Airbed - Air mattress Easy Home - Free user manual and instructions

Product Type	Air mattress (inflatable bed)
Brand	Easy Home
Model	Airbed (77260 / MLHUS / 16005)
Dimensions (W x D x H)	59.8\" x 79.9\" x 18.5\" (152 x 203 x 47 cm)
Weight	Approx. 17.6 lbs (8 kg)
Maximum Load Capacity	602 lbs (273 kg)
Power Supply	110–120 V, 60 Hz
Power Output	120 W
Protection Class	II (double insulated)
Inflation Method	Automatic (built-in pump) or manual (external pump)
Deflation Method	Automatic (built-in pump) or manual (open valve)
Pump Control	Rotary knob with \"Inflate\", \"Deflate\", and \"Off\" positions
Valve Type	Dual-cap valve for rapid inflation/deflation
Material	Vinyl (PVC)
Includes	Airbed, built-in pump, valve, cover cap, 2 repair patches
Intended Use	Indoor sleeping/resting only; not for water or commercial use
Cleaning	Wipe with damp cloth and mild soap; do not submerge or machine wash
Storage	Deflate completely, fold gently, store in dry place at 41–68°F (5–20°C)
Safety Features	Overheat protection, cool-touch plug, child-resistant design
Repairability	Small holes repairable with included patches; top side with repair glue
Warranty	Refer to warranty card included in packaging

Frequently Asked Questions - Airbed Easy Home

How do I inflate the airbed automatically?

Spread the airbed on a flat surface. Remove the cover cap and plug the power cord into a socket. Turn the pump control clockwise to the "Inflate" position. The pump will start. Once desired firmness is reached, turn the control to "0", unplug, and store the cord behind the cap.

How do I deflate the airbed automatically?

Plug in the airbed. Turn the pump control counterclockwise to the "Deflate" position. The pump will suck out air. When deflated, turn to "0", unplug, and store the cord behind the cap.

Can I use the airbed manually without electricity?

Yes. For manual inflation, open the valve cap and use a suitable external air pump (not included). For manual deflation, open both caps of the valve and let air escape on its own.

What is the maximum weight capacity?

The maximum load capacity is 602 lbs (273 kg). Do not exceed this limit to avoid damage or injury.

How do I clean the airbed?

First unplug the power. Wipe the surface with a damp cloth and a small amount of mild soapy solution if needed. Do not use harsh cleaners, brushes, or submerge in water. Let it dry completely before storage.

Can I use the airbed outdoors or on water?

No. The airbed is strictly for indoor use only. It is not a raft or flotation device and poses a risk of drowning or electric shock if used near water.

How should I store the airbed?

Deflate completely. Lay it flat with the sleeping surface up and fold gently following the folding instructions (see figure E). Store in a dry place away from direct sunlight, at room temperature (41–68°F / 5–20°C). Keep out of reach of children.

Can small children sleep on this airbed?

No. Children 15 months or younger must not sleep on inflatable mattresses due to suffocation risk. Older children should be supervised.

What do I do if the airbed develops a hole?

Small holes on the sides or bottom can be repaired using the included repair patches. For damage on the top side, use commercially available repair glue. Follow the patch/glue instructions. If the damage is large, dispose of the airbed properly.

Why does the airbed lose firmness after the first use?

New vinyl tends to stretch initially, which is normal. The airbed may require re-inflation during the first few days to maintain desired firmness. Changes in ambient temperature and load can also affect firmness.

USER MANUAL Airbed Easy Home

English......06

Español .....17

Contents

Overview ....3

Use....4

Pack contents/parts....6

General information....7

Reading and storing the user manual .....7

Explanation of symbols 7

Safety 8

Proper use....8

Safety notes 8

Use....12

Checking the airbed and product contents 12

Inflating the airbed 12

Deflating the airbed 13

Adjusting the firmness of the airbed....14

Cleaning....14

Storage 15

Repair....15

Technical data 16

Disposal....16

Disposing of the packaging 16

Disposing of old appliances 16

Zur Freigabe V2

Pack contents/parts

1 Airbed
2 Air pump
3 Valve
4 Pump control
5 "Deflate"
6 "Inflate"
7 Cover cap
8 Repair patches (not shown)

General information

Reading and storing the user manual

This user manual accompanies this airbed. It contains important information on handling and use.

Before using the airbed, read the user manual carefully. This particularly applies to the safety instructions. Failure to heed this

user manual may result in severe injury or damage to the airbed.

Store the user manual for future use. Make sure to include this user manual when passing the airbed on to third parties.

Explanation of symbols

The following symbols and signal words are used in this user manual, on the airbed or on the packaging.

WARNING!

This signal symbol/word designates a hazard with moderate degree of risk which may lead to death or severe injury if not avoided.

NOTICE!

This signal word warns against potential damages to property.

