Product Type	Fan Heater
Model	TZR15WG / TZR15GB
Power	2000W (Max)
Voltage	220-240V~ 50/60Hz
Heat Settings	Fan only, Low (1000W), High (2000W)
Temperature Control	Adjustable thermostat
Indicator Light	Yes (power/heat on)
Safety Features	Overheat protection, DO NOT COVER warning, minimum distance 50 cm from walls
Cleaning	Wipe with damp lint-free cloth; do not use detergents
Storage	Cool down completely; store in original box
Usage	Indoor domestic use only; suitable for well-insulated spaces or occasional use
Placement	Horizontal on stable, flat, dry surface; at least 30 cm from obstacles
Children Safety	Children under 3 must be kept away; ages 3-8 only switch on/off under supervision
Repair	Do not disassemble; contact dealer or service center
Nominal Heat Output	1.883 kW
Maximum Continuous Heat Output	1.884 kW

Frequently Asked Questions - TZR15WG TERMOZETA

How do I turn on the fan heater?

Plug the heater into a suitable outlet. Turn the dial on the right clockwise: once for fan only, twice for low heat (1000W), and three times for high heat (2000W). The indicator light will illuminate when heating.

Can I use this heater in a bathroom?

No, this heater is for indoor domestic use only and must not be used in the immediate surroundings of a bath, shower, or swimming pool due to risk of electric shock.

What should I do if the heater stops working?

First, unplug the heater and let it cool. Check if the power supply and plug are functioning. If it still doesn't work, do not attempt to repair it yourself; contact the dealer or an authorized service center.

Can I cover the heater?

Never cover the heater. It can cause overheating and fire. The appliance has a 'DO NOT COVER' warning. Keep air grilles and outlets free.

How far should the heater be from walls or objects?

Maintain a minimum distance of 50 cm from walls and objects. The air flow should not be directed towards them. Also ensure a distance of at least 15 cm from wall corners.

How do I clean the fan heater?

Always unplug the heater before cleaning. Wipe the exterior with a damp, lint-free cloth. Do not use detergents, solvents, or chemical agents. Make sure it is completely dry before reusing.

Is the heater safe for use around children?

Children under 3 must be kept away unless continuously supervised. Children aged 3-8 can only switch the heater on/off under supervision. Children aged 8+ and persons with reduced capabilities can use it with proper instruction. Always supervise children near the heater as parts become very hot.

What is the power consumption of this heater?

The heater has a maximum power of 2000W (high setting) and a low setting of 1000W. The fan-only mode uses very little power.

Can I use an extension cord with this heater?

It is recommended not to use extension cords. If you must, use an extension cord that is suitable for the heater's power and unwind it completely to avoid overheating. However, the manual advises against using adapters, multiple outlets, or extension cords.

How should I store the heater when not in use?

Allow the heater to cool down completely. Store it in its original box in a dry place. Keep the power cord unwound and away from hot surfaces.

USER MANUAL TZR15WG TERMOZETA

Exterior view of a white electric heating fan with cooling fins and two side fans (no visible text or symbols)

Exterior view of a white electric heating fan with ventilation grille and two side fans (no visible text or symbols)

This product is only suitable for well insulated spaces or occasional use.

INSTRUCTION MANUAL

Please READ and RETAIN for future reference.

CAUTION: To prevent overheating do not cover the appliance. The appliance must not be placed below electric socket on the wall.

