

Operating instructions

IAN 93829

DE AT CH

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

Inhaltsverzeichnis

Einführung. 3

Urheberrecht .... 3

Simple line drawing of a three chasing recycling symbol (no text or labels)

Symbol of a trash bin crossed with no text or labels

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

Inhoud

Inleiding 25

Auteursrecht 25

Simple line drawing of a recycling symbol (three chasing arrows) with no text or labels

Simple line drawing of a trash bin with two crossed lines indicating no waste or prohibition (no text or symbols)

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

Content

Introduction 47

Copyright 47

Limited liability 48

Warnings 48

Proper use 50

Safety instructions .... 50

Danger of hearing damage ..... 52

Accident hazard 53

Initial use. 54

Package contents (see fold out sides) ..... 54

Disposal of the packaging ..... 55

Operation 56

Exchanging the ear cushions ..... 56

Putting on the sports headphones ..... 57

Connecting the sports headphones ..... 57

Malfunction causes and remedies ..... 58

GB

Cleaning 60

Storage 60

Disposal 61

Appendix 62

Technical data 62

Information regarding the

EU conformity declaration ..... 63

Warranty 63

Service 65

Importer 65

Introduction

Congratulations on the purchase of your new appliance. You have clearly decided in favour of a quality product. These operating instructions are a part of this product. They contain important information in regard to safety, use and disposal. Before using the product, familiarise yourself with all of these operating and safety instructions.

Use the product only as described and only for the specified areas of application. Retain these instructions for future reference. In addition, pass these documents on, together with the product, to any future owner.

Copyright

This documentation is copyright protected. Any duplication and/or reprinting, entirely or partially, as well as reproduction of illustrations, also in modified form, is only permitted with written consent from the manufacturer.

Limited liability

The manufacturer assumes no responsibility for damage caused by failure to observe the instructions, improper use, inappropriate repairs, making unauthorized changes or for using unapproved replacement parts.

Warnings

In the current operating instructions the following warnings are used:

WARNING

A Warning of this danger level signifi es a possible dangerous situation.

If the dangerous situation is not avoided it can lead to injuries.

The directives in this warning are there to avoid personal injuries.

IMPORTANT

A Warning of this danger level sig-nifi es possible property damage.

If the situation is not avoided it can lead to property damage.

The directives in this warning are there to avoid property damage.

NOTE

A notice signifies additional information that assists in the handling of the device.

Proper use

Use of these sports headphones is intended for the non-commercial listening of audio material. Any other or unintended use is regarded as improper use and can lead to damages. Claims of any kind for damage resulting from unintended use will not be accepted.

Safety instructions

For safe handling of the device observe the following safety information:

■ Before use check the sports headphones for visible external damage. Do not operate damaged or dropped sports headphones.

■ Damaged cables or connections should be replaced by authorized qualified personnel or by the customer service department.

Persons who, due to their physical, intellectual or motor abilities, are incapable of operating the sports headphones safely must only use them under the supervision or direction of a responsible person.

■ Only permit children to use the sports headphones under supervision. Children may not be able to correctly assess potential dangers.

■ Repairs to the sports headphones should only be carried out by authorized specialist personnel or by the customer service department. Incorrect repairs can result in danger for the user. In addition warranty claims become void.

A repair to the sports headphones, during the warranty period, may only be carried out by a customer service department authorized by the manufacturer otherwise no additional warranty claims can be considered for subsequent damages.

■ Defective components may only be replaced with original replacement parts. Only by using original replacement parts can you guarantee that the safety requirements are complied with.

■ Do not undertake any unauthorised reconstruction or modifications to the sports headphones.
■ Protect the sports headphones from moisture and liquid penetration.
■ Do not use the sports headphones in the vicinity of open fl ames.

Danger of hearing damage

WARNING

Danger as a result of extreme sound levels!

Loud music can lead to hearing damage.

▶ Avoid extreme sound levels, especially over long periods of time, when you are using these sports headphones.

Accident hazard

WARNING

Danger through impaired perception!

▶ Acoustical warning and indication signals and environmental noises can sound different when you are wearing these sports headphones. Make yourself aware of how these signals deviate in their sound so that you can recognise the signals in the corresponding situations.

▶ Do not use the sports headphones when driving a vehicle, riding a bicycle, operating a machine or in any other situation in which impaired perception of ambient noise could put you or other people in danger.

Initial use

WARNING

The packaging material is not a toy. Keep plastic sheeting, bags and all other packaging material away from children. There is a risk of suffocation.

Package contents (see fold out sides)

The sports headphones are delivered with the following components as standard:

- Sports headphones with pre-installed ear cushions (medium size) ①

- 2 Pair of ear cushions (small ② and large ③)

● These operating instructions (not depicted)

NOTE

▶ Check the contents to make sure everything is there and for visible damage.

If the contents are not complete or are damaged due to defective packaging or through transportation contact the service hotline (see chapter "Service").