This symbol provides you with additional useful information regarding handling or use.

Protection class II

This airbed can melt or burn.

Keep the airbed away from fire, heaters and other hot objects. Do not smoke on the airbed.

The airbed is not to be used as a rescue device. It is not permitted to be used in water. It is not a flotation device or an aquatic toy.

The airbed is not suitable for use as a standing area, stepladder or for hopping on.

Keep the airbed away from sharp objects to prevent damage.

Never lay a small child 15 months of age or younger down to sleep on inflatable mattresses.

Safety

Proper use

The airbed is only designed for rest/sleep. It is only intended for private use and not suitable for commercial purposes.

Only use the airbed as described in this user manual. Using it in any other way is deemed improper and may result in damage to property or even personal injury. The airbed is not a children's toy.

The manufacturer or vendor cannot be held liable for damages incurred through improper or incorrect use.

Safety notes

WARNING!

Risk of electric shock!

A faulty electrical installation or excessive line voltage may result in an electric shock.

• Only connect the air pump if the line voltage of the socket corresponds to the specification on the nameplate.
• Only connect the air pump to an easily accessible socket so that you can quickly disconnect the air pump from the grid in the event of a fault.

- Do not use the airbed if it is visibly damaged or if the power cable or power plug is defective.

- If the power cable of the air pump is damaged, the manufacturer, its after sales support or a person with similar qualifications must replace it to avoid risks.

- Do not open the housing; instead, have a qualified professional perform the repairs. Contact a qualified workshop for this. Liability and warranty claims are waived in the event of repairs performed by the user, improper connection or incorrect operation.

- Only parts that comply with the original device data may be used for repairs. Electric and mechanical parts, which are essential for providing protection against risk sources, are contained in this airbed.

- Do not operate the air pump with an external timer or separate telecontrol system.

- Do not immerse the air pump, the power cable and the power plug in water or other liquids.

- Never touch the power plug with wet hands.

- Never pull the power plug out of the socket by the power cable; instead, always do so by taking hold of the power plug.

- Never use the power cable as a carrying strap.

- Keep the airbed, power plug and power cable away from open flames and hot surfaces.

- Lay the power cable so that it does not pose a tripping hazard.

- Do not kink the power cable and do not lay it over sharp edges.

- Only use the airbed in indoor areas. Do not use it in wet rooms or in the rain.

- Never reach to retrieve an electrical device if it has fallen in water. In such a case, immediately disconnect the power plug.

• Make sure that children do not insert any objects in the airbed.
• Always switch the airbed off and pull the power plug out of the socket when you are not using the airbed, cleaning it or in the event of a fault.

WARNING!

Danger for children and persons with impaired physical, sensory or mental capacities (e.g. partially disabled persons, older persons with reduced physical and mental capacities) or lack of experience and knowledge (e.g. older children).

• This airbed may be used by children 8 years and over as well as persons with impaired physical, sensory or mental capacities or those lacking experience and knowledge if they are supervised or have been instructed in how to safely use the airbed and have understood the risks associated with operating it. Children must not play with the airbed. Cleaning and user maintenance must not be performed by unsupervised children.
• Keep children under 15 months of age away from the airbed and connector cable.
• Do not leave the airbed unattended when inflating and deflating it.
• Do not let children play with the packaging wrapper. Children may get caught in it when playing and suffocate.
• Make sure that the mattress and walls, chests or other vertical objects are at least shoulder-width apart to prevent any risk of a child getting caught there.

WARNING!

Burn hazard and risk of explosion!

Never expose the airbed to hot or explosive materials, there is a burn hazard or risk of explosion.

• Do not use any cleaning or repair sprays that could catch fire and fulminate.
• Keep open flames and electrical heat sources away from the airbed.

WARNING!

Risk of drowning!

The airbed is not suitable for use in water. It is not a raft or buoyancy aid. There is a risk of drowning or a short circuit if you use it on water.

• The airbed is only suitable for domestic use in indoor spaces.
• Never use the airbed near or on water bodies.

NOTICE!

Risk of damage!

Improper handling of the airbed may result in damage to the airbed.

- Place the airbed on an easily accessible, level, dry and sufficiently stable surface where there are no sharp edged and pointy objects.

- Never expose the airbed to high temperatures (heaters etc.) or to the effects of the weather (rain etc.).

- Never fill the airbed with liquid.

- Do not exceed the airbed's load bearing capacity of 602 lb (273 kg).

- Stop using the airbed if the airbed's foil body or air pump exhibit cracks or breaks or are deformed.

Use

Checking the airbed and product contents

NOTICE!

Risk of damage!

If you are not cautious when opening the packaging with a sharp knife or other pointed object, you may quickly damage the airbed.

- Be very careful when opening.