1. Remove the packing and make sure that the appliance is intact. The appliance must be intact without visible damages which could be caused by transport. In case of doubt do not use it and contact our after-sales service. Do not leave packaging materials like plastic bags, foam polystyrene, buttons and staples within reach of children.
2. If external cable is damaged, it must be replaced by a qualified service assistance.
3. Before cleaning and maintenance disconnect the appliance from electric socket.
4. In case of abnormal situation turn off the appliance immediately and contact the dealer or the service.
5. Do not use flying sockets or damaged cables.
6. Hold the plug firmly when disconnecting from the electric socket to prevent electric shock, short circuit or fire.
7. It's absolutely forbidden to dismount or repair the unit: risk of electric shock; contact your dealer or service center.
8. Do not insert items in the slots of the unit.
9. Before connecting the appliance check if the electrical voltage and frequency of the circuit correspond to those indicated on the appliance.
10. The unit is for domestic use only. Do not cover the appliance while it's turned on or plugged. Don't expose the product to atmospheric agents.
11. Danger. Do not use it for other purposes.
12. Before connecting the appliance check if the electrical voltage and frequency of the circuit correspond to those indicated on the appliance.

13. Do not to use adapters, multiple outlets and/or extension cords.

14. Use the appliance only for the mentioned purpose, namely for heating for domestic use. Do not use it for any other application as it could get dangerous. The manufacturer is not responsible for any eventual damages caused by improper or faulty use.

15. The product is intended for indoor use only. Don't ‘use it externally. Don’t allow atmospheric agents to in touch with the product.
16. The use of every electrical appliance calls for the awareness of some basic rules, such as:
    -Never touch the appliance with wet or damp hands or feet.
    -Never use the appliance with bare feet.
17. Never pull the chord of the appliances.
18. Before cleaning the appliance or carrying out any maintenance switch off the whole system or disconnect the appliance
19. If the appliance malfunctions or is out of work switch it off without tampering it. If any repair is required please contact only the after-sale centers approved by the manufacturer and ask for original spare parts. Otherwise safety of the appliance can be compromised.
20. When the appliance is not in use switch it off and unplug it. Make harmless the parts of the appliance which could be handled hazardously by children for playing.
21. Children should be supervised to ensure that they do not play with the appliance.
22. To avoid overheating risks you are recommended to unwind completely the extension cord.
23. Keep the power chord far from hot sources. Don't put heavy objects on the cable. Don't allow it twists around the product.
24. Don't allow power chord hangs down form the table.
25. Never pull the chord of the appliance for moving it or for disconnecting it from main supply.
26. After use, disconnect the product from main supply.
27. Air grilles and outlets must be kept free, in order to avoid over heating of the product.
28. Keep a minimum distance of 50 cm from walls and objects avoiding that the air flow is directed towards them. Avoid that between the

appliance and the wall corners there is a distance which is lower than 15 cm.

1. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
2. Avoid power chord goes in touch with the frontal grille of the product.
3. Do not use this heater in the immediate surroundings of a bath, a shower or a swimming pool.
4. Only use the product in horizontal position.
5. Always position the product on a stable, flat, dry surface.
6. Maintain the outlet grille clean.
7. The heater must not be located immediately below a socket outlet.
8. Don't use the appliance near explosive or flammable materials.

36.

DO NOT COVER

WARNING: In order to avoid overheating, do not cover the heater.

1. Warning: do not place the unit near curtains or other combustible materials for risk of fire
2. Children of less than 3 years should be kept away unless continuously supervised.

3. Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.

4. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

5. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision

6. Caution — some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present
7. When the product is working just touch the knobs and the handle
8. Do not use this device connected to controllers, timers, remote control or any other device that may turn the unit automatically on, risk of fire if the unit is covered or placed uncorrectly.
9. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
10. This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
11. or instruction concerning use of the appliance by a person responsible for their safety.
12. Warning: to prevent overheating, do not cover the appliance.
13. Always be sure that air outlets are free and not obstructed.
14. Don't leave the heater without supervision when plugged.
15. Don't use the product in very small environments or where many people are present.
16. Do not use f lying sockets or damaged cables
17. Hold the plug firmly when disconnecting from the electric socket to prevent electric shock, short circuit or fire.
18. Don't try to repair the product by yourself. Don't dismount it. Always refer to the dealer or Technical Center.
19. Don't insert any objects into the product slots and grilles.
20. Don't use unproperly the product, don't use it for other purposes respect to which it has been design.