Disposal of the packaging

The packaging protects the device from transport damage.

Simple line drawing of a recycling symbol (three chasing arrows) with no text or labels

The recirculation of packaging into the material circuit saves on raw material and reduces generated waste.

Dispose of packaging materials that are no longer needed according to regionally established regulations.

Operation

Exchanging the ear cushions

When delivered the sports headphones are provided with medium size ear cushions. Depending on the size of your ear cup you can use ear cushions of another size from those supplied.

■ With your fingers carefully pull on the ear cushions to detach them from the sports.
■ Select from the supplied ear cushions ones that are suitable for your use. Push these directly onto the ear clips until they slip into the recesses on the ear clips.

Putting on the sports headphones

■ When putting the sports headphones on observe the indicators "R" (right) and "L" (left) on the side of the earpieces.

■ Place the neckband of the sport headphones so that the band runs around the back of your neck. Then lightly press the ear cushions into your ears.

Connecting the sports headphones

The sports headphones are equipped with a 3.5 mm jackplug. Many consumer electronic devices are provided with a corresponding headphones socket. In the event that your audio device has been provided with a different connection for headphones you can use, if necessary, a suitable adapter (not supplied).

Troubleshooting

Malfunction causes and remedies

The following table will help with localizing and remedying minor malfunctions:

GB

Defect Cause/Remedy

No sound is coming from the sports headphones.	The volume control of the play-back device is set to minimum volume.Increase the playback volume.
	The 3.5 mm jackplug is not fully inserted into the playback device's headphones socket.Plug the 3.5 mm jackplug fully into the socket.

Defect Cause/Remedy

Sound is only coming from one side of the sports headphones.	The 3.5 mm jackplug is not fully inserted into the playback device's headphones socket. Plug the 3.5 mm jackplug fully into the socket.
	The Stereo-Balance-Control on the playback device is incorrectly adjusted. Adjust it to the setting you desire.

NOTE

If the malfunction can not be remedied with the described solution proposals or if other types of malfunctions occur please contact our service department (see warranty and service).

Cleaning

IMPORTANT

Do not allow any liquids to penetrate inside the sports headphones. This can lead to irreparable damage to them.

■ Clean the sports headphones with a slightly damp cloth.

■ Remove the ear cushions for cleaning. Clean the ear cushions under running water. Dry the ear cushions well. Replace the ear cushions over the ear clips only after they have completely dried.

Storage

■ Store the ear clip headphones in a dry environment.

Disposal

Simple line drawing of a trash bin with two crossed lines indicating no waste or restriction (no text or symbols)

Under no circumstances should you throw the device into the normal household waste. This product is subject to the European directive 2012/19/EU.

Dispose of the device through an approved disposal centre or at your community waste facility. Observe the currently applicable regulations. In case of doubt, please contact your waste disposal centre.

Appendix

Technical data

Impedance 32 Ω +/-10 %
Sensitivity	100 dB +/- 10 % at 1 kHz
Transmission range 20 Hz - 20 kHz
Input power Max. 60 mW
Wide Band Characteristic Voltage	85 mV +/-10 %
Plug 3.5 mm Jackplug
Cable length 120 cm
Weight 22 g approx.
Operating temperature	5 - 35 °C
Humidity (no condensation)	5 - 85 %

Information regarding the EU conformity declaration

This device complies in regard to conformity with the basic requirements and other relevant regulations of the RoHS directive 2011/65/EU. The complete original declaration of conformity can be obtained from the importer (see chapter Importer).

CE

Warranty

You receive a 3-year warranty for this device as of the purchase date. This device has been manufactured with care and meticulously examined before delivery. Please retain your receipt as proof of purchase. In the case of a warranty claim, please get in touch, by telephone, with our service department. Only in this way can a post-free dispatch for your goods be assured.

NOTE

The warranty covers only claims for material and manufacturing defects, not for transport damage, wear and tear or for damage to fragile components, e.g. switches or rechargeable batteries.

This product is for private use only and is not intended for commercial use. The warranty is void in the case of abusive and improper handling, use of force and internal modifications not carried out by our authorized Service Centre. Your statutory rights are not restricted in any way by this warranty. The warranty period is not extended through repairs made under warranty. This applies also for replaced or repaired parts. Any damages or defi ciencies found on purchase must be reported as soon as possible after unpacking, at the latest two days after purchase. On expiry of the warranty, all repairs carried out are subject to payment.

Service

Service Great Britain

Tel.: [phone] (£ 0.10/Min.)

E-Mail: [e-mail]

IAN 93829

Hotline availability:

Monday to Friday 08:00 - 20:00 (CET)

Importer

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

GERMANY

www.kompernass.com

KOMPERNASS HANDELS GMBH

BURGSTRASSE 21

44867 BOCHUM

DEUTSCHLAND / GERMANY

www.kompernass.com

Stand der Informationen · Stand van de informatie

Last Information Update: 08 / 2013

Ident.-No.: SSK120A1-072013-2