1. Take the airbed out of the packaging.
2. Check to make sure that the delivery is complete (see fig. A).
3. Check whether the airbed or the individual parts exhibit damage. If this is the case, do not use the airbed. Contact the manufacturer at the service address specified on the warranty card.

Inflating the airbed

Automatically inflating the airbed

NOTICE!

Risk of damage!

Handling the airbed improperly could damage the airbed. - When inflating the airbed, always stay close to it.

1. Spread the airbed 1 out in an open area.
2. Remove the cover cap 7 and insert the power plug in a properly installed socket (see fig. B).
3. Turn the pump control 4 clockwise to the "Inflate" position 6 (see fig. C).

The air pump 2 will start inflating the airbed.

1. As soon as the desired firmness has been reached, turn the pump control to position "0".
2. Pull the power plug and store it behind the cover cap.
3. Repeat steps 1–5 as needed.

Manually inflating the airbed

1. Spread the airbed 1 out in an open area.
2. Open the first cap of the valve 3 and insert a suitable air pump in the valve (see fig. D).
3. Inflate the airbed until it has reached the desired firmness.
4. Remove the air pump.
5. Close the valve cap.

Deflating the airbed

Automatically deflating the airbed

NOTICE!

Risk of damage!

Handling the airbed improperly could damage the airbed. - When deflating the airbed, always stay close to it.

1. Remove the cover cap 7 and insert the power plug in a properly installed socket (see fig. B).
2. Turn the pump control 4 counterclockwise to the "Deflate" position 5 (see fig. C).

The airpump 2 will start deflating the airbed.

1. As soon as the airbed has been deflated, turn the pump control to position "0".
2. Pull the power plug and store it behind the cover cap.

Manually deflating the airbed

- Open the two caps of the valve 3. The air will escape on its own and the airbed will be deflated.

Adjusting the firmness of the airbed

The air in the airbed may expand or contract depending on the ambient temperature and the load on the airbed. The firmness of the airbed may also change as a result.

It is normal for new vinyl to expand. It is therefore possible that the airbed initially loses some of its firmness and has to be inflated in order to maintain the desired level of firmness. This is a normal occurrence during the first days of use. The specified dimensions are only of an approximate nature and may vary depending on the temperature of the vinyl and air.

• Add air to increase the firmness of the airbed (see chapter "Inflating the airbed").
• Let air escape to decrease the firmness of the airbed (see chapter “Deflating the airbed”).

Cleaning

WARNING!

Risk of electric shock!

Water that has penetrated the airbed may result in an electric shock.

- Disconnect the power plug before cleaning.

NOTICE!

Risk of short circuit!

Water that has penetrated the airbed may cause a short circuit.

• Never submerge the airbed in water.
• Make sure that no water penetrates the airbed.
• Do not in any case wash the airbed in the washing machine. It would be destroyed as a result.

NOTICE!

Risk of damage!

Improper handling of the airbed may result in damage.

- Do not use any aggressive cleaners, brushes with metal or nylon bristles or sharp or metallic cleaning utensils such as knives, hard scrapers and the like. They could damage the surfaces.

1. Disconnect the power plug before cleaning.
2. Wipe the airbed off with a damp cloth and, if necessary, a small amount of soapy solution.
3. Then let the airbed dry completely.

Storage

1. All parts must be completely dry before storage.
2. Let the airbed completely deflate before storing it (see chapter "Deflating the airbed").

3. Lay the airbed down flat with the sleeping surface up and gently fold it as described in the folding instructions (see fig. E).

4. Always store the airbed in a dry area.

5. Protect the airbed from direct sunlight!
6. Store the airbed so that it is not accessible to children, securely locked away and at a storage temperature between 41°F and 68°F (+5°C and +20°C) (room temperature).

Repair

• You can repair small holes in the sides or on the bottom of the airbed with commercially-available repair patches (2 repair patches 8 are included with the airbed).
• If the top side of the airbed is damaged, you can repair it with commercially available repair glue.
• When using repair patches or glue, follow the manufacturer's instructions.
• If you are unable to repair the damage, dispose of the airbed in accordance with applicable regulations (see chapter "Disposal").

Technical data

Model: 77260// MLHUS/16005

Supply voltage: 110–120 V; 60 Hz

Output: 120 W

Protection class: II

Weight: approx. 17.6 lbs (8 kg)

Dimensions (W × D × H): 59.8" × 79.9" × 18.5" (152 × 203 × 47 cm)

Max. carrying capacity: 602 lbs (273 kg)

Article number: 94235

Disposal

Disposing of the packaging

- Sort the packaging before you dispose of it. Dispose of paperboard and cardboard with the recycled paper service and wrappings with the appropriate collection service.

Disposing of old appliances

• Should the airbed no longer be capable of being used at some point in time, dispose of it in accordance with the regulations in force in your city or state.
• Please ensure your recycling information applies to local regulations and the EPA recommendations (www.epa.gov).