GENERAL OVERVIEW

1. POWER SETTING
2. TEMPERATURE SETTING
3. INDICATOR LIGHT
4. AIR OUTLET

HOW TO USE

Remove the unit from the box and take off any protective wrapping and unwind the cord to its full length.

Place the heater on a smooth level surface at least 30cm away from any obstacles.

Plug your fan heater into the power supply. Make sure the power supply corresponds to the power indicated on the rating label. Insert the plug of the heater into a suitable power outlet making sure not to locate the heater immediately below a socket outlet. The heat temperature setting can be regulated using the switch located on the top of the heater. This switch is use for both the fan and heat elements. Note the fan speed cannot be altered and will always remain constant to turn the appliance on:

- Fan-for a lower power air circulator; Turn the dial on the right clockwise, once for the fan function.

• Low-Turn it twice for the Medium heat setting (1000W). This setting is best suited for smaller, well-insulated areas that require less warming.
  • High-Turn the switch once more for High setting, or full power (2000W) which delivers rapid warm air to increase the temperature to a given area.

CLEANING AND STORING

• Always disconnect the appliance from the main power outlet before cleaning.
- Clean the outside of the heater by wiping with a damp, lint free cloth.
• Do not use any detergents/solvents or chemical agents to clean the heater.
• Make sure that the heater has cooled down completely before storing.
- Storing the heater in its original box is highly recommended.

TECHNICAL DATA

MODEL: TZR15WG/ TZR15GB

POWER: 2000W

VOLTAGE: 220 – 240V\~ 50/60 Hz

INFORMATION REQUIREMENTS FOR LOCAL SPACE HEATERS

Model identifier(s):		TZR15WG / TZR15GB
Item	Symbol	Value Unit Item Unit
Heat output				Type of heat input, for electric storage local space heaters only (select one)
Nominal heat output	P_nom	1.883	kW		Manual heat charge control, with integrated thermostat
Minimum heat output (indicative)	P_min	0	kW		Manual heat charge control with room and/or outdoor temperature feedback
Maximum continuous heat output	P_max,c	1.884	kW		Electronic heat charge control with room and/or outdoor temperature feedback
Auxiliary electricity consumption					Fan assisted heat output
At nominal heat output	el_max	N/A kW			Type of heat output/room temperature control (select one)
At minimum heat output	el_min	N/A kW			Single stage heat output and no room temperature control
In standby mode	el_SB	N/A kW			Two or more manual stages, no room temperature control
					temperature control
					With electronic room temperature control
					Electronic room temperature control plus day timer
					Electronic room temperature control plus week timer
					Other control options (multiple selections possible)
					Room temperature control, with presence detection
					Room temperature control, with open window detection
					With distance control option No
					With adaptive start control No
					With working time limitation No
					With black bulb sensor No
Contact details	Lange Distribution S.r.l. Via Treviso, 35 - 20127, Milano - Italy mail: [e-mail] www.termozeta.com Tel. [phone]

In accordance with European Directive 2012/19/UE on electric and electronic equipment waste disposal.

1. The barred symbol of the rubbish bin shown on the equipment indicates that, at the end of its useful life, the product must be collected separately from waste.
2. Therefore, any products that have reached the end of their useful life must be given to waste disposal centres specialising in separate collection of waste electrical and electronic equipment, or given back to the retailer at the time of purchasing new similar equipment, on a one for one basis.
3. The adequate separate collection for the subsequent start-up of the equipment sent to be recycle, treated and disposal of in an environmentally compatible way contributes to preventing possible negative effects on the environment and health and optimises the recycling and reuse of components making up the apparatus.
4. Abusive disposal of the product by the user involves application of the administrative sanctions according to the laws in force.

Lange Distribution S.r.l. reserves the right to introduce technical and/or aesthetic changes to its products intended to improve performances. Termozeta is an international trademark. Copyright © 1995. All rights reserved. Lange Distribution S.r.l. -Via Treviso,35-20127 Milano-Italy
